Toro Wheel Horse 260 Series Tractor Service Manual – PDF DOWNLOAD
Original price was: $85.00.$15.95Current price is: $15.95.
Official Toro Wheel Horse 260 Series tractor service manual for lawn tractors from 1994-2002, detailing specifications, chassis repairs, transaxle maintenance for Tuff Torq, Hydro-Gear, and Tecumseh Peerless models, gear drive systems, electrical diagnostics, and troubleshooting. Includes torque specs, adjustments, and safety guidelines. 112 pages of essential repair content.
Description
Toro Wheel Horse 260 Series Tractor Service Manual – PDF DOWNLOAD
Description
This comprehensive Toro Wheel Horse 260 Series tractor service manual is designed for service technicians working on Toro 260 Series lawn tractors, including both hydrostatic and gear drive variants. It provides detailed procedures for maintenance, disassembly, inspection, repair, and reassembly, with emphasis on basic shop safety, mechanical/electrical skills, and strict cleanliness for hydrostatic transaxles to prevent contamination. The manual references additional resources like the Toro Electrical Demystification Guide (492-4404), Tuff Torq (492-0699), Hydro-Gear (492-0682), Peerless transaxle manuals, and engine-specific instructions from manufacturers.
Key highlights include troubleshooting charts, belt routing diagrams, adjustment procedures for brakes, neutral, and shift linkage, and testing methods for electrical components like relays, solenoids, switches, and modules. Ideal for Toro 260 Series lawn tractor troubleshooting and repair, it covers models from 1994 to 2002 and may apply to later units.
Extracted and categorized table of contents in bullet-point format:
- Specifications
- General Specifications: 1-1
- Tecumseh Peerless Transaxle: 1-2
- Identification: Tecumseh Peerless Model 820-024: 1-2
- General Specifications: 1-2
- Hydrostatic Transaxles: 1-3
- Identification: Tuff Torq Model K61A Transaxle: 1-3
- General Specifications: 1-3
- Identification: Hydro-Gear Model 322-3000 & 330-3000 Transaxle: 1-4
- General Specifications: 1-4
- Torque Specifications: 1-5
- Fastener Identification: 1-5
- Standard Torque for Dry, Zinc Plated, and Steel Fasteners (Inch Series): 1-6
- Standard Torque for Dry, Zinc, and Steel Fasteners (Metric Fasteners): 1-7
- Other Torque Specifications: 1-8
- SAE Grade 8 Steel Set Screws: 1-8
- Thread Cutting Screws (Zinc Plated Steel): 1-8
- Conversion Factors: 1-8
- Wheel Bolts and Lug Nuts: 1-8
- Thread Cutting Screws (Zinc Plated Steel): 1-8
- Equivalents and Conversions: 1-9
- Decimal and Millimeter Equivalents: 1-9
- U.S. to Metric Conversions: 1-10
- Chassis
- Model and Serial Number Location: 2-1
- Greasing and Lubrication: 2-1
- Front Wheel Toe-in: 2-2
- Front Wheel Toe-in Adjustment: 2-3
- Front Wheel and Spindle Removal and Installation: 2-3
- Removal: 2-3
- Front Axle Removal and Installation: 2-4
- Steering Gear: 2-6
- Description: 2-6
- Steering Backlash Adjustment: 2-6
- Steering Gear Shaft Disassembly: 2-7
- Steering Gear Assembly: 2-10
- Sector Gear Disassembly: 2-11
- Sector Gear Assembly: 2-12
- Tilt Steering: 2-12
- Description: 2-12
- Tilt Steering Disassembly: 2-13
- Tilt Steering Assembly: 2-14
- Steering Specifications: 2-15
- Hood Removal: 2-16
- Seat and Fender Removal: 2-16
- Gas Tank Removal: 2-17
- Lift Lever Linkage: 2-18
- Dial-A-Height Linkage: 2-19
- Lift Arm Linkage: 2-20
- Adjustments: 2-21
- Lift Height: 2-21
- Leveling: 2-21
- Side to Side: 2-21
- Power Lifts: 2-21
- Electrohydraulic Lift (2000 and Prior Models): 2-21
- Electric Lift (2001 and Later Models): 2-21
- Removal: 2-21
- Installation: 2-21
- Tuff Torq Transaxle
- Tuff Torq Hydrostatic Transaxle: 3-1
- Internal Service: 3-1
- Fluid Change: 3-1
- Transaxle Removal – Tuff Torq: 3-1
- Installation – Tuff Torq Transaxle: 3-4
- Belt Replacement – Tuff Torq Transaxle: 3-6
- Belt Routing: 3-10
- Belt Adjustment: 3-13
- Troubleshooting – Tuff Torq Transaxle: 3-14
- Purging Procedures – Tuff Torq Transaxle: 3-15
- Brake – Tuff Torq Transaxle: 3-15
- Checking the Brake: 3-15
- Adjusting the Brake – Tuff Torq Transaxle: 3-15
- Foot Control Adjustment Procedure: 3-16
- Neutral Adjustment – Tuff Torq Transaxle: 3-17
- Hydro-Gear Transaxle
- Hydro-Gear Hydrostatic Transaxle: 4-1
- Internal Service: 4-1
- Fluid Change: 4-1
- Transaxle Removal – Hydro-Gear: 4-1
- Installation – Hydro-gear Transaxle: 4-4
- Belt Adjustment: 4-7
- Purging Procedures – Hydro-Gear Transaxle: 4-8
- Brake – Hydro-Gear Transaxle: 4-9
- Checking the Brake: 4-9
- Brake Adjustment – Hydro-Gear Transaxle: 4-9
- Foot Control Adjustment Procedure: 4-10
- Troubleshooting Chart for the Hydro-Gear Transaxle: 4-11
- Belt Replacement – Hydro-Gear Transaxle: 4-11
- Belt Routing Diagram: 4-15
- Belt Adjustment: 4-16
- Neutral Adjustment – Hydro-Gear Transaxle: 4-17
- Gear Drive
- Transaxle Removal – Gear Drive: 5-1
- Installation – Gear Drive Transaxle: 5-3
- Troubleshooting: 5-5
- Internal Service: 5-5
- Symptom: Unit Jumps Out Of Gear: 5-6
- Symptom: Unit Can Not Be Shifted (or Difficult to Shift): 5-6
- Symptom: Unit Does Not Drive: 5-6
- Belt Replacement – Gear Drive: 5-7
- Belt Routing Diagram: 5-9
- Belt Adjustment: 5-12
- Proper Shifting Procedures – Gear Drive: 5-13
- Shift Linkage Adjustment: 5-13
- Shift Detent Tension Adjustment: 5-14
- Brakes: 5-14
- Checking the Brake: 5-14
- Adjusting the Brake: 5-15
- Electrical Systems
- Gear Drive Models: 6-1
- Hydrostatic Models: 6-1
- Relay: 6-1
- Purpose: 6-1
- Location: 6-1
- How It Works: 6-1
- Testing: 6-2
- Solenoid: 6-2
- Purpose: 6-2
- Location: 6-3
- How it Works: 6-3
- Testing: 6-3
- Ignition Switch: 6-4
- Purpose: 6-4
- Location: 6-4
- How It Works: 6-4
- Testing: 6-5
- Low Voltage Module: 6-5
- Purpose: 6-5
- Location: 6-5
- How It Works: 6-5
- Testing: 6-6
- Electric (PTO) Clutch: 6-6
- Purpose: 6-6
- Location: 6-6
- How It Works: 6-6
- Testing: 6-6
- Coil Resistance Measurement: 6-6
- Measuring Clutch Current Draw: 6-7
- Setting the Air Gap on 1999 and Prior Model 260 Series Tractors: 6-8
- Clutch Burnishing Procedure: 6-8
- PTO Switch: 6-8
- Purpose: 6-8
- Location: 6-8
- How it Works: 6-8
- Testing: 6-8
- Microswitches: 6-9
- Purpose: 6-9
- Testing: 6-9
- Location: 6-10
- Neutral Switch – Plunger Type (Used on 2000 and Later Hydrostatic Models): 6-11
- Purpose: 6-11
- Location: 6-11
- How it Works: 6-11
- Testing: 6-12
- Brake Switch (Used on 2000 and Later Hydrostatic Models): 6-12
- Purpose: 6-12
- Location: 6-12
- How it Works: 6-12
- Brake Switch Testing: 6-13
- Seat Switch: 6-13
- Purpose: 6-13
- Location: 6-13
- How It Works: 6-14
- Testing: 6-13
- KeyChoice™ Reverse Operating System – Used on 1999 and Later Tractors: 6-14
- Testing the Key Choice™ Reverse Operating System – Unactivated: 6-14
- Testing the KeyChoice™ Operating System – Activated: 6-14
- KeyChoice™ Reverse Operating System Switch: 6-16
- Purpose: 6-16
- How It Works: 6-16
- Testing: 6-16
- Reverse Switch (Hydrostatic Models): 6-16
- Purpose: 6-16
- Location: 6-16
- How It Works: 6-16
- Testing: 6-16
- Reverse Switch (Gear Drive Tractors): 6-17
- Purpose: 6-17
- Location: 6-17
- How It Works: 6-17
- Testing: 6-17
- KeyChoice™ Reverse Operating System Module: 6-17
- Purpose: 6-17
- Location: 6-18
- How It Works: 6-18
- Testing – No Power to Circuit (With Module Out of Circuit): 6-19
- Testing – Powered Circuit (With Module Out of Circuit): 6-19
The manual integrates practical tips, such as proper shifting procedures and clutch burnishing, making it a valuable Toro 260 Series hydrostatic transaxle maintenance guide and Toro Wheel Horse 260 Series electrical system diagnostics resource. Copyright 2002 by The Toro Company.
File Details:
- Manual Name: 260 Series Tractor Service Manual
- Models Covered: Toro Wheel Horse 260 Series Tractors
- Year: 2002 (applicable to 1994-2002 models)
- Manual PDF Quality: High-quality digital with clear text, diagrams, and searchable content
- No. of Pages: 112
