Unicarriers Forklift 1F2UPU Parts Manual PN PM5UC-1F2PU – PDF DOWNLOAD

Description

Unicarriers Forklift 1F2UPU Parts Manual PN PM5UC-1F2PU – PDF DOWNLOAD

FILE DETAILS:

Unicarriers Forklift 1F2UPU Parts Manual PN PM5UC-1F2PU – PDF DOWNLOAD

Language : English
Pages : 587
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Unicarriers Forklift 1F2UPU Parts Manual PN PM5UC-1F2PU – PDF DOWNLOAD

Platinum II Series IC Pneumatic Tire
Engine Powered/Carburetor Gasoline & Dual Fuel, Diesel
4,000-7,000 lb. Capacities

Cover 1
Bulletin PB2018-288 New Grammer Seat 2
Edition Page 24
English – Front Pages 25
General Index 25
Contents 26
Introduction 27
Group Symbols and Abbreviations 28
Model Variation (Long Model Code) Breakdown 29
Classification of Model 30
Chassis and Engine Serial Number 32
Table of Chassis Numbers 33
Section Index 35
Español – Primeras Páginas 37
Índice General 37
Contenido 38
Introducción 39
Grupo Símbolos y Abreviaturas 40
Model Variación (Largo Código de Modelo) Detalle 41
Modelo de Clasificatción 42
Chasis y Número de Serie del Motor 44
Tabla de los Numeros de Chasis 45
Índice Sección 47
Português – Páginas Dianteiras 49
Índice Geral 49
Conteúdo 50
Introdução 51
Grupo Símbolos e Abreviaturas 52
Modelo Variação (Long Código de Modelo) a Repartição 53
Classificação do Modelo 54
Número de série do chassi e do Motor 56
Tabela de números de chassis 57
Índice da Seção 59
Engine Mechanical Sec 100-150 & 296 61
Sec 100 Engine Assembly 62
Sec 102A Engine Gasket Kit (K21 & K25) 64
Sec 102B Engine Gasket Kit (QD32) 66
Sec 110A Cylinder Block & Oil Pan (K21 & K25) 68
Sec 110B Cylinder Block & Oil Pan (QD32) 70
Sec 111A Cylinder Head & Rocker Cover (K21 & K25) 74
Sec 111B Cylinder Head & Rocker Cover (QD32) 76
Sec 112 Engine & Mounting 78
Sec 117B Fan, Compressor & Power Steering Belt (QD32) 80
Sec 118A Crank Case Ventilation (K21 & K25) 82
Sec 118B Crank Case Ventilation (QD32) 84
Sec 120A Piston, Crankshaft & Flywheel (K21 & K25) 86
Sec 120B Piston, Crankshaft & Flywheel (QD32) 90
Sec 130A Camshaft & Valve Mechanism (K21 & K25) 92
Sec 130B Camshaft & Valve Mechanism (QD32) 94
Sec 135A Front Cover & Fitting (K21 & K25) 98
Sec 135B Front Cover & Fitting (QD32) 100
Sec 140A Manifold (K21 & K25) 104
Sec 140B Manifold (QD32) 106
Sec 150A Lubricating System (K21 & K25) 108
Sec 150B Lubricating System (QD32) 110
Sec 296 Controller (VCM) 112
Fuel & Engine Control Sec 160-199 115
Sec 160A Carburetor (K21 & K25) 116
Sec 164A Fuel Strainer & Fuel Hose (K21 & K25) 120
Sec 164B Fuel Strainer & Fuel Hose (QD32) 122
Sec 165 Air Cleaner 124
Sec 170A Fuel Pump (K21 & K25) 128
Sec 173A Fuel Piping (K21 & K25) 130
Sec 173B Fuel Piping (QD32) 132
Sec 180 Accelerator Linkage 134
Sec 185B Fuel Supply System (QD32) 138
Sec 186B Fuel Injection Pump (QD32) 140
Sec 191A Governor (K21 & K25) 142
Sec 195A Vaporizer (K21 & K25) 144
Sec 196A LPG Filter & Piping 146
Sec 199A LPG Bombe 150
Sec 199B LPG Bombe -Fixed 154
Sec 199C LPG Bombe (LPGQ) 156
Exhaust & Cooling Sec 200-216 159
Sec 200A Exhaust Tube & Muffler (K21 & K25) 160
Sec 200B Exhaust Tube & Muffler (QD32) 162
Sec 200C Exhaust Tube & Muffler (QD32-MFLH) 164
Sec 210A Water Pump, Cooling Fan & Thermostat (K21 & K25) 166
Sec 210B Water Pump, Cooling Fan & Thermostat (QD32) 170
Sec 213B Oil Cooler (QD32) 174
Sec 214 Radiator, Shroud & Fitting 176
Sec 216 Torque Converter Oil Cooler & Piping 180
Engine Electrical Sec 220-233 183
Sec 220A Ignition System (K21 & K25) 184
Sec 220B Ignition System (QD32) 186
Sec 221A Distributor (K21 & K25) 188
Sec 223A Vacuum Piping (K21 & K25) 190
Sec 230A Alternator Fitting (K21 & K25) 192
Sec 230B Alternator Fitting (QD32) 194
Sec 231A Alternator (K21 & K25) 196
Sec 231B Alternator (QD32) 198
Sec 233A Starter Motor (K21 & K25) 200
Sec 233B Starter Motor (QD32) 202
Body Electrical Sec 240-267 205
Sec 240 Wiring Engine Room & Instrument 206
Sec 241A1 Wiring (Body) (K21 & K25) Part 1 208
Sec 241A2 Wiring (Body) (K21 & K25) Part 2 212
Sec 241B1 Wiring (Body) (QD32) Part 1 214
Sec 241B2 Wiring (Body) (QD32) Part 2 218
Sec 244 Battery & Battery Mounting 220
Sec 248 Instrument Meter & Gauge 222
Sec 251 Switch 224
Sec 253 Electrical Unit 226
Sec 260 Head Lamp 228
Sec 261 Front Combination Lamp 230
Sec 265A Rear Combination Lamp 232
Sec 265B Rear Combination Lamp -LMRA 234
Sec 267A Lamps (Others) 236
Sec 267B Lamps (Others) -MBZBR 238
Sec 267C Lamps (Others) -LMRA 240
Power Train Sec 310-380 243
Sec 310 Transmission Asembly & Fitting (ATM) 244
Sec 311 Torque Converter Case & Housing (ATM) 246
Sec 313 Oil Pump Parts (ATM) 248
Sec 314 Governor & Gear Parts (ATM) 250
Sec 315 Clutch & Brake Band (ATM) 252
Sec 317 Control Valve (ATM) 254
Sec 370 Propeller Shaft (ATM) 256
Sec 380A Final Drive Assembly (ATM-20+25) 258
Sec 380B Final Drive Assembly (ATM-30+35 1015~0617) 262
Sec 380C Final Drive Assembly (ATM-30+35 0617~) 266
Axle & Suspension Sec 402-434 269
Sec 402 Drive Axle 270
Sec 403 Steering Axle 274
Sec 433 Road Wheel & Tire (Drive Axle) 278
Sec 434 Road Wheel & Tire (Steering Axle) 282
Brake Sec 440-465 285
Sec 440 Front Brake 286
Sec 443 Parking Brake Control 290
Sec 460 Brake Master Cylinder 292
Sec 462 Brake Piping & Control 294
Sec 465 Brake & Clutch Pedal 296
Steering Sec 480-497 299
Sec 480 Steering Gear 300
Sec 484 Steering Wheel 302
Sec 485 Steering Linkage 304
Sec 488 Steering Column 308
Sec 497 Power Steering Piping 310
Body (Front, Roof & Floor) Sec 500-740 312
Sec 500A Frame -Main 314
Sec 500B Frame -Front Covers 318
Sec 500C Frame -NIZ2, DSTC, DSTW, MRPKG 320
Sec 580A Lift Cylinder (2F) 324
Sec 580B Lift Cylinder (2W 2 & 2 5 Ton) 332
Sec 580C Lift Cylinder (2W 2 8, 3 & 3 5 Ton) 336
Sec 580D Lift Cylinder (3F) 340
Sec 580E Lift Cylinder (3V) 348
Sec 585A Chain Wheel Support & Chain (2F) 358
Sec 585B Chain Wheel & Chain (2W) 362
Sec 585C Chain Wheel Support & Chain (3F) 366
Sec 585D Chain Wheel Support & Chain (3V) 370
Sec 586 Tilt Cylinder 374
Sec 591A Mast (2F) 378
Sec 591B Mast (2W) 382
Sec 591C Mast (3F) 386
Sec 591D Mast (3V) 392
Sec 594 Back Rest & Fork 396
Sec 595A Carriage (2F) 400
Sec 595B Carriage (2W) 402
Sec 595C Carriage (3F) 404
Sec 595D Carriage (3V) 406
Sec 597A Sideshifter (S/S01, S/S02) 408
Sec 597B Sideshifter (S/S03, S/S04) 412
Sec 655 Top Panel, Hinge & Fitting 416
Sec 680 Instrument Panel, Pad & Cluster Lid 420
Sec 691A Hydraulic Oil Pump & Fitting (Tank Fitting Part) 422
Sec 691B Hydraulic Oil Pump & Fitting (Pump Fitting Part) 424
Sec 692 Hydraulic Oil Pump Assembly 426
Sec 693A Hydraulic Control Valve 428
Sec 693B Hydraulic Control Valve (FC) 432
Sec 694B Hydraulic Control Valve Fitting (VAL3) 434
Sec 694C Hydraulic Control Valve Fitting (VAL4) 438
Sec 694D Hydraulic Control Valve Fitting (Kit Parts) 442
Sec 694E Hydraulic Control Valve Fitting (FC-VAL3) 444
Sec 694F Hydraulic Control Valve Fitting (FC-VAL4) 446
Sec 695A Hydraulic Control Lever (Fitting Parts) 448
Sec 695C Hydraulic Control Lever (LVRW/VAL3) 450
Sec 695D Hydraulic Control Lever (LVRW/VAL4) 452
Sec 695G Hydraulic Control Lever (LVRL/VAL3) 454
Sec 695H Hydraulic Control Lever (LVRL/VAL4) 458
Sec 695I Hydraulic Control Lever (FC Fitting Parts) 462
Sec 695J Hydraulic Control Lever (FC) 464
Sec 695K Hydraulic Control Lever (FC Wiring) 468
Sec 697A Hydraulic Oil Piping (From Tank To Pump) 470
Sec 697B Hydraulic Oil Piping (From Tank To Valve) 472
Sec 697C Hydraulic Oil Piping (From Valve To Cylinder) 474
Sec 697D Hydraulic Oil Piping (From Tank To Strg) 476
Sec 697E Hydraulic Oil Piping (ACMX) 478
Sec 698A Hydraulic Oil Piping Mast (2F) 480
Sec 698B Hydraulic Oil Piping Mast (2W) 484
Sec 698C Hydraulic Oil Piping Mast (3F) 486
Sec 698D Hydraulic Oil Piping Mast (3V) 490
Sec 699A Hydraulic Oil Piping (Attachment) (2F) 494
Sec 699B Hydraulic Oil Piping (Attachment) (2F, VAL3) 496
Sec 699C Hydraulic Oil Piping (Attachment) (2F, VAL4) 500
Sec 699D Hydraulic Oil Piping (Attachment) (2W) 506
Sec 699E Hydraulic Oil Piping (Attachment) (2W, VAL3) 508
Sec 699F Hydraulic Oil Piping (Attachment) (2W, VAL4) 512
Sec 699G Hydraulic Oil Piping (Attachment) (3F) 516
Sec 699H Hydraulic Oil Piping (Attachment) (3F, VAL3) 518
Sec 699I Hydraulic Oil Piping (Attachment) (3F, VAL4) 522
Sec 699J Hydraulic Oil Piping (Attachment) (3V) 528
Sec 699K Hydraulic Oil Piping (Attachment) (3V, VAL3) 530
Sec 699L Hydraulic Oil Piping (Attachment) (3V, VAL4) 534
Sec 737 Over Head Guard 538
Sec 740 Floor Panel 542
Body (Side, Rear & Seat) Sec 871 545
Sec 871A Seat 546
Sec 871B Seat (FC) 550
Miscellaneous Sec 991-999 553
Sec 991 Caution Plate & Label Car 554
Sec 992 Caution Plate & Label Electrical 556
Sec 993 Caution Plate & Label Mast 558
Sec 999 Touch Up Paint 560
Part No Index 563
Dealer Suggested Stocking List 583
