New Holland Tractor TC35 TC35D TC40 TC40D TC45 TC45D Service Repair Manual (86618104) – PDF Download

Description

New Holland Tractor TC35 TC35D TC40 TC40D TC45 TC45D Service Repair Manual (86618104)

File Details:

New Holland Tractor TC35, TC35D, TC40, TC40D, TC45, TC45D Repair Manual_86618104
Size: 31.9 MB
Format: PDF
Language: English
Number of Pages: 1012 pages
Brand: New Holland
Type of machine: Tractor
Type of document: Repair Manual
Model: TC35, TC35D, TC40, TC40D, TC45, TC45D
Part No: 86618104

NEW HOLLAND TRACTOR TC35 TC35D TC40 TC40D TC45 TC45D SERVICE REPAIR MANUAL (86618104) – PDF DOWNLOAD:

Image Preview:

Description:

New Holland Tractor TC35 TC35D TC40 TC40D TC45 TC45D Service Repair Manual (86618104)

Technical Information:

GENERAL
The TC35, TC35D, TC40, TC40D, TC45 and TC45D tractors have been built using metric hardware.
NOTE: Be sure to use the hardware specified when using tapped holes, as trying to install ametric bolt in an inch thread, or an inch bolt in a metric thread, will damage the thread.
Certain hardware must be tightened to specific torque specifications. If specific torque specifications are not noted, tighten the hardware to the standard torque chart specification listed in this manual.
PLATING
Hardware used on New Holland balers is plated with zinc chromate (gold color). Gold colored hardware has different torquing requirements from unplated or zinc plated (silver color) hardware because of th  difference in the coefficient of friction of the plating material. The torque charts in this manual list the correct specifications for gold, silver, and unplated bolts.
NUT TIGHTENING
Whenever possible, the nut should be tightened, not the head of the bolt. When tightening using the bolt head, the clamp load can be lost because some of the torque applied twists the bolt instead of tensioning (stretching) it. The tension on the bolt is what holds the joint together. Approximately 90% of the torque applied during assembly goes to overcoming friction between the parts. The other 10% is used to tension (stretch) the bolt. After assembly, the frictional forces disappear,  which is the basis for the saying “If it does not fail during assembly, it will not fail in service.” The bolt may later fail due to other factors, but not from being over tightened.
LOCKNUTS
Most locknuts are coated with a special lubricant that is dry to the touch. Anytime a locknut is used, a lower than normal torque is required. Refer to the torque charts in this manual for specific values.
JAM NUTS
When using a jam nut to lock a regular nut, the jam nut should be installed first and tightened to one half the recommended torque, then held in place while installing a regular nut to the recommended torque.
THREAD LUBRICATION
The addition of antiseize compound, Molykote, oil, graphite, or any other lubricant to a bolt decreases the friction between it and a nut. This makes it necessary to reduce the recommended torque to prevent over tensioning of the bolt. When using the torque charts in this manual, decrease the value by 20% whenever a lubricant is used

Table Of Contents:

New Holland Tractor TC35 TC35D TC40 TC40D TC45 TC45D Service Repair Manual (86618104)

Table of Contents ............................  1
General Information .......................... 17
Engine ....................................... 63
Clutch .......................................211
Transmiddion .................................239
Driveline ....................................309
4WD Front Axle, Supersteer and Sensitrack ....343
Differential, Rear Axle ......................399
Hydrostatic Transmission .....................431
Power Take-Off (PTO) Systems .................511
Brakes .......................................585
Hydraulic System .............................597
Steering .....................................671
2WD Front Axle ...............................731
Electrical ...................................745
Platform .....................................961
