UTILEV 2.0T-3.5T Internal Combustion Counterbalanced Forklift Truck Service Manual PDF
$20.95
UTILEV 2.0T-3.5T Internal Combustion Counterbalanced Forklift Truck Service Manual – PDF DOWNLOAD
PART NO. 76002089(R5)
Description
UTILEV 2.0T-3.5T Internal Combustion Counterbalanced Forklift Truck Service Manual – PDF DOWNLOAD
FILE DETAILS:
UTILEV 2.0T-3.5T Internal Combustion Counterbalanced Forklift Truck Service Manual – PDF DOWNLOAD
Language : English
Pages : 90
Downloadable : Yes
File Type : PDF
PART NO. 76002089(R5)
IMAGES PREVIEW OF THE MANUAL:
TABLE OF CONTENTS:
UTILEV 2.0T-3.5T Internal Combustion Counterbalanced Forklift Truck Service Manual – PDF DOWNLOAD
1 Powertrain 6
1 1 1 Engines 6
2 1 2 Mazda 2 2L 7
3 1 3 PSI 2 4L 8
4 1 4 4TNE92/4TNE98 Diesel 9
2 Transmission and Torque Converter 12
5 2 1 Data 12
6 2 2 Summary: Transmission Overview 13
7 2 3 Principles of Operation 14
8 2 4 Torque Converter (Fig 2-4) 19
9 2 5 Two-Way Clutch (Fig 2-5) 20
10 2 6 Charging Pump (Fig 2-6) 21
11 2 7 Inching Valve (Fig 2-7) 22
12 2 8 Transmission Housing 22
13 2 9 Cover and Control Valve (Fig 2-8) 23
14 2 10 Reducer Gear & Differential 24
3 Drive Axle 26
15 3 1 Data 26
16 3 2 Fault Diagnoses and Corrections 26
17 3 3 Drive Axle Components 27
18 3 4 Assembly and Disassembly of Drive Axle 29
19 3 5 Axle Shaft and Wheel Hub 30
20 3 6 Bearing Adjusting 31
4 Steering Axle 32
21 4 1 General Specifications 32
22 4 2 Fault Diagnoses Corrections 32
23 4 3 Steering Axle 34
24 4 4 Steering Kingpin and Steering Spindle 34
25 4 5 Wheel Bearing Adjustment 34
5 Steering System 36
26 5 1 Data 36
27 5 2 Trouble Shooting 36
28 5 3 Summary 37
29 5 4 Install Steering System 39
6 Brake System 40
30 6 1 Fault Diagnoses and Corrections 40
31 6 2 Summary 41
7 Hydraulic System 47
32 7 1 Data 47
33 7 2 Fault Diagnoses and Corrections 48
34 7 3 Main Pump 50
35 7 4 Hydraulic Control Valve (Fig 7-2) 51
36 7 5 Hydraulic Schematic 54
8 Lifting System 57
37 8 1 Assemble Data 57
38 8 2 Fault Diagnoses and Corrections 58
39 8 3 Summary 59
40 8 4 Removal and Adjustment 65
41 8 5 Detaching and Installing the Lift Cylinders 69
42 8 6 Disassembly and Installation of Tilt Cylinder 70
43 8 7 Debugging Precautions Following Forklift Assembly 71
44 8 8 Counterbalance weight 72
9 Electrical System 73
45 9 1 Schematics 82
