TGB Target 400 / 425 ATV Service Repair Manual – Full Workshop Edition PDF
Original price was: $65.00.$26.95Current price is: $26.95.
Factory service and repair manual for TGB Target 400 and 425 ATVs, providing full procedures for inspection, maintenance, overhaul, and troubleshooting. Includes torque values, detailed specifications, wiring diagrams, engine disassembly, lubrication, cooling, drive systems, and frame assembly. Ideal for professional ATV mechanics and owners maintaining the TGB Target 400 series.
Description
TGB Target 400 / 425 ATV Service Repair Manual – Full Workshop Edition – PDF DOWNLOAD
IMAGES:
Description
📘 Overview
The TGB Target 400 / 425 Service Manual by Taiwan Golden Bee Co., Ltd. provides complete technical data and factory-recommended service procedures for the TGB 400cc and 425cc 4-stroke ATVs.
It includes illustrations, torque charts, safety precautions, and inspection standards for every system, ensuring precise repair and maintenance.
📑 Table of Contents
1. General Information
Safety guidelines & symbols
Torque values for engine and frame
Troubleshooting: engine no-start, sluggish running, clutch, power loss
Lubrication points & service symbols
371501204-tgb-target-400-servic…
2. Maintenance Information
Periodic maintenance schedule (1,000–4,000 km intervals)
Specifications: oil, coolant, compression, tire pressures
Service procedures for:
Fuel lines, air cleaner, spark plug, valve clearance
Carburetor idle & emission adjustment
Ignition system checks (CDI timing, advance)
Compression test, drive belt inspection
Brake system bleeding, clutch wear, tire service
Steering and suspension inspection
Full special tools catalog with TGB part numbers
371501204-tgb-target-400-servic…
3. Lubrication System
Engine oil circuits & oil pump service
Filter replacement procedures
Oil pressure specifications
4. Fuel System
Carburetor cleaning & float level check
Fuel line routing & vacuum hose diagram
5. Engine Removal / Installation
Engine dismount procedure, safety, and torque reassembly chart
6–7. Cylinder Head / Piston
Valve adjustment, piston inspection, compression ratio (9.2:1)
Detailed exploded views of head, valve, and camshaft assembly
8–10. Drive & Transmission
“V” type belt CVT system & kick starter overhaul
Final drive gear inspection and replacement
Alternator and starting clutch removal & test
11. Crankshaft / Crankcase
Disassembly steps, bearing fit, seal replacement
12. Cooling System
Radiator, water pump, and coolant bleeding procedure
13–16. Frame and Body
Disassembly of body covers, fenders, seats, brackets
Front and rear brake system details
Steering shaft, tie-rod alignment, front/rear suspension service
17. Electrical Equipment
CDI, ignition coil, regulator, relays, sensors
Charging & lighting circuits testing
18. Wiring Diagram
Full color-coded electrical schematic for Target 400/425
📊 File Details
| Detail | Specification |
|---|---|
| Manual Name | TGB Target 400 / 425 Service Repair Manual |
| Models Covered | Target 400, Target 425 ATVs |
| Manufacturer | Taiwan Golden Bee Co., Ltd. |
| Engine Type | 4-stroke, water-cooled, single-cylinder |
| Compression Ratio | 9.2:1 |
| Ignition | CDI |
| Transmission | Automatic CVT (L/H/N/R) |
| Language | English |
| Format | PDF (searchable, illustrated) |
| No. of Pages | ~110 |
| PDF Quality | OEM scan with clear schematics & diagrams |
💡 Benefits of This Manual
Complete mechanical coverage from engine rebuilds to electronics.
Factory specifications for torque, lubrication, and part tolerances.
Includes detailed troubleshooting charts for common issues.
Electrical and hydraulic schematics support precise diagnostics.
Essential for workshops, ATV owners, and performance tuners.
