Yunnei D20 Series China VI Diesel Engine Service Manual YND20 D20TCIF PDF
Original price was: $95.00.$18.95Current price is: $18.95.
Official Kunming Yunnei Power D20 Series China VI diesel engine service manual covering the D20TCIF model. Includes complete technical specifications, full disassembly & assembly procedures, BOSCH common-rail system setup, DOC+DPF+SCR+ASC aftertreatment maintenance, ECU fault code tables, troubleshooting for 20 fault categories, and engine storage procedures. Essential reference for technicians servicing YND20 / D20TCIF engines in pickup trucks and light commercial vehicles. Instant PDF download — 179 pages.
Description
Yunnei D20 Series China VI Diesel Engine Service Manual YND20 D20TCIF PDF DOWNLOAD
DESCRIPTION
Yunnei D20 Series China VI Diesel Engine — Official Service Manual (PDF Download)
This is the complete official service manual for the Kunming Yunnei Power Co., Ltd. D20 Series China VI Diesel Engine, model D20TCIF — a modern, electronically controlled, high-pressure common-rail diesel engine built on the proven D19TCI platform in collaboration with FEV. Designed for professional maintenance technicians, diesel mechanics, and authorized Yunnei service stations, this 179-page manual delivers factory-level guidance on every aspect of engine servicing — from assembly and calibration to BOSCH common-rail diagnostics and China VI aftertreatment system maintenance.
The YND20 D20TCIF engine powers the latest generation of light commercial vehicles including pickup trucks and light trucks, meeting the stringent China VI (National VI) emission standards through its integrated DOC + DPF + SCR + ASC aftertreatment system. With real-world testing validated at extreme conditions (+40°C high temperature, 4500m plateau altitude, and -25°C high cold), this engine is built for demanding operating environments.
📋 File Details
| Field | Details |
|---|---|
| Manual Name | Yunnei D20 Series China VI Diesel Engine Service Manual |
| Models Covered | D20TCIF (YND20 / D20 Series) |
| Manufacturer | Kunming Yunnei Power Co., Ltd. |
| Emission Standard | China VI (National VI) |
| Applications | Pickup trucks, light commercial vehicles |
| PDF Quality | High-quality, clean text — fully readable |
| Number of Pages | 179 pages |
| File Format | |
| Language | English |
⚙️ Engine Technical Specifications at a Glance
| Parameter | Specification |
|---|---|
| Model | D20TCIF |
| Engine Type | In-line, 4-cylinder, 4-stroke, water-cooled, supercharged + mid-cooled, high-pressure common rail |
| Displacement | 1.999 L |
| Bore × Stroke | 81 × 97 mm |
| Compression Ratio | 16.2:1 |
| Rated Power / Speed | 93 kW / 3200 rpm |
| Maximum Torque / Speed | 350 N·m / 1600–2500 rpm |
| Low Idling Speed | 800 rpm |
| High Idling Speed | ≤3520 rpm |
| Combustion Chamber | Direct injection |
| Fuel Injection System | BOSCH electronically controlled high-pressure common rail |
| Fuel Injector Model | CRI1-20 (electronically controlled) |
| High-Pressure Fuel Rail | HFR-20 (hot forging rail, 200 MPa rated pressure) |
| High-Pressure Oil Pump | CB4 (common-rail type) |
| Cylinder Firing Order | 1-3-4-2 |
| Lubrication | Pressure-spatter mixing |
| Cooling | Forced circulation, water-cooled |
| Engine Oil Capacity | 5.5 L |
| Aftertreatment System | DOC + DPF + SCR + ASC |
| Emission Standard | China VI |
| Minimum Fuel Consumption | ≤205 g/kW·h |
| Net Weight | 210–250 kg |
| Starting Motor | QDJ2581 (24V / 3.7 kW) |
| Charging Generator | 70A / 28.5V silicon rectifier |
| Thermostat Opening Temp | 78±2°C (full open: 92°C) |
| Accessory Belt | 6PK2660 poly V-belt |
