Nichiyu 60 Series FB10P-30P Electric Lift Truck Service Manual PDF

Description

Nichiyu 60 Series FB10P-30P Electric Lift Truck Service Manual – PDF DOWNLOAD

FILE DETAILS:

Nichiyu 60 Series FB10P-30P Electric Lift Truck Service Manual – PDF DOWNLOAD

Language : English
Pages : 97
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Nichiyu 60 Series FB10P-30P Electric Lift Truck Service Manual – PDF DOWNLOAD

Electric lift trucks 1
General 2
Model name and name plate 3
Model coding system 3
Name plate 4
Position of serial number on frame and componemts 4
Specifications 5
Specifications for standard trucks 5
Specifications for high speed trucks 6
Stability of forklift truck 7
Load center and load chart 7
Before starting to work 8
Motors (drive hydraulic power steering) 9
Removing 10
Construction and constructive parts 10
Drive motor 11
Hydraulic motor 11
Disassembling procedures and cautions 12
Inspection 14
Armature comp 14
Carbon brush, brush holder and spring 15
Assembling procedures 17
Mounting field coli and measuring insulation 17
Mounting brush holder 18
Tightening terminal bolt 18
Inspection of motor ass’y 18
Trouble shooting 20
Electric system 21
Control unit 22
Main constructive parts 22
Removing 28
Removing prodcedure of parts and cautions 29
Inspection 36
Assembling procedures and cautions 40
Mounting 43
Accelerator linkage 47
Constructive parts 47
Feature and construction of accalerator 47
Adjusting procedure 48
Indicator panel 49
Constructive parts and display of LED 49
Disassembling procedure 50
Assembling and cautions 50
Directional switch 51
Removing 51
Disassembling procedure and constructive parts 51
Fuse 52
Removing and cutions on replacement 52
Capacity of fuse 52
Battery and battery plug 53
Inspection of battery 53
Cleaning 55
Inspection of battery plug 55
Trouble shooting 56
Charger (built in type) 57
Removing 57
Inspection 60
Assembling procedure and key point 61
Inspection after assembling 61
Setting timer and charging procedures 64
Selecting the terminal of charging source voltage 66
Trouble shooting 67
Service Data 68
Front Axle 69
Rear Axle (steering) 71
Wheel 73
Steering gear box 74
Brake system 76
Hydraulic system 78
Cylinders 81
Mast ass’y 82
Motor ass’y 84
Electric system 86
FET unit ass’y 86
Contactor ass’y 88
Others 86
Thightening torque of bolts 90
Inspection prior to operation and contents 91
Periodic servicing 92
Lubrication points and recommanded oil 94
Special tool and jiga 95

S.V 06/24
