Still STED Electric forklift truck Explosion-protected RXS0-10 RXS0-13 RXS0-15 RXS0-16 Workshop Manual

Description

Still STED Electric forklift truck Explosion-protected RXS0-10 RXS0-13 RXS0-15 RXS0-16 Workshop manual – PDF DOWNLOAD

FILE  DETAILS:

Still STED Electric forklift truck Explosion-protected RXS0-10 RXS0-13 RXS0-15 RXS0-16 Workshop manual – PDF DOWNLOAD

Language : English
Pages : 140
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Still STED Electric forklift truck Explosion-protected RXS0-10 RXS0-13 RXS0-15 RXS0-16 Workshop manual – PDF DOWNLOAD

00 Product information
Explosion protection information
General considerations
Personnel qualified to work with explosion protection-related components
Towing the truck safely out of potentially explosive areas
Testing the electrical system
Tyres
Zones and equipment categories for explosion protection
Explosion groups
Temperature classes
Types of spark protection
Explosion protection-specific components on the truck
Nameplate
34 Driver’s compartment
Driver’s compartment
Warning lights related to explosion protection
Driver’s seat
Checking the antistatic varnish layer
46 Wheels and tyres
Wheels
Checking the tyres and measuring leak resistance
Brake temperature and brake wear
56 Display elements
Operating console
Connecting the diagnostic device
60 Electrics/electronics
Electrics/electronics, general
Disconnecting and connecting the battery male connector
Pressure-tight housing – Identification
Opening the pressure-tight housing
Closing the pressure-tight housing
Electronic control unit – Structure
Checking the intrinsic safety PCB
Insulation protection and emergency shutdown
Checking the SD insulation-monitoring PCB -1
Sheet 01 – Revisions -1
Sheet 02 – Index -2
Sheet 03 – Drive units -3
Sheet 04 – Intrinsic safety for mini-lever version -5
Sheet 05 – Intrinsic safety for joystick version -7
Sheet 06 – Intrinsic safety of sensors and switches -9
II 55048011526 [EN]
Testing the MBZ zener barriers
Replacing the electric motors
Making a cable inlet
Repairing the flashing light
Changing the interrupter unit
Repairing headlight EL 150
Repairing light EL 160
Repairing light FL 32
Repairing the working spotlights FL 150
Replacing fuses and electrical components
84 Load support
Fork arms
Checking the fork arms
90 Special equipment/accessories
Miretti spare parts list
Coating on the fork arms
Antistatic paint
Negative battery male connector
Positive battery male connector
Flashing light
Headlight EL 150
Light EL 160
Light FL 32
Tables of cables used
Table of cable inlets used
Annex
X Circuit diagrams
CAT 2G electric circuit diagrams
Sheet 07 – Intrinsic safety of zener barriers -11
Sheet 08 – Intrinsic safety of zener barriers -13
Sheet 09 – Scope of intrinsic safety (sensors) -15
Sheet 10 – Scope of intrinsic safety (sensors) -17
Sheet 11 – Intrinsic safety of the display and operating unit and E-hydraulics -19
Sheet 12 – CAN connection and diagnostic connector -21
Sheet 13 – Auxiliary equipment -23
Sheet 14 – CAN-Power-Port 2B (lighting) -25
Sheet 15 – Relay-Power-Port (lighting) -27
Sheet 16 – Fuses -29
Sheet 17 – Relay power port (RPP) -31
Sheet 18 – Additional electrical installation and 5th hydraulic function (variant) -33
Sheet 20-27 – Parts list -34
Sheet 28 – Cable routing -38
Sheet 32 – Cables BB1, BB2 -40
Sheet 33 – Cables BE1, BE2 -41
Sheet 34 – Cables W1B1, W2B -43
Sheet 35 – Cable W3B01, WABEII -44
Sheet 36 – Cable WD1, WD2 -45
Sheet 37 – Cable WD3 -47
Sheet 38-54 – Connectors -48
