Yale E842 MP 18-22 L Service Manual – PDF DOWNLOAD

Description

Yale E842 MP 18-22 L Service Manual – PDF DOWNLOAD

FILE DETAILS:

Yale E842 MP 18-22 L Service Manual – PDF DOWNLOAD

DESCRIPTION:

Yale E842 MP 18-22 L Service Manual – PDF DOWNLOAD

This manual is addressed to the skilled technicians of Yale service
network
PART NO:524301820
E842….. MP18 – MP20
MP20L – MP22

• Before using the batteries, make sure that the cables are connected to the terminals as described: (+) with (+) and (-) with (-). Do not short-circuit the terminals. The gas emanated during a recharge is higly flammable. During the recharge of the battery leave the battery compartment uncovered in order to use a more efficient ventilation and remove the plugs. Do not check the condition of the battery charge by means of “jumpers” obtained by placing metal objects on the terminals.
• Before any intervention check if there are no short-circuit elements. Disconnect the batteries before acting on the electric system. For the battery chargers and similar equipment, use only auxiliary electric power supply sources in order to avoid any electric shocks. A fluid passing through a very small hole can be almost invisible but strong enough to penetrate into the skin; in these cases check the fluid by means of a card or a piece of wood. To chek the pressure of the plant use the proper devices. BANDS, ROPES AND HANGING ROPES: SUGGESTIONS FOR THE USE Register all used hanging ropes, whose features and data are shown on the identification plate.
• Do not use bands, ropes or hanging ropes, whose identification plate has been lost. Always use bands, ropes or hanging ropes of proper dimensions. As far as the hanging ropes are concerned, take into consideration the lifting angle and the unbalance of the load. The hooks of the hanging ropes must have a proper size according to the hook of the bridge crane and they must move freely.
• Position the load in the hook mouth. Do not place the load on the point of the hook. During lifting, do not carry out sudden operations that could tear the ropes and the bands. Do not carry out lifting operations with twisted ropes and bands. Knots are forbidden.Always protect the ropes and the bands when they are near sharp edges. During the movements without load in order to avoid unintentional collisions or hooking, fasten the hooks to the proper seats and lock them.
• Use of hanging ropes with unbalanced load If unbalanced loads must be lifted it is advisable to reduce the carrying capacity of the hanging ropes: Slings with 2 arms, consider them as the slings with 1 arm. Slings with 3 and 4 arms, consider them as the slings with 2 arms. Suggestions for maintenance Check the bands, the ropes and the hanging ropes according to the law in force in order to determine their working conditions.
• Carry out the replacement in the following cases: When the components are deformed, cut or when there are cracks, hollows, notches or abrasions on them. When the wear of the components is higher than 10% of the initial dimensions. When the sling is overloaded.

TABLE OF CONTENTS:

Yale E842 MP 18-22 L Service Manual – PDF DOWNLOAD

Section1: Presentation
Section 2: Installation and settings
Section 3: Diagnostics and measurements
Section 4: Electrical system
Section 5: Hydraulic system
Section 6: Mechanics
Section 7: Reduction unit
Section 8: Braking system
Section 9: Ordinary maintenance

YALE E842 MP 18-22 L SERVICE MANUAL – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

PLEASE NOTE:

• This is the SAME MANUAL used by the dealerships to diagnose your vehicle
• No waiting for couriers / posts as this is a PDF manual and you can download it within 2 minutes time once you make the payment.
• Your payment is all safe and the delivery of the manual is INSTANT – You will be taken to the DOWNLOAD PAGE.
• So have no hesitations whatsoever and write to us about any queries you may have : heydownloadss @gmail.com
