Massey Ferguson MF85 MF88 MF Super 90 MF Super 90WR Shop Manual – PDF DOWNLOAD

Description

Massey Ferguson MF85 MF88 MF Super 90 MF Super 90WR Shop Manual

FILE DETAILS:

Massey Ferguson MF85 MF88 MF Super 90 MF Super 90WR Shop Manual

Language: English
Size: 64.7 MB
Pages:  70
Format: PDF
Downloadable: YES

DESCRIPTION:

Massey Ferguson MF85 MF88 MF Super 90 MF Super 90WR Shop Manual

SAMPLE PAGES FROM THE MANUAL:

TROUBLESHOOTING:

The following paragraphs list the more common troubles encountered in the operation of the power steering system. Once the cause of trouble is determined, the procedure for correction is usually evident. LOSS OF POWER ASSISTANCE. Most common cause is low system pressure or flow, which may be due to insufficient fluid in reservoir, defective pump or relief valve or plugged or restricted lines. Other possible causes are binding linkage or sticking or worn control valve.

• POWER ASSISTANCE IN ONE DIRECTION ONLY. Could be caused by sticking or worn control valve and/ or valve linkage, or faulty cylinder. UNEQUAL TURNING RADIUS. Could be caused by binding or bent linkage, or improperly adjusted tie- rods. ERRATIC STEERING CONTROL. Could be caused by plugged filter, low fluid level, sticking or worn control valve or faulty relief valve. UNEQUAL TURNING EFFORT.
• Could be caused by sticking or worn control valve, faulty cylinder or bind- ing mechanical linkage. In checking for trouble, note the tree back and forth movement of the worm shaft (7—Fig. MFIOQ) when the steering wheel is turned with the en- gine not running. Movement should be approximately equal both directions from center. Listen for unusual noises.

TABLE OF CONTENTS:

Massey Ferguson MF85 MF88 MF Super 90 MF Super 90WR Shop Manual

BELT PULLEY
BRAKE
Adjustment
R&R andOverhaul
CARBURETOR (Gasoline)
CARBURETOR (LP-Gas)
CLUTCH (Engine Except Multipower)
(Multipower Clutch)
CLUTCH (PTO)
COOLING SYSTEM (Non-Diesel)
Radiator
WaterPump
COOLING SYSTEM (Diesel)
Radiator
WaterPump
DIESELFUELSYSTEM
Bleeding
Fuel Filters
Injector Nozzles
Overhaul
Remove :5 Beinstall
Testing
Injection Pump
Remove 6 Reinstall –
Pro-combustion chambers
DlFFEREN‘l’IAL
ELECTRICAL SYSTEM (Non‘Diesel)
ELECTRICAL SYSTEM [Diesel]
ENGINE (Non-Diesel)
Camshaft
Connecting rods and hearings ,
Crankshalt and bearings
Cylinder head
Cylindersleeves
Flywheel
Ignition Timing
Main Bearings
Oil Pump
PistonstSHings
Piston pins
Relief valve
RearOilSeal
Rockerarrns
Timing gears
Valve guides
Valves &seats l
Valvessprings
ENGINE(Diese1)
Balancer assembly
Camshaft
Connecting rods and bearings
Crankshaft and bearings
Cylinder head
Cylinder sleeves
ENGINE (Diesel) Cont
Flywheel
Injection timing
Main bearings
Oil pump
Pistons and rings
Piston pins
Relief valve
Rear oil scal
Timing gears
Valve guides
Valves Sseats
Valves springs
FINALDRIVE
Bevel Gears
Bull geard pinion
Planetary final drive
FRONTSYSTEM
Axle main member
Dual wheel tricycle
Steering spindles
Single wheel and fork
Tierod sand toein
GOVERNOR (Non-Diesel)
HYDRAULIC LIFT SYSTEM
Adjustment
Control irarne
Lift cover RSR
Pump
Rock shaft and cylinder
Remote cylinder
Remote valve
IGNITION SYSTEM
LP-GAS‘SYSTEM
Carburetor
Fuel ton): and lines
Adjustment
Vaporizer
POWERTAKEOI’F
Control valve
Dump valve
Outputshaft
Trouble shooting
STEERING SYSTEM
Control valve
Cylinders and pistons
Lower gear and housing
Pressure relief valve
Pump
Rear steering gear
Trouble shooting
Worm shaft and upper gear
