New Holland HW305 HW305S HW325 Self Propelled Windrower Service Manual – PDF DOWNLOAD

Description

New Holland HW305 HW305S HW325 Self Propelled Windrower Service Manual

FILE DETAILS:

New Holland HW305 HW305S HW325 Self Propelled Windrower Service Manual

Language : English
Pages : 2030
Downloadable : YES
Format : PDF
Part No : 87576230

DESCRIPTION:

New Holland HW305 HW305S HW325 Self Propelled Windrower Service Manual

INTRODUCTION:

The models HW305, HW305S, and HW325 windrowers have been designed to harvest a variety of crops. In addition to the base unit, a variety of header widths are available for the windrowers. On this equipment, left and right are determined by standing behind the unit, looking in the direction of travel.

• This service manual provides the technical information to properly service and maintain the Model HW305, HW305S, and the HW325 windrowers. Use it in conjunction with the operators manual which is supplied with the windrower.
• Keep both manuals available for ready reference: 10041062 1 The HW305, HW305S, and HW325 are similar machines, with major difference being engine horsepower.
• This manual details the easiest and least timing-consuming removal, disassembly and reassembly procedures. Modifying any of these procedures is not recommended.
• New Holland windrowers are designed with emphasis on operator safety and protection. However, careless and negligent operation can still result in serious injury to persons or damage to property. Be sure to read and follow all safety instructions in the manual.

SAFETY PRECAUTIONARY STATEMENTS:

A careful operator is the best operator. Most accidents can be avoided by observing certain precautions. To help prevent accidents, read the following precautions before operating this equipment. Equipment should be operated only by those who are responsible and instructed to do so.
Carefully review the procedures given in thismanual with all operators. It is important that all operators be familiar with and follow safety precautions.
1. To stop, return the MFH lever to neutral, engage the parking brake, center the steering wheel to the locked position, and stop the
engine before leaving the seat.
2. When descending steep grades on the road and when in the field, always place the switch into the field range position.
3. When going down a steep grade, pull theMFH lever back toward neutral to slow ground speed.
4. With the parking brake engaged, the steering wheel centered, and the hydrostatic MFH lever in the neutral slot, the neutral lock will engage pulling the lever to the right. The parking brake must be engaged before the engine will start.
5. The neutral lock should always be engaged when the windrower is stopped.
6. The steering wheel must be centered to keep thewindrower fromturning evenwith theMFH lever in neutral. When moving forward, the windrower turns the direction the steering wheel is turned. When moving in reverse, the windrower turns opposite the direction the wheel is turned. In reverse, hold the steering wheel at the back of the rim and move your hand in the direction you want to go.

TABLE OF CONTENTS:

New Holland HW305 HW305S HW325 Self Propelled Windrower Service Manual

SECTION 00 – GENERAL INFORMATION 2
SECTION 10 – ENGINE 3
SECTION 25 – FRONT MECHANICAL DRIVE 11
SECTION 29 – HYDROSTATIC TRANSMISSION 12
SECTION 33 – BRAKES AND CONTROLS 16
SECTION 35 – HYDRAULIC SYSTEMS 17
SECTION 44 – REAR AXLE 22
SECTION 50 – CLIMATE CONTROL 24
SECTION 55 – ELECTRICAL SYSTEMS 30
SECTION 58 – HEADER ATTACHMENTS 51
SECTION 88 – OPTIONAL EQUIPMENT 56
SECTION 90 – PLATFORM, CAB AND DECALS 60
