New Holland Tractor CX8070,CX8080,CX8090 Combine Service Manual – PDF DOWNLOAD
Original price was: $57.95.$38.95Current price is: $38.95.
New Holland Tractor CX8070,CX8080,CX8090 Combine Service Manual
Description
New Holland Tractor CX8070,CX8080,CX8090 Combine Service Manual
FILE DETAILS:
New Holland Tractor CX8070,CX8080,CX8090 Combine Service ManualΒ
Size: 67 MB
Format: PDF
Language: English
Number of Pages: 3534
Brand: New Holland
Type of machine: Tractor
Type of document: Service Manual
Model: CX8070,CX8080,CX8090 Combine
DESCRIPTION:
New Holland Tractor CX8070,CX8080,CX8090 Combine Service ManualΒ
Foreword:
IMPORTANT INFORMATION:
- All repair and maintenance works listed in this manual must be carried out only by staff belonging to the NEW HOLLAND Service network, strictly complying with the instructions given and using, whenever required, the special tools. Anyone who carries out the above operations without complying with the prescriptions shall be responsible for the subsequent damages.
- The manufacturer and all the organizations of its distribution chain, including without limitation national, regional or local dealers, reject any responsibility for damages due to the anomalous behavior of parts and/or components not approved by the manufacturer himself, including those used for the servicing or repair of the product manufactured or marketed by the Manufacturer.
- In any case, no warranty is given or attributed on the product manufactured or marketed by the Manufacturer in case of damages due to an anomalous behavior of parts and/or components not approved by the Manufacturer. No reproduction, though partial of text and illustrations allowed.
Basic instructions:
SHIMMING:
For each adjustment operation, select adjusting shims and measure individually using a micrometer, then add up the recorded values. Do not rely on measuring the entire shimming set, which may be incorrect, or the rated value indicated on each shim.
ROTATING SHAFT SEALS:
For correct rotating shaft seal installation, proceed as follows:
β’ before assembly, allow the seal to soak in the oil it will be sealing for at least thirty minutes
β’ thoroughly clean the shaft and check that the working surface on the shaft is not damaged
β’ position the sealing lip facing the fluidΝΎ with hydrodynamic lips, take into consideration the shaft rotation direction and position the grooves so that they will deviate the fluid towards the inner side of the seal
β’ coat the sealing lip with a thin layer of lubricant (use oil rather than grease) and fill the gap between the sealing lip and the dust lip on double lip seals with grease
β’ insert the seal in its seat and press down using a flat punch, do not tap the seal with a hammer or mallet
β’ whilst inserting the seal, check that it is perpendicular to the seatΝΎ once settled, make sure that it makes contact with the thrust element, if required
β’ to prevent damaging the seal lip on the shaft, position a protective guard during installation operations
O-RING SEALS:
Lubricate the O-RING seals before inserting them in the seats, this will prevent them from overturning and twisting, which would jeopardise sealing efficiency.
TABLE OF CONTENTS:
New Holland Tractor CX8070,CX8080,CX8090 Combine Service ManualΒ
COMPLETE CONTENTS.......................... 1 INTRODUCTION............................... 91 SECTION A - DISTRIBUTION SYSTEMS........... 103 SECTION B - POWER PRODUCTION...............1977 SECTION C - POWER TRAIN....................2303 SECTION D - TRAVELLING.....................2531 SECTION E - BODY AND STRUCTURE.............2723 SECTION K - CROP PROCESSING................2957 87690999-Linked pdf.pdf.................... 0 TABLE OF CONTENTS ..................... 0 DISTRIBUTION SYSTEMS A................. 209 87691000-Linked pdf.pdf.................... 0 TABLE OF CONTENTS ..................... 0 DISTRIBUTION SYSTEMS - A .............. 561 87691001-Linked pdf.pdf.................... 0 Contents .............................. 0 DISTRIBUTION SYSTEMS A................. 923 87691002-Linked pdf.pdf.................... 0 Table of Contents ..................... 0 DISTRIBUTION SYSTEMS -FAULT CODES .....1011 87691003-Linked pdf.pdf.................... 0 Table of Contents ..................... 0 DISTRIBUTION SYSTEMS - FAULT CODES .... 0 87691004-Linked pdf.pdf.................... 0 Table of Contents ..................... 0 DISTRIBUTION SYSTEMS - FAULT CODES .... 0 87691005-Linked pdf.pdf.................... 0 CONTENTS .............................. 0 DISTRIBUTION SYSTEMS...................1693 87691006-Linked pdf.pdf.................... 0 Table of Contents .................... 0 POWER PRODUCTION.......................1977 87691007-Linked pdf.pdf.................... 0 TABLE OF CONTENTS ..................... 0 Power Train ...........................2303 87691008-Linked pdf.pdf.................... 0 TABLE OF CONTENTS ..................... 0 TRAVELLING ............................2531 87691009-Linked pdf.pdf.................... 0 TABLE OF CONTENTS ..................... 0 BODY AND STRUCTURE E...................2723 87691010-Linked pdf.pdf.................... 0 Table of Contents ..................... 0 Crop Processing .......................2957 87691011-Linked pdf.pdf.................... 0 Table of Contents ..................... 0 CROP PROCESSING K......................3201
NEW HOLLAND TRACTOR CX8070,CX8080,CX8090 COMBINE SERVICE MANUAL – PDF DOWNLOAD:
IMAGES PREVIEW OF THE MANUAL:
Β
PLEASE NOTE:
- This is not a physical manual but a digital manual – meaning no physical copy will be couriered to you. The manual can be yours in the next 2 mins as once you make the payment, you will be directed to the download page IMMEDIATELY.
- This is the same manual used by the dealers inorder to diagnose your vehicle of its faults.
- Require some other service manual or have any queries: please WRITE to us atΒ [email protected]
