2008-2012 Peugeot Vivacity 50 Scooter Shop Manual
FILE DETAILS:
2008-2012 Peugeot Vivacity 50 Scooter Shop Manual
LANGUAGE:ENGLISH
PAGES:52
DOWNLOADABLE:YES
FILE TYPE:PDF
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
2008-2012 Peugeot Vivacity 50 Scooter Shop Manual
The oil pump must be drained in accordance with the recommended procedures. The light comes on when the ignition is turned on to check it is operational and comes off as soon as the engine starts if there is no incident. When starting the engine hot or cold do not accelerate.
TABLE OF CONTENTS:
2008-2012 Peugeot Vivacity 50 Scooter Shop Manual
Table of contents................................................................ 3 Products danger symbols used..................................................... 5 Characteristics.................................................................. 7 Engine....................................................................... 7 Capacities................................................................... 7 Chassis...................................................................... 7 Dimensions and weight........................................................ 8 Tyres........................................................................ 8 Brakes....................................................................... 8 Service schedule and commissioning............................................... 9 To be checked at each service................................................ 9 Service operations........................................................... 9 Time required for maintenance................................................ 9 Battery preparation (Except battery without maintenance)*....................10 Installing the battery vent hose.........................................10 New machine preparation......................................................10 Special important points.........................................................11 Oil and fuel.................................................................11 Starting up after overhauling the engine.....................................11 Tightening torques...............................................................12 Engine part..................................................................12 Body panels..................................................................12 Cycle part...................................................................13 Standard.....................................................................13 Special tools....................................................................14 Location of components...........................................................16 Body panels......................................................................17 Location of body components..................................................17 Body component sequence of disassembly.......................................18 Removal of the rear storage compartment......................................19 Removal of the rear cover assembly and mudflap...............................19 Removal of the front storage compartment.....................................21 Removal of the rear shield panel.............................................21 Removal of the front shield panel............................................22 Removal of the footboard.....................................................23 Removal of the instrument cluster............................................24 Service operations...............................................................25 Removal of the spark plug....................................................25 Replacing the air filter.....................................................25 Front brake pads.............................................................26 Replacing the brake pads.....................................................26 Checking the brake fluid level...............................................27 Rear brake linings...........................................................28 Disassembly..............................................................28 Reassembly...............................................................30 Transmission.................................................................31 Checking the drive belt......................................................33 Checking the clutch linings..................................................33 Replacing the clutch lining assembly.........................................34 Removal of the fuel filter...................................................35 Miscellaneous operations.........................................................36 Removal of the fork..........................................................36 Replacing the bearings of the steering system................................36 Reassembly...............................................................37 Steering system tightening method............................................38 Removal of the fuel pump.....................................................40 Removal of the fuel gauge....................................................40 Removal of the fuel tank.....................................................40 Removal of the carburettor...................................................42 Remove the valve.........................................................42 Removal of the float, needle valve and jets..............................43 Removal of the engine speed adjuster screw and mixture control screw.....44 Reassembly...................................................................45 Removal of the power unit....................................................47
