Mustang 642 842 844 Telehandler Parts Manual 913289 – PDF DOWNLOAD

Description

Mustang 642 842 844 Telehandler Parts Manual 913289 – PDF DOWNLOAD

FILE DETAILS:

Mustang 642 842 844 Telehandler Parts Manual 913289 – PDF DOWNLOAD

Language : English
Pages : 266
Downloadable : Yes
File Type : PDF
Size: 5.57 MB

TABLE OF CONTENTS:

Mustang 642 842 844 Telehandler Parts Manual 913289 – PDF DOWNLOAD

Introduction
Table of Contents 2
Filter Reference 4
Cab
Standard Cab 8
Front and Rear Window (Enclosed Cab) 10
Wipers – Front and Rear Window (Enclosed Cab) 12
Top and Left Window (Enclosed Cab) 14
Cab Door (Enclosed Cab) 16
Instrument Panel and Switches 18
Fuses, Wire Harnesses and Electrical 20
Front and Rear Lights 22
Heater 24
Steering Column Components 26
Seat 28
Brake Valve 30
Brake and Accelerator Pedals 32
Cab Mounts 34
Chassis, Covers and Tanks
Outrigger 36
Hoods and Covers 38
Fuel Tank and Battery 42
Hydraulic Reservoir 44
WPS (Personnel Work Platform)
Personnel Work Platform Group 46
Radio Remote – Transmitter and Receiver 48
Engine
External Components – 115 H P Engine 50
External Components – 99 H P Engine 52
Air Intake – 115 H P Engine 54
Air Intake – 99 H P Engine 56
Exhaust 58
Radiator and Coolers (115 H P Engine) 60
Radiator and Coolers (115 H P Engine) 64
Transmission
External Components and Driveshafts 66
Torque Converter Housing 68
Case and Plate 70
Torque Converter 72
Gear Assembly 74
Drive Pump 76
Continued on next page
PRINTED IN U S A 3 913289/BP0208
Transmission (continued)
Charge Pump 77
Reverse Idler 78
Forward and Reverse 80
Third Shaft 82
First and Second Shaft 84
Output Shaft 86
Electronic Controllers 88
Drive Plate 90
Modulation Valve 91
Axles
Mounts, Tires and Fenders 92
Brake and Steering Hydraulic Circuit 94
Tie Rods, Steer Cylinder and Center Housing (Front and Rear) 96
Differential (Front and Rear) 98
Outer End (Front and Rear) 100
Brakes (Front) 102
Brakes (Rear) 103
Boom Components
Outer Boom (Front) 104
Outer Boom (Rear) 106
Outer Boom Side Cover 108
Intermediate Boom (Front) 110
Intermediate Boom (Rear) 112
Intermediate Boom Hose Tray 114
Intermediate Boom Chain 116
Inner Boom (Front) 118
Inner Boom (Rear) 120
Attachment Bracket Assembly 122
Boom Hydraulics
Boom Extend / Retract 124
Tilt 126
Slave (Compensation) 128
Boom Up/Down 130
Auxiliary Hydraulics Circuit 132
Chassis Hydraulics
Frame Level 134
Frame Stabilizer 136
642 / 842 / 844 Telehandler Table of Contents
913289/BP0208 4 PRINTED IN U S A
Hydraulics
Hydraulic Pump 138
Steering 140
Main Valve 142
Main Valve – Dual Controls 144
Main Valve – Radio Remote Control Option 146
Dual Controls (Standard) 148
Dual Controls (w/Auxiliary Hydraulics) 150
Dual Controls (w/Outriggers) 152
Dual Controls (All Options except WPS) 154
Dual Controls (w/WPS Only) 156
Dual Controls (w/WPS and Outriggers) 158
Dual Controls (w/WPS and Auxiliary Hydraulics) 160
Dual Controls (w/WPS, Outriggers and Auxiliary Hydraulics) 162
Dual Controls (Radio Remote) 164
Dual Controls (Radio Remote – w/Outriggers) 166
Dual Controls (Radio Remote – w/Auxiliary Hydraulics) 168
Dual Controls (Radio Remote – w/Auxiliary Hydraulics and Outriggers) 170
Outrigger Main Valve / Controller 172
Hydraulic Cylinders
Frame Level 174
Stabilizing 176
Boom Lift 178
Boom Extend 180
Slave (Compensation) 182
Tilt 184
Outrigger 186
Rotate Carriage 188
Swing Carriage 189
Fork Shift 190
Axle Steer 191
Hydraulic Components
Hydraulic Pump 192
Master Cylinder Brake Valve 193
Power Steer Motor 194
Steer Select Valve 195
Priority Flow Divider Valve 196
Joystick Relief – Flow Divider 197
WPS Manifold 198
Stabilizing Valve 200
Radio Remote Manifold 201
Main Valve 202
Main Valve – Auxiliary Hydraulics Work Section 204
Continued on next page
Table of Contents 642 / 842 / 844 Telehandler
PRINTED IN U S A 5 913289/BP0208
642 / 842 / 844 Telehandler Table of Contents
Hydraulic Components (continued)
Outrigger Control Valve 206
Controller – Tilt / Frame Level (Standard) 208
Controller – Boom Lift/Extend (Standard) 210
Controller – Outrigger (Option) 212
Controller – Auxiliary Hydraulics 214
Attachments
Carriage Forks 216
Standard Carriage 218
Fork Shift Carriage 220
Rotate Carriage 222
Swing Carriage 224
180O Swing Carriage 226
180O Manual Swing Work Platform 228
Log/Pipe Carriage 230
Truss Boom and Winch 232
Bucket 234
Work Platform 236
Decals
Decal Application and Paint 239
Decal Locations 240
Numerical Index 244
Index 255

DESCRIPTION:

Mustang 642 842 844 Telehandler Parts Manual 913289 – PDF DOWNLOAD

Applies to the following machines:
642 Serial Number 80222 – 80300
842/844 Serial Number 90210 – 90300

Introduction :

The Table of Contents pages list the page locations of various component groups on the machine. When ordering service parts, specify the part number, full description, quantity required, and the unit model and serial number. Model and serial numbers for this unit are stamped on a plate located inside the operator’s station.

• The serial number is also stamped on the top front of the frame. The following reference shows the breakdown of the serial number: “Right” and “left” are determined from a position standing behind the unit and facing the direction of travel.
• Mustang Manufacturing Company reserves the right to make changes or improvements in the design or construction of any part of the unit without incurring the obligation to install such changes on any unit previously delivered.
• Grease fittings and common attaching hardware, such as cotter pins, set screws, woodruff keys, screws and nuts are included in the parts list, indented below the part they are associated with, but NOT illustrated, except where a particular routing or special fastening arrangement must be maintained.
• The hardware listed is for mounting purposes and is NOT included when the part is ordered for replacement.
• Standard attaching hardware torque values are provided on the inside back cover. Unless otherwise specified, all capscrews are Grade 5, cadmium or zinc plated; hexagon nuts for Grade 5 capscrews and bolts are Grade 5.
