War Department Ford Tank Engines GAA GAF & GAN Technical Manual 9-1731B – PDF DOWNLOAD

INTRODUCTION:
1. SCOPE.:
a. These instructions are published for the information and guid
ance of personnel charged with the maintenance and repair of the
Ford tank engines, models GAA, GAN, and GAF. These instructions
are supplementary to field and technical manuals prepared for the
using arms. This manual does not contain information which is
intended primarily for the using arms, since such information is
available to ordnance maintenance personnel in 100-series TM’s or
FM’s.
b. This manual contains a description of, and procedure for re
moval, disassembly, inspection, repair, and assembly of the Ford
tank engines, models GAA, GAN, and GAF.
c. TM 9-1826B contains information for the maintenance of the
Stromberg carburetor used on these engines.
d. TM 9-1828A contains information for the maintenance of the
A-C fuel pump used on these engines.
e. TM 9-1825B contains information for the maintenance of the
Auto-Lite electrical equipment used on these vehicles.
f. TM 9-1734A contains information for the maintenance of the
General Electric governor used on vehicles using the GAN engine.

TABLE OF CONTENTS:

War Department Ford Tank Engines GAA GAF & GAN Technical Manual 9-1731B – PDF DOWNLOAD

CHAPTER 1 INTRODUCTION 1-2 1-3
CHAPTER 2 ENGINE 3-40 4M93
SECTION I Description and data 3-4 4-17
II Preparation of engine for overhaul 5-9 17- 23
III Disassembly of stripped engine into
subassemblies 10-11 23- 32
IV Disassembly, cleaning, inspection,
repair and assembly of subas
semblies 12-27 33-126
V Assembly of stripped engine 28-29 126-145
VI Installation of accessories 30-33 146-158
VII Run-in test 34-38 158-178
VIII Serviceability standards 39-40 178-193
CHAPTER 3 MAGNETOS 41-51 194-223
CHAPTER 4 SPECIAL TOOLS 52 224-226
APPENDIX
References 53-55 227-230
INDEX 231-235
