We are greatly satisfied in complementing you for purchasing a product from the AGCO of Brazil line. This manual was developed to inform you about the correct procedures to be adopted during operation, adjustments and maintaining the Pneumatic Planter MP 506 It i’ IIF. The implement was developed and manufactured to provide maximum yield, savings. versatility, durability, and easy operation in a broad range of working conditions. Monoblock frame with reinforced structure, designed and developed to ensure resistance to the strains generated from the soils various conditions. The head is articulated. which makes transportation and storage easier.

• It also has a height-adjustable hitch that makes it possible to level the implement with all tractor models. The wheels are independent and can be moved along the frame in order to adjust to various spacing without the tires running over the rows already planted, equipped with a device for pressuring the soil designed with a spring and free travel. ensuring the continual and correct engagement of the transmissions.
• The fertilizer containers are hinged, which facilitates cleaning and maintenance, and are made of polymeric material that ensures resistance against corrosion and increases its useful life. The distribution of fertilizers is done with the transversal metering system, conventional models, and Ferti system (Optional). The highly mismatched fertilizer lines ensure straw flow. can be mounted with furrowers of dual disks (with options of 15″ and 16″). and pressure system adjusted together with the cutting disk adjustment. Mismatched cutting disk with diameters of 18″ and 20″. pressure system by means of compression spring, and front adjustment through a threaded rod and nut. The seed lines are fitted with 15″ and 16″ double disks (optional furrowing rods) that can be assembled as matched or mismatched and with the pantographic articulation system.
• The seed distribution is done my means of stainless steel disks positioned inside the Matermacc Seed Distributors that makes it possible to precisely distribute different types of seeds. The turbine is driven by a hydraulic motor or drive shaft. Set of seed depth limiting devices and compactors available in various models, adapting to each planting situation.
• The depth limiting device set at the side of the seeds double disk (Optional) maintains the uniformity of the depth in which the seed is deposited. The disarm-arm furrower systems (optional) and line marker (optional) are technologies that ensure greater agility and quality to work when planting. For any further clarification or to solve technical problems see your AGCO of Brazil Authorized Dealer who. together with the Technical Assistance Department ensure full operation of your implement. in whatever event. It is important to keep handy the Information contained in the identification plate that can be found fixed to the implement frame.
