New Holland MH2.6 MH3.6 Excavator Service Repair Manual – PDF DOWNLOAD

Description

New Holland MH2.6 MH3.6 Excavator Service Repair Manual

FILE DETAILS:

New Holland MH2.6 MH3.6 Excavator Service Repair Manual

Language : English
Pages : 898
Downloadable : YES
Format : PDF
Size : 64.8 MB
Print No. 604.13.477

DESCRIPTION:

New Holland MH2.6 MH3.6 Excavator Service Repair Manual

SAFETY PRECAUTIONS:

Read the Operation and Maintenance Instruction Man- pal carefully before starting. operating. maintaining. fuelling or servicing the machine. Carefully read the explanation to each and all safety signs in the special section of this Manual before starting. operating. maintaining. fuelling or servicing the machine. Machine-mounted safety plates are colour coded yel- low with black borders when they refer to points where special ATTENTION must be paid and failure to observe them may cause a serious DANGER to the integrity of machine operators.

• They are white with red borders and black lettering when they refer to a FORBIDDEN practice. It is fundamental that all machine operators know very well the meaning of each safety plate as this consid- erably decreases operating hazards and accidents Do not allow unauthorised personnel to operate or service this machine. Do not wear rings. wrist watches. jewellery. loose or hanging garments. such as ties. torn clothing. scarves. unbuttoned or unzipped jackets that can get caught in moving parts.
• Wear certified safety clothes such as: hard hat. no—slip footwear. heavy gloves. ear protection. safety glasses. reflector vests. respirators every time the job requires it. Ask your employer about safety regulations in force and protective equipment. Always keep the operator’s compartment. step plates. grab-rails and handles clean and clear of foreign ob- jects. oil. grease. mud or snow to minimise the dan- ger of slipping or stumbling. Remove mud or grease from your shoes before operating the machine.
• Do not jump on or off the machine. Always keep both hands and one foot. or both feet and one hand in con- tact with steps andlor grab rails. Do not use controls or hoses as hand holds. Hoses and controls are movable parts and do not provide solid support. Besides. controls may be inadvertently moved and cause unexpected movement of the ma- chine or its attachments. Never operate the machine or its attachments from any position other than sitting in the driver’s seat.
• Keep head, body. limbs. hands and feet inside the op- erator’s compartment at all times to reduce exposure to external hazards. Be careful of possible slippery conditions of the steps and hand rails as well as of the ground around the machine. Wear protective boots or shoes with the soles made of highly no-slip rubber. Do not leave the machine until it has come to a com- plete stop. Always check height. width and weight limitations which may be encountered in the working site and en- sure the machine does not exceed them.

TABLE OF CONTENTS:

New Holland MH2.6 MH3.6 Excavator Service Repair Manual

SECTION 1 – MAIN OPERATING RULES
Sections Index
Introduction
Features of the manual
SECTION 2 -SAFETY PRECAUTIONS
Safety precautions
Safety labels
SECTION 3 – FEATURES AND DATA
Foreword
Identification data
Noise levels (2000/14/EC)
Summary plate for maintenance operations
Wheeled excavator main components
Filling chart MHZG
Filling chart MH36
SECTION 4 – SUPERSTRUCTURE
Superstructure
Main frame and counterweight
Power unit
Diesel engine
Radiator
Hydraulic pumps
Air cleaner
Exhaust gas silencer
Hydraulic oil tank
Fuel tank
Fuel transfer pump
Hoods and covers
Swinging assy
Main control valve
Slew devlce
Control lever
Control pedal
Steering unit
Swiveljolnt
Brake pedal valve
Accumulators
Pressure switches
Solenold valves
SECTION 5 – UNDERCARRIAGE
Slewing bearing
Lower frame
Travel assy
Wheels and tyres
Tyres
Blade
Lateral stabilizers
