New Holland Tractor TD60 TD70 TD80 TD90 TD95 Straddle Service Manual 48047633 – PDF DOWNLOAD

Description

New Holland Tractor TD60 TD70 TD80 TD90 TD95 Straddle Service Manual

FILE DETAILS:

New Holland Tractor TD60 TD70 TD80 TD90 TD95 Straddle Service Manual

Size: 51.8 MB
Format: PDF
Language: English
Number of Pages : 587 pages
Brand: New Holland
Type of document: Service Manual
Model: TD60 Straddle, TD70 Straddle, TD80 Straddle, TD90 Straddle, TD95 Straddle
Part No: 48047633

DESCRIPTION:

New Holland Tractor TD60 TD70 TD80 TD90 TD95 Straddle Service Manual

GENERAL INSTRUCTIONS:

IMPORTANT NOTICE:
All maintenance and repair operations described in this manual should be carried out exclusively by the authorized workshops. All instructions detailed should be carefully observed and special equipment indicated should be used if necessary. Everyone who carries out service operations described without carefully observing these prescriptions will be directly responsible of deriving damages.

SHIMMING:

At each adjustment, select adjusting shims, measure them individually using a micrometer and then sum up recorded values. Do not rely on measuring the whole shimming set, which may be incorrect, or on the rated value indicated for each shim.

ROTATING SHAFT SEALS:
To correctly install rotating shaft seals, observe the following instructions:
• Let the seal soak into the same oil as it will seal for at least half an hour before mounting;
• Thoroughly clean the shaft and ensure that the shaft working surface is not damaged;
• Place the sealing lip towards the fluid. In case of a hydrodynamic lip, consider the shaft rotation direction and orient grooves in order that they deviate the fluid towards the inner side of the seal;
• Coat the sealing lip with a thin layer of lubricant (oil rather than grease) and fill the gap between the sealing lip and the dust lip of double lip seals with grease;
• Insert the seal into its seat and press it down using a flat punch. Do not tap the seal with a hammer or a drift;
• Take care to insert the seal perpendicularly to its seat while you are pressing it. Once the seal is settled, ensure that it contacts the thrust element, if required;
• To prevent damaging the sealing lip against the shaft, place a suitable protection during installation.
O RINGS:
Lubricate the O rings before inserting them into their seats. This will prevent the O rings from roll over and twisting during mounting, which will jeopardize sealing.
SEALERS:
Apply silicone/gasket eliminator over the mating surfaces marked with an X. Before applying the sealer, prepare the surface as follows:
• remove possible scales using a metal brush;
• thoroughly degrease the surfaces using one of the following cleaning agents: trichlorethylene, diesel fuel or a water and soda solution.

TABLE OF CONTENTS:

New Holland Tractor TD60 TD70 TD80 TD90 TD95 Straddle Service Manual

INTRODUCTION
Engine 10
[10 001] Engine and crankcase 10 1
Clutch 18
[18 110] Clutch and components 18 1
Transmission 21
[21 114] Mechanical transmission 21 1
[21 120] Gearbox 21 2
[21 160] Creeper 21 3
Four-Wheel Drive (4WD) system 23
[23 304] Four-Wheel Drive (4WD) gearbox 23 1
Front axle system 25
[25 100] Powered front axle 25 1
[25 102] Front bevel gear set and differential 25 2
[25 108] Final drive hub, steering knuckles, and shafts 25 3
Rear axle system 27
[27 100] Powered rear axle 27 1
[27 106] Rear bevel gear set and differential 27 2
Power Take-Off (PTO) 31
[31 101] Rear mechanical control 31 1
Brakes and controls 33
[33 202] Hydraulic service brakes 33 1
[33 110] Parking brake or parking lock 33 2
[33 220] Trailer brake hydraulic control 33 3
Hydraulic systems 35
[35 204] Remote control valves 35 1
48047633 19/11/2016
[35 100] Main lift system 35 2
Steering 41
[41 101] Steering control 41 1
[41 216] Cylinders 41 2
Wheels 44
[44 511] Front wheels 44 1
Electrical systems 55
[55 100] Harnesses and connectors 55 1
[55 201] Engine starting system 55 2
[55 302] Battery 55 3
[55 408] Warning indicators, alarms, and instruments 55 4
[55 301] Alternator 55 5
Platform, cab, bodywork, and decals 90
[90 150] Cab 90 1
