2017 Yamaha FZN250 (FZ-25) Motorcycle Service Manual

2017 Yamaha FZN250 (FZ-25) Motorcycle Service Manual

Publication Part No. B97-F8197-E0
Produced by India Yamaha Motor Pvt. Ltd.

The 2017 Yamaha FZN250 (FZ-25) Motorcycle Service Manual is a comprehensive technical workshop reference designed for professional mechanics and dedicated motorcycle owners. Whether you’re performing routine periodic servicing, troubleshooting advanced electronic fuel injection faults, rebuilding the 249 cm³ SOHC engine, or conducting full suspension and hydraulic disc brake overhauls, this definitive service manual provides precise step-by-step instructions, exploded assembly diagrams, factory tolerances, and accurate torque specifications.

File Details

• Manual Type: Factory Service Manual / Workshop Manual
• Brand: Yamaha (India Yamaha Motor Pvt. Ltd.)
• Model: FZN250 / FZ-25 (Model Code: B971)
• Model Year: 2017
• Document / Part Number: B97-F8197-E0
• Edition / Revision: First Edition, February 2017
• Language: English
• Page Count: 310+ pages
• File Format: PDF Download

Chapters Covered

Chapter 1: General Information

Vehicle Identification Number (Frame No.) and Engine Serial Number locations; Features and Outline of the FI System; Multi-Function Display operations and self-diagnosis mode; Important service rules, replacement parts, gaskets, seals, and circlips; Basic service information, quick fasteners, and electrical system handling precautions; Complete specialized workshop tools list.

Chapter 2: Specifications

General specifications (dimensions, curb weight, load limits); Maintenance specifications for engine, chassis, and electrical systems; General and component-specific tightening torques; Lubrication points, lubricant grades (Yamalube 10W-40 API SL / JASO MA), and lubrication system diagrams; Cable, wire harness, and hose routing diagrams.

Chapter 3: Periodic Checks and Adjustments

Periodic maintenance and lubrication schedule for emission control and chassis; Valve clearance inspection and adjustment (cold: intake 0.05–0.10 mm, exhaust 0.08–0.13 mm); Engine idling speed adjustment (1300–1500 r/min) and CO density volume setting; Spark plug inspection (NGK DR8EA) and cylinder compression testing (1044–1344 kPa); Engine oil and oil filter element replacement; Clutch lever and throttle grip free play adjustments; Hydraulic brake pad inspection, fluid renewal (DOT 4), and system bleeding; Drive chain slack adjustment (40–45 mm) and alignment; Front fork, steering head bearing preload, and rear shock absorber preload adjustment.

Chapter 4: Chassis

General chassis cowling, side covers, and seat removal; Front and rear wheel removal, bearing inspection, oil seal replacement, and static balancing; Hydraulic front brake (282 mm single disc) and rear brake (220 mm disc) caliper overhaul, pad replacement, master cylinder rebuild, and hose installation; Handlebar removal and installation; Front fork leg disassembly, damper rod servicing, bushing replacement, and oil level setting (469 cm³ G10 oil); Steering head bearing inspection and lower bracket overhaul; Rear shock absorber assembly removal and inspection; Swingarm removal, bearing depth installation, and pivot shaft servicing; Drive chain and sprocket inspection and replacement.

Chapter 5: Engine

Complete engine removal and chassis installation; Cylinder head disassembly, valve timing alignment, warpage limits (0.05 mm), and timing chain tensioner servicing; Camshaft and rocker arm shaft inspection; Valve removal, valve guide clearance, seat contact width, spring tilt/free length inspection, and valve lapping; Cylinder block inspection, piston skirt clearance, piston pin bore, and ring end gaps; AC Magneto rotor and starter clutch removal and installation; Starter motor disassembly and brush wear limits; Wet multi-plate clutch overhaul, friction plate thickness, clutch spring free length, and push rod adjustment; Engine oil pump, oil strainer, and external oil cooler assembly; Shift shaft, stopper lever, and shift drum segment; Balancer drive and driven gear timing and installation; Crankcase splitting and bearing replacement; Crankshaft runout and installation; 5-speed constant-mesh transmission disassembly, gear dog inspection, and shift fork assembly.

Chapter 6: Fuel System

Fuel tank removal and installation; Fuel pump assembly removal, filter inspection, and operating pressure check (220–300 kPa at idle); Fuel injector resistance (12.2 Ω) and throttle body joint assembly; Fuel line inspection and canister evaporative emission system.

Chapter 7: Electrical System

TCI ignition system circuit diagram, ignition coil resistance, and troubleshooting; Electric starting system, starter circuit cut-off system, and starter motor; Charging system, AC magneto stator coil resistance (0.456–0.684 Ω), and rectifier/regulator testing; Headlight, LED meter lighting, auxiliary light, and turn signal circuits; Electronic Fuel Injection (FI) circuit diagrams, ECU self-diagnostic function, error codes, and Yamaha Diagnostic Tool operation; Switches, relays, sensors (crankshaft position, intake air temp, engine temp, O2, lean angle), and fuse ratings.

Chapter 8: Troubleshooting

Systematic diagnostic tables and troubleshooting flowcharts covering starting failures, poor idling, poor engine performance, gear shifting issues, overheating, faulty braking, and electrical malfunctions.

Together, these chapters equip service technicians with complete, factory-approved procedures for overhauling every mechanical, hydraulic, and electrical system on the Yamaha FZ-25 / FZN250, ensuring repairs are completed strictly according to original equipment standards.

Comprehensive Engine, Fuel Injection & Chassis Technical Coverage

The 2017 Yamaha FZN250 (FZ-25) Motorcycle Service Manual provides in-depth technical procedures for every major assembly. The engine section guides you through teardown and reassembly of the 249 cm³ 4-stroke air-cooled single-cylinder powertrain, detailing critical clearances such as cylinder bore (74.000–74.016 mm), piston skirt diameter (73.983–73.998 mm), and piston-to-cylinder clearance (0.010–0.025 mm). The fuel injection section outlines pressure testing with the inline gauge adapter, fast idle device operation, injector testing, and ECU error code diagnosis using the dedicated Yamaha Diagnostic Tool (INS-018 / INS-019). Detailed chassis instructions cover front fork damper rod servicing, front and rear disc brake caliper rebuilds with piston seal replacement schedules, wheel bearing installation depths, and complete wiring schematics with color coding and routing paths.

Professional Capability, Precision & Instant Delivery

Owning this 2017 Yamaha FZN250 FZ-25 workshop manual eliminates guesswork from maintenance and repair jobs. With genuine factory torque values — such as 33 N·m for cylinder head bolts, 60 N·m for the camshaft sprocket bolt, 75 N·m for the clutch boss nut, and 110 N·m for the steering stem nut — you can prevent stripped threads, oil leaks, component failure, and unsafe riding conditions. Available as an instant digital PDF download, this manual is delivered immediately upon purchase with no shipping delays. Store it conveniently on your smartphone, tablet, laptop, or workshop computer, or print specific pages and diagrams directly for hands-on bench work.
