The BiPAP® System Service Manual provides full factory technical documentation for servicing and maintaining Respironics BiPAP S, S/T, S-D, and S/T-D ventilatory support units.

This manual includes:

• safety warnings and service cautions (Chapter 1)

• system identification and specifications (Chapter 2)

• controls and setup procedures (Chapter 3)

• maintenance schedules and verification steps (Chapter 4)

• troubleshooting flowcharts and test checks (Chapter 5)

• repair and replacement procedures (Chapter 6)

• performance testing and calibration (Chapter 7)

• parts lists and exploded diagrams (Chapter 8)

The Table of Contents shown on pages 3–6 lists all major service sections including maintenance, diagnostics, repair procedures, calibration routines, and required test equipment.

📑 Structured Contents / Bookmarks

Chapter 1 — Warnings, Cautions & Notes

(See pages 8–10)

Includes:

• patient safety precautions

• clinical use disclaimers

• electrical and service guidelines

• respiratory circuit handling

• sterilization & cleaning precautions

Chapter 2 — BiPAP System Overview

(See pages 11–20)

Includes:

• model identification & part numbers (p.12–13)

• detailed system specifications (p.14–15)

• pressure & flow characteristics

• cycling and timing parameters

• electrical requirements and ratings

• operating & storage temperature limits

• system mode descriptions (CPAP / S / S-T / S-D / S-T-D)

• functional operating explanations (p.16–17)

• feature comparison table (p.18)

• system components diagram — Figure 2-1 (p.19)

• system airflow diagram — Figure 2-2 (p.20)

The system component diagram on page 19 illustrates blower, valve, muffler, power supply, and flow transducer layout, while the airflow path diagram on page 20 shows patient-circuit routing.

560311294-b-Pap-St-Service-Manu…

Chapter 3 — Controls & Setup

• front & rear control panel layout

• detachable control panel (DCP)

• setup procedures

• DCP communication connections

Chapter 4 — Maintenance

Includes:

• maintenance schedule

• time-meter recording

• voltage selector switch verification

• fuse checks

• control functions testing

• cleaning procedures

Chapter 5 — Troubleshooting

• troubleshooting charts

• blower system checks

• MCB / BCB board checks

• transformer verification

• temperature guidelines

• wiring diagram

Chapter 6 — Repair & Replacement

Step-by-step factory procedures for:

• blower assembly replacement

• motor controller board

• BTAP & BCB board replacement

• muffler & valve replacement

• power switch modules

• connector harnesses

• fan & rear panel components

• S-D / S-T-D specific components

Chapter 7 — System Adjustment & Final Testing

Includes full calibration workflows:

• test equipment setup

• valve control calibration

• pressure monitor calibration

• flow transducer calibration

• EPAP / IPAP setup & verification

• tidal volume verification (S-D / S-T-D)

• respiratory rate verification

• leak rate testing

• corrective actions

This section contains detailed service test procedures for all models and modes.

Chapter 8 — Parts Lists & Exploded Views

• blower assembly views

• enclosure & foam panel diagrams

• component reference mapping
