Volvo T450D Articulated Dump Truck Workshop Service repair Manual – PDF Download

Description

Volvo T450D Articulated Dump Truck Workshop Service repair Manual

FILE DETAILS:

FILE TYPE:PDF
MANUAL LANGUAGE:ENGLISH
DOWNLOADABLE:YES
PAGES:1900+

DESCRIPTION:

• Engine The machine is equipped with a straight 6-cylinder, 4-stroke diesel engine. The engine is a direct-injected, turbocharged low-emission engine with intercooler. Electrical system The machine has four control units (ECU). I-ECU (for the instruments) is integrated with the information display unit, warning lights, and instruments, and gives the operator information via these. V-ECU (for the machine) receives signals from sensors on the machine that are sent to the I-ECU.
• T-ECU controls the transmission. E-ECU controls the engine. Power transmission The planetary geartransmission is fully automatic. It has a torque converter with free-wheel stator and automatic direct clutch (lock-up) on all gears except reverse gears. The machine has six forward gears and two reverse gears. A hydraulic retarder is integrated in the transmission.
• The dropbox with high/low range has a differential which eliminates stresses between the driven axles, which reduces tire and road wear as well as fuel consumption. The longitudinal differential is provided with a lock function. Together with the transmission, six gears forward in low range and six gears forward in high range are available.
• In reverse, two gears in low range and two gears in high range are available. In low range, the dropbox automatically shifts to high range (6H) after 6 L The drive axles are equipped with a differential planetary gear hub reductions. All drive axles have differential lock.

TABLE OF CONTENTS:

Volvo T450D-SM
Volvo T450D-SM\0 General.pdf
Volvo T450D-SM\0 Safety.pdf
Volvo T450D-SM\1 Standard Parts, Service.pdf
Volvo T450D-SM\2 Engine with Mounting and Equipment.pdf
Volvo T450D-SM\3 Elec. System, Warning System, Information System, Instruments.pdf
Volvo T450D-SM\4 Power Transmission.pdf
Volvo T450D-SM\5 Brake.pdf
Volvo T450D-SM\6 Steering.pdf
Volvo T450D-SM\7 Frame and Wheel.pdf
Volvo T450D-SM\8 Machinery House, Cab, Exterior Trim Parts Anywhere.pdf
Volvo T450D-SM\9 Hydraulic System.pdf
