Navistar Electrical Systems CV Vocational Series Integration Guide Manual

Description

Navistar Electrical Systems CV Vocational Series Integration Guide Manual –  PDF DOWNLOAD

FILE DETAILS:

Navistar Electrical Systems CV Vocational Series Integration Guide Manual –  PDF DOWNLOAD

Language : English
Pages :100
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Navistar Electrical Systems CV Vocational Series Integration Guide Manual –  PDF DOWNLOAD

Contents
1 Revision Summary Table 3
2 Forward: 3
3 Vehicle Architectures: 6
31 Introduction: 6
32 Multiplexing Architecture: 6
321 High-Speed GMLAN 7
322 Chassis High-Speed GMLAN 8
323 Powertrain High-Speed GMLAN 8
324 Low-Speed GMLAN 8
325 Media Oriented Systems Transport (MOST) 8
326 Local Interconnect Network (LIN) 9
327 GateWay Modules 10
33 Data Link Connector (DLC) 10
4 Standard Electrical Offerings: 11
41 Typical Dash Layout: 11
42 Lights ON with Wipers: 12
43 Power Outlets 12
44 Seat Belt Reminder Light 12
5 Power Take Off (PTO) 13
51 Power Take Off (PTO) & Engine Speed Controls (Sales Feature Code 12WGG) 13
52 Power Take-Off (PTO) – Quick Start Reference 13
53 Factory PTO Settings 15
54 Primary PTO Operating Modes 18
55 Preset PTO Operating Modes and Programming 19
551 Preset PTO – In-cab Operation: Enable Conditions [factory default programming] 19
552 Preset PTO – Remote Operation: Enable Conditions 20
553 Preset PTO – Remote Operation with In-Cab Engage: Enable Conditions 21
56 Variable PTO Operating Modes and Programming 22
561 Variable PTO – In-cab operation: Enable Conditions 22
562 Variable PTO – Remote Operation: Enable Conditions 22
563 Variable PTO – Remote Operation with In-Cab Engage: Enable conditions 23
57 Diesel Particulate Filter [DPF] Cleaning during Stationary PTO Operation 25
58 Mobile PTO Operating Modes and Programming 26
581 Mobile PTO – in-cab operation only: Enable Conditions 26
59 OSIM PTO (Operator Selectable In-Cab Mode) 27
591 OSIM PTO – Preset [Stationary] Operation: Enable Conditions 27
592 OSIM PTO – Variable [Stationary] Operation: Enable Conditions 27
593 OSIM PTO – Mobile Operation: Enable Conditions 27
510 PTO System Disengage Conditions 28
5101 Stationary Modes [preset or variable] – in-cab control 28
5102 Stationary Modes [preset or variable] – remote control [with or without in-cab engage] 29
5103 Mobile Mode 30
511 Prolonged or Extended PTO Operation 31
5111 Diesel Particulate Filter [DPF] Cleaning during Stationary PTO Operation 31
512 PTO Operational Speed Control 32
5121 [Variable] PTO operational speed control provides the following functions: 32
5122 In-cab Cruise Res + Switch (or Remote PTO Tap Up switch) 32
513 Driver Information Center (DIC) Warnings Messages 36
514 Appendix: PTO, Remote Engine Speed Control, and General Safety Recommendations 37
6 Fast Idle Control – Engine Speed Control L/PTO 42
61 To obtain Fast Idle capability you must order the following options: 42
Required Initial Conditions 42
62 Enable (Turn ON) Fast Idle 43
63 Preset Fast Idle 43
64 Adding Fast Idle (UF3) 43
7 Truck Equipment Manufacture (TEM) Options 44
71 Auxiliary Switches / Relay outputs: 44
711 International Factory Feature 08XJP – Switch, Auxiliary, 4 Switches with 30-Amp fuses (Same as GM feature RPO 9L7) 44
712 International Factory Feature 08XLS – Switch, Auxiliary, 6 Switches with 20-Amp fuses, Accessory Controlled, with Switches in Headliner (Same as GM feature RPO UEH) 50
713 International Factory Feature 08XJG – Fog Lights, Halogen Rectangular (Same as GM feature RPO T3U) 53
714 International Factory Feature 08WTT – Auxiliary Switch for Worklight (Same as GM feature RPO UEH) 54
715 International Factory Feature 08XKS – Auxiliary Switch for Roof Beacon/Worklight (Same as GM feature RPO TRW) 55
72 Body Builder Wiring and Harness 57
721 International Factory Feature 08TUM – Auxiliary Harness – Y-Harness for Plow Applications (Same as GM feature RPO UNL) 57
722 Body Builder Wiring – Factory Feature 08HXV – Back of Cab (Same as GM feature RPO 5DX) 58
723 Body Builder Wiring – Factory Feature 08HXU – Rear of Frame (Same as GM feature RPO 5DY) 60
73 Stop, Turn, Tail-lights and Wiring 62
731 Stop, Turn, Tail-lights – Factory Feature 08TUL (Same as GM feature RPO TR1) 62
732 Stop, Turn, Tail Lights – Factory Feature 08TUK (Same as GM feature RPO UGE) 63
733 Stop, Turn, Tail-lights – Factory Feature 08TKD 64
734 Tail Light Wiring Modified – Factory Feature 08NAA 64
74 Trailer Connections and Controls 65
741 Trailer Connection Socket – Factory Feature 08TRA (Same as GM feature RPO UY7) 65
742 Trailer Brake Control, Integrated – Factory Feature 08HBW (Same as GM feature RPO JL1) 67
75 Back-Up Alarm Electric 102 dBa – Factory Feature 08THB (Same as GM feature RPO UZF) 68
76 Power Inverter – Factory Feature 08XJX – (Same as GM feature RPO KI4) 69
8 Auxiliary Battery Connections 69
81 Repair/Recommendation: 70
82 Additional Information: 70
821 Positive Cable Recommendation 70
83 Jump Start Stud – Factory Feature 08WBW – (Same as GM feature RPO BTN) 73
9 Rearview Camera Installation 74
91 Mounting the Camera 74
92 Camera Installation Guidelines 74
93 Camera System, Rear View – Factory Feature 08RNY – (Same as GM feature UVC) 76
10 Infor – Radio Telephone/Mobile radio (Transceiver) Installation and troubleshooting Guidelines 77
101 Transceiver Location 78
102 Antenna Installation 78
103 Antenna Cable Routing 79
104 Antenna Tuning 79
105 Radio Wiring and Connection Locations 79
106 Radio Wire Routing 80
107 Troubleshooting 80
11 Gauge and Fault Code Display 83
111 Base Gauge Cluster: 83
112 Premium Gauge Cluster: 84
12 Relocation of electrical Components/Devices-Best Practices/Recommendations 84
121 Under-hood/Vehicle: 84
122 Under-dash: 85
123 Doors: 85
124 Under Seats: 85
125 Rear Stowage Areas: 85
126 General Recommendation: 85
13 Appendix – General Electrical Section: 85
131 Color Code System for International® Truck Wiring: 86
132 Recommended Circuit Protection: 86
133 Electrical Components Commonly Used by Equipment Installers: 87
134 Wire Splicing and Termination – Standard Terminals and Splices: 88
135 HIGH VOLTAGE CIRCUITS (GREATER THAN 50 VOLTS) ON INTERNATIONAL TRUCKS AND BUSES: 95
