New Holland D180C Crawler Dozers Service Repair Manual 71114549 – PDF DOWNLOAD

Description

New Holland D180C Crawler Dozers Service Repair Manual

FILE DETAILS:

New Holland D180C Crawler Dozers Service Repair Manual

Language : English
Pages : 1693
Downloadable : YES
Format : PDF
Part No:71114549

DESCRIPTION:

New Holland D180C Crawler Dozers Service Repair Manual

Basic instructions – Important notice regarding equipment servicing:

All repair and maintenance work listed in this manual must be carried out only by qualified dealership personnel, strictly complying with the instructions given, and using, whenever possible, the special tools. Anyone who performs repair and maintenance operations without complying with the procedures provided herein shall be responsible for any subsequent damages.

• The manufacturer and all the organizations of its distribution chain, including – without limitation – national, regional, or local dealers, reject any responsibility for damages caused by parts and/or components not approved by the manufacturer, including those used for the servicing or repair of the product manufactured or marketed by the manufacturer.
• In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer. The information in this manual is up-to-date at the date of the publication. It is the policy of the manufacturer for continuous improvement.
• Some information could not be updated due to modifications of a technical or commercial type, or changes to the laws and regulations of different countries. In case of questions, refer to your NEW HOLLAND CONSTRUCTION Sales and Service Networks.

Safety rules – Ecology and the environment:

• Soil, air, and water quality is important for all industries and life in general. When legislation does not yet rule the treatment of some of the substances that advanced technology requires, sound judgment should govern the use and disposal of products of a chemical and petrochemical nature.
• Familiarize yourself with the relative legislation applicable to your country, and make sure that you understand this legislation. Where no legislation exists, obtain information from suppliers of oils, filters, batteries, fuels, anti-freeze, cleaning agents, etc., with regard to the effect of these substances on man and nature and how to safely store, use, and dispose of these substances.

Helpful hints:
• Avoid the use of cans or other inappropriate pressurized fuel delivery systems to fill tanks. Such delivery systems may cause considerable spillage.
• In general, avoid skin contact with all fuels, oils, acids, solvents, etc. Most of these products contain substances that may be harmful to your health.
• Modern oils contain additives. Do not burn contaminated fuels and or waste oils in ordinary heating systems.
• Avoid spillage when you drain fluids such as used engine coolant mixtures, engine oil, hydraulic fluid, brake fluid, etc. Do not mix drained brake fluids or fuels with lubricants. Store all drained fluids safely until you can dispose of the fluids in a proper way that complies with all local legislation and available resources.
• Do not allow coolant mixtures to get into the soil. Collect and dispose of coolant mixtures properly.
• The air-conditioning system contains gases that should not be released into the atmosphere. Consult an air-conditioning specialist or use a special extractor to recharge the system properly.
• Repair any leaks or defects in the engine cooling system or hydraulic system immediately.
• Do not increase the pressure in a pressurized circuit as this may lead to a component failure.
• Protect hoses during welding. Penetrating weld splatter may burn a hole or weaken hoses, allowing the loss of oils, coolant, etc.

TABLE OF CONTENTS:

New Holland D180C Crawler Dozers Service Repair Manual

INTRODUCTION
Engine 10
[10001] Engine and crankcase 101
[10216] Fuel tanks102
[10202] Air cleaners and lines 103
[10250] Turbocharger and lines 104
[10254] Intake and exhaust manifolds and muffler 105
[10400] Engine cooling system 106
[10414] Fan and drive 107
[10310] Aftercooler 108
[10304] Engine lubrication system 109
Hydrostatic drive 29
[29218] Pump and motor components 291
Brakes and controls 33
[33110] Parking brake or parking lock331
[33202] Hydraulic service brakes332
Hydraulic systems 35
[35300] Reservoir, cooler, and filters 351
[35104] Fixed displacement pump 352
[35106] Variable displacement pump 353
[35105] Charge pump 354
[35359] Main control valve 355
[35741] Dozer blade cylinders 356
[35752] Hydraulic fan drive cooling system 357
[35000] Hydraulic systems 358
Frames and ballasting 39
71114549 16/03/2015
[39100] Frame 391
Tracks and track suspension 48
[48134] Track tension units 481
[48140] Dropbox and final drive 482
Cab climate control 50
[50100] Heating 501
[50104] Ventilation502
Electrical systems 55
[55000] Electrical system 551
[55011] Fuel tank system 552
[55014] Engine intake and exhaust system 553
[55015] Engine control system 554
[55030] Service brake electrical system 555
[55050] Heating, Ventilation, and Air-Conditioning (HVAC) control system 556
[55100] Harnesses and connectors 557
[55201] Engine starting system 558
[55202] Cold start aid 559
[55301] Alternator 5510
[55302] Battery 5511
[55512] Cab controls5512
[55518] Wiper and washer system 5513
[55DTC] FAULT CODES 5514
Dozer blade and arm 86
[86110] Dozer blade 861
Tools 89
[89128] Ripper assembly 891
Platform, cab, bodywork, and decals 90
[90150] Cab 901
71114549 16/03/2015
[90114] Operator protections 902
[90100] Engine hood and panels903
