New Holland E260CSR Crawler Excavator Service Manual 48090747 – PDF DOWNLOAD

Description

New Holland E260CSR Crawler Excavator Service Manual

FILE DETAILS:

New Holland E260CSR Crawler Excavator Service Manual

Format: PDF
Language: English
Pages: 1468
Number: 48090747 (february 2017)
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

DESCRIPTION:

New Holland E260CSR Crawler Excavator Service Manual

INTRODUCTION:
TO THE READER:

• This manual is written for an experienced technician to provide technical information needed to maintain and repair this machine.
• Be sure to thoroughly read this manual for correct information concerning the service procedures.

ADDITIONAL REFERENCES
• Please refer to the materials listed below in addition to this service manual:
– Operator’s Manual
– Service Parts Catalogue

COMPLETE SERVICE MANUAL :

• The Service Manual consists of one volume: – E260CSR Service Manual for “Crawler Excavators The Service Manual for “Crawler Excavators” contains the necessary technical information to carry out maintenance and repair operations on the machine, the necessary tools to carry out maintenance operations, the information on service standards, the procedures for removal, installation, disassembly and reassembly.

SAFETY PRECAUTIONS:

The serviceman or mechanic may be unfamiliar with many of the systems on this machine. This makes it important to use caution when performing service work. A knowledge of the system and or components is important before the removal or disassembly of any component. Because of the size of some of the machine components, the serviceman or mechanic should check the weights noted in this manual. Use proper lifting procedures when removing any components. Weight of components table is shown in the section ;
SPECIFICATIONS.
The following is a list of basic precautions that must always be observed.
(1) Read and understand all Warning plates and decal on the machine before Operating, Maintaining or Repairing this machine.
(2) Always wear protective glasses and protective shoes when working around machines. In particular, wear protective glasses when using hammers, punches or drifts on any part of the machine or attachments.Use welders gloves, hood/goggles, apron and the protective clothing appropriate to the welding job being performed. Do not wear loose fitting or torn clothing. Remove all rings from fingers, loose jewelry, confine long hair and loose clothing before working on this machinery.
(3) Disconnect the battery and hang a “Do Not Operate”tag in the Operators Compartment. Remove ignition keys.
(4) If possible, make all repairs with the machine parked on a firm level surface. Block the machine so it does not roll while working on or under the machine. Hang a “Do Not Operate” tag in the Operators Compartment.
(5) Do not work on any machine that is supported only by lift, jacks or a hoist. Always use blocks or jack stands, capable of supporting the machine, before performing any disassembly. Do not operate this machine unless you have read and understand the instructions in the OPERATOR’S MANUAL. Improper machine operation is dangerous and could result in injury or death.
(6) Relieve all pressure in air, oil or water systems before any lines, fittings or related items are disconnected or removed. Always make sure all raised components are blocked correctly and be alert for possible pressure when disconnecting any device from a system that utilizes pressure.
(7) Lower the bucket, dozer, or other attachments to the ground before performing any work on the machine. If this cannot be done, make sure the bucket, dozer, ripper or other attachment is  blocked correctly to prevent it from dropping unexpectedly.
(8) Use steps and grab handles when mounting or dismounting a machine. Clean any mud or debris from steps, walkways or work platforms before using. Always face to the machine when using steps, ladders and walkways. When it is not possible to use the designed access system, provide ladders, scaffolds, or work platforms to perform safe repair operations.
(9) To avoid back injury, use a hoist when lifting components which weigh 20kg (45lbs) or more. Make sure all chains, hooks, slings, etc., are in good condition and are the correct capacity. Be sure hooks are positioned correctly. Lifting eyes are not to be side loaded during a lifting operation.
(10)To avoid burns, be alert for hot parts on machines which have just been stopped and hot fluids in lines, tubes and compartments.
(11)Be careful when removing cover plates. Gradually back off the last two capscrews or nuts located at opposite ends of the cover or device and carefully pry cover loose to relieve any spring or other pressure, before removing the last two capscrews or nuts completely.
(12)Be careful when removing filler caps, breathers and plugs on the machine. Hold a rag over the cap or plug to prevent being sprayed or splashed by liquids under pressure. The danger is even greater if the machine has just been stopped because fluids can be hot.

TABLE OF CONTENTS:

New Holland E260CSR Crawler Excavator Service Manual

• 1. OUTLINE
• 2. SPECIFICATIONS
• 3. ATTACHMENT DIMENSIONS
• 11. TOOLS
• 12. STANDARD MAINTENANCE TIN
• 13. MAINTENANCE STANDARD AN PROCEDURE
• 21. MECHATRO CONTROL SYSTEM
• 22. HYDRAULIC SYSTEM
• 23. ELECTRIC SYSTEM
• 24. COMPONENTS SYSTEM
• 25. AIR-CONDITIONER SYSTEM
• 31. DISASSEMBLING AND ASSEMBl
• 32. ATTACHMENTS
• 33. UPPER SLEWING STRUCTURE
• 34. TRAVEL SYSTEM
• 46. TROUBLE SHOOTING(BY ERROR
• 47. TROUBLESHOOTING (BY TROUB
• 51. ENGINE

NEW HOLLAND E260CSR CRAWLER EXCAVATOR SERVICE MANUAL 48090747 – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

PLEASE NOTE:

• This is the same manual used by the DEALERSHIPS to SERVICE your vehicle.
• The manual can be all yours – Once payment is complete, you will be taken to the download page from where you can download the manual. All in 2-5 minutes time!!
• Need any other service / repair / parts manual, please feel free to contact us at heydownloadss @gmail.com . We may surprise you with a nice offer
