Still STED OM Series XNA XNAac – Generation 3 48V Workshop Manual – PDF DOWNLOAD

Description

Still STED OM Series XNA XNAac – Generation 3 48V Workshop Manual – PDF DOWNLOAD

FILE DETAILS:

Still STED OM Series XNA XNAac – Generation 3 48V Workshop Manual – PDF DOWNLOAD

Language : English
Pages : 790
Downloadable : Yes
File Type : PDF

DESCRIPTION:

Still STED OM Series XNA XNAac – Generation 3 48V Workshop Manual – PDF DOWNLOAD

General product information
Speed optimisation
General

• Speed optimisation is a software function in the FZS that reduces the driving speed of the truck in relation to the lift height and the load it is carrying. Apart from the actual driving speed, the rate of acceleration and deceleration is reduced, as are those of the auxiliary movements.
• This means, for example, that acceleration of the shift function takes place more gently at 10m than in the lowered state. Speed optimisation comes in different versions ( 2.X, 3.X, 4.X) and releases (e.g. 3.0, 3.1, 3.2, 3.3 ). Since each truck can have its own (customerspeci ?c) dimensions, a different reduction characteristic must be calculated for each truck.
• This is done with the help of a special software program (“VNAP tool”). The corner points (P1-P6) resulting from these calculations are important for the stability of the truck. The corner points are stored in the FZS.
• The following factors are the basis for the calculation
  mentioned above:
  ? Battery type
  ? max. load carrying capability
  ? A-dimension of the turret head
  ? Max. outreach
  ? Max. lift height of main lift
  ? Max. lift height of auxiliary lift
  ? Overall height of truck
  ? Width of load wheel axle
  ? Mechanical rail guidance or inductive guide
  ring
  ? Traction drive version
