2002 Chrysler DodgeRs Rg Town Country Caravan And Voyager Service Repair Workshop Manual Download

Description

2002 Chrysler DodgeRs Rg Town Country Caravan And Voyager Service Repair Workshop Manual Download

IMAGE PREVIEW:

sample content from manual

When Monitored and Set Condition:
CABIN HEATER CONTROL CIRCUIT OPEN (STORED)
When Monitored: When the DCHA system is off.
Set Condition: The DCHA Low Side Driver inside the FCM expects to see a system
voltage of 13.8 volts through the DCHA relay coil when the DCHA system is off. This DTC
will set if the FCM sees a voltage below 3.5 volts on the Cabin Heater Assist Control circuit
during this time.

When Monitored and Set Condition:
B1821 COMBUSTION AIR FAN CIRCUIT: OPEN
When Monitored: After DCHA activation, when the system is in a steady state of
operation.
Set Condition: This DTC will set if the DCHA Control detects no-load voltage on the
Combustion Air Fan circuit output pin.
B1821 COMBUSTION AIR FAN CIRCUIT: SHORT TO GROUND
When Monitored: After DCHA activation, when the system is in a steady state of
operation.
Set Condition: This DTC will set if the DCHA Control detects a high current draw on the
Combustion Air Fan circuit output pin.

File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
