Storti Dunker T2 14-16-18-21-24m3 Wagen Parts Manual PDF

Description

Storti Dunker T2 14-16-18-21-24m3 Wagen Parts Manual – PDF DOWNLOAD

FILE DETAILS:

Storti Dunker T2 14-16-18-21-24m3 Wagen Parts Manual – PDF DOWNLOAD

Language : English_German_Spanish_Italian
Pages : 104
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Storti Dunker T2 14-16-18-21-24m3 Wagen Parts Manual – PDF DOWNLOAD

INDEPENDENT GROUP FRAME / FRONT SHORT FIG 1
INDEPENDENT GROUP FRAME / LONG FIG 2
CASE 14-16-18-21-24m3 FIG 3
CASE DISCHARGE FRONT FIG 4
CASE DISCHARGE LATERAL FIG 5
CASE REAR DISCHARGE FIG 6
CASE DISCHARGE FRONT AND REAR FIG 7
PLATFORM WITH STAIRCASE FIG 8
REAR DOOR OPEN INDICATOR FIG 9
RING CONTENENT FIG 10
TRANSMISSION FIG 11
MIXING FIG 12
GEAR SHIFT CONTROL FIG 13
GEAR BOX R 1:1 – 1,5:1 FIG 14
GEAR BOX R 1:1 – 1,8:1 FIG 15
R= 18 2:1 REDUCTOR FIG 16
R= 21 1:1 REDUCTOR FIG 17
R= 16 3:1 REDUCTOR FIG 18
CYLINDER DISCHARGE DOORS FIG 19
FEET THE TRACTOR HYDRAULIC SYSTEM FIG 20
FEET TO HYDRAULIC SYSTEM ON BOARD MACHINE FIG 21
HYDRAULIC CIRCUIT STANDARD FIG 22
HYDRAULIC INDEPENDENT CIRCUIT FIG 23
HYDRAULIC CIRCUIT FRONT / REAR FIG 24
HYDRAULIC 2 COUNTERACTING KNIFE SYSTEM FIG 25
CUTTER ACTIVE SYSTEM FIG 26
G19 PVC BILATERAL UNLOADING BELT FIG 27
G22 PVC BILATERAL UNLOADING BELT FIG 28
NEW G19/G22 PVC BILATERAL UNLOADING BELT FIG 29
NEW LATERAL DISPLACEMENT OF PVC DISCHARGE CONVEYOR FIG 30
ADDITIONAL HOPPER G6,5-G9-G12-G15 FIG 31
ASSEMBLY ADDITIONAL HOPPER FIG 32
SHEET METAL CONTAINMENT AND CLOSING FIG 33
HYDRAULIC SYSTEM LATERAL DISPLACEMENT FIG 34
RIGTH ANLAGE ADDITIONAL HOPPER FIG 35
REMOTE MECHANICAL CONTROL FIG 36
ELECTRICAL CONTROLS FIG 37
MAGNET MODELL 90 FIG 38
ROTATING MAGNET TO RIGHT FIG 39
ROTATING MAGNET TO LEFT FIG 40
WEIGHING SYSTEM AND ACCESSORIES FIG 41
SYSTEM BRAKE MECHANIC FIG 42
SYSTEM BRAKE HYDRAULIC – MECHANIC FIG 43
SYSTEM BRAKE PNEUMATIC AND MECHANIC FIG 44

S.V 11/24
