Takeuchi TL65 TL80 TL80AS TL100 TL70S Service Manual (May 2010) PDF
Original price was: $100.00.$28.95Current price is: $28.95.
Factory Takeuchi Service Manual for TL 65, TL 80, TL 80AS, TL 100 & TL 70S wheel loaders. Covers general safety, technical data, diesel engine, hydraulic system, setting/adjustment values, functioning description, electrical system, maintenance, operation, options, detailed repair instructions, and service bulletins. Ideal for workshops and owner-maintainers.
Description
Takeuchi TL65 TL80 TL80AS TL100 TL70S Service Manual (May 2010) – PDF DOWNLOAD
Description
🔧 Takeuchi TL Series Wheel Loader Service Manual — Workshop-Level Coverage
This is the official Takeuchi service manual built for real repairs and diagnostics on the TL 65 / TL 80 / TL 80AS / TL 100 / TL 70S. Use it to troubleshoot faults, confirm pressure/setting values, follow correct repair procedures, and keep maintenance on schedule—exactly how a professional shop would.
✅ Models Covered
TL 65
TL 80
TL 80AS
TL 100
TL 70S
📌 What’s Inside (Contents / Main Groups)
1) General
Foreword / user information
Safety & accident prevention guidelines
Tightening torques (incl. piston nuts)
Pictograms (machine symbols legend)
Test ports / measuring equipment references
Units & conversion tables
2) Technical Data
Technical data sections by model:
TL65
TL80
TL80AS
TL100
TL70S
Covers key specs (varies by model): engine data, electrical system, transmission, travel ranges, setting values, capacities, etc.
3) Diesel Engine
Engine service information and specifications
4) Hydraulic System
Hydraulic system service information and specifications
5) Setting Instructions
Adjustment and setting procedures/values for correct machine performance
6) Functioning Description
System operating descriptions (useful for diagnostics)
7) Electrical System
Electrical troubleshooting and system coverage
8) Maintenance
Service intervals, inspections, and routine maintenance
9) Operation
Operating information and usage guidance
10) Options
Optional equipment/service information
11) Repair Instructions
Step-by-step repair procedures
12) Service Bulletins
Updates, revisions, and important service notes
📄 File Details
| Item | Details |
|---|---|
| Manual Name | Takeuchi Service Manual |
| Models Covered | TL 65, TL 80, TL 80AS, TL 100, TL 70S |
| Year | 05.2010 |
| Manual PDF Quality | Workshop/service-manual format (diagrams + tables) |
| Pages | 258 pages |
Skip the guesswork—this official Takeuchi TL Series service manual gives you the exact specs, settings, and repair steps to diagnose and fix issues fast. Download instantly and get your loader back to work today.
