Tigercat H855C LH855C Harvester Service Manual – PDF DOWNLOAD

Description

Tigercat H855C LH855C Harvester Service Manual – PDF DOWNLOAD

DESCRIPTION:

Tigercat H855C LH855C Harvester Service Manual – PDF DOWNLOAD

SERIAL NUMBER 85531001 TO 85532000
SERIAL NUMBER 85581001 TO 85582000

INTRODUCTION
Tigercat 855C/L855C Feller Buncher
An Operator’s manual, Service manual and a Parts catalog are made available by Tigercat to assist the dealer, customer and operator in becoming familiar with the features of the H855C/LH855C Harvesters
Serial numbers:-
H855C 85531001 TO 85532000
LH855C 85581001 TO 85582000

The H855C/LH855C Harvesters are designed for harvesting trees, at-the-stump processing or roadside processing applications as well as thinning, selective felling and clear felling applications in plantations and natural stands. The operator’s manual will assist the operator with the techniques of proper and safe operation of the H855C/LH855C Harvesters. There is also important information regarding the safe operation of the attachment.

• The service manual contains safety and servicing procedures and a preventive maintenance schedule to assist in repair and to ensure optimum machine performance. Section 1 in both the operator’s manual and the service manual contains safety information that must be followed.
• As well, throughout the rest of the manuals, DANGER, WARNING and CAUTION notices are displayed where necessary, drawing attention to possible hazards when performing certain procedures. Only trained personnel should be allowed to operate or work on the machine.
• The information contained in this manual is current at time of printing. Improvements to the machine are on-going and may not be covered, therefore in these cases contact your Tigercat dealer for the appropriate information. The phrase “and up” appearing in this manual after the serial number implies that the related information is current for any machine serial number HIGHER than the serial number preceding the “and up”.
• Tigercat reserves the right to make changes to the machine after this manual release date that may not immediately appear in this manual. Every effort is made to send out updates on a regular basis. If the machine in question was built after the release date of this manual and there is a discrepancy, call Tigercat service department. The release date appears on the first page. The Company reserves the right to change information contained herein at any time without prior notice.
