New Holland H9870, H9880 Service Repair Manual – PDF DOWNLOAD

Description

New Holland H9870, H9880 Service Repair Manual

FILE DETAILS:

New Holland H9870, H9880 Service Repair Manual

Size: 78 MB
Format: PDF
Language: English
Number of Folder: 7
Brand: New Holland
Type of document: Service Manual
Model: H8060, H8080 Bale Wagon
Part No: 84175490-84175496

DESCRIPTION:

New Holland H9870, H9880 Service Repair Manual

INTRODUCTION:

The hydraulic system consists of two separate systems: a dual open-center system, and a closed-center system. Each system has its own pump, with oil supplied from a common reservoir. The open-center system uses a fixed-displacement double gear pump, making it effectively two subsystems driven by the same pump. The closed-center system uses a variable-displacement piston pump that is both flow- and pressure-compensated.

• Both pumps draw their supply through inline filter screens from the common hydraulic reservoir. All functions driven by the dual gear pump are controlled through a valve manifold utilizing solenoid-operated valves. Similarly. all functions supplied by the piston pump are controlled through a separate solenoid valve manifold.
• Filtered return lines from both manifolds pass through a return oil filter to the common hydraulic reservoir. The closed-center system includes an unfiltered return line. providing low-pressure return for some function.

TABLE OF CONTENTS:

New Holland H9870, H9880 Service Repair Manual

• DISTRIBUTION SYSTEMS — A
• POWER PRODUCTION — B
• POWER TRAIN — C
• TRAVELLING — D
• BODY AND STRUCTURE — E
• CROP PROCESSING — K

NEW HOLLAND H9870, H9880 SERVICE REPAIR MANUAL – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

PLEASE NOTE:

• This is the SAME exact manual used by your dealers to fix your vehicle.
• The same can be yours in the next 2-3 mins as you will be directed to the download page immediately after paying for the manual.
• Any queries / doubts regarding your purchase, please feel free to contact [email protected]
