ALLIS CHALMERS CRAWLER TRACTOR H4 HD4 PART MANUAL PM 1012402 – PDF DOWNLOAD
DESCRIPTION:
ALLIS CHALMERS CRAWLER TRACTOR H4 HD4 PART MANUAL PM 1012402 – PDF DOWNLOAD
FOREWORD
The parts in this catalog are listed in alphabetical order and are located at the front of this catalog. Except for some common hardware all parts are identified with an item number. Common hardware not identified such as bolts, nuts, cotter pins and lubrication fittings, are listed in the text under the part which they attach or fit into.
- Note particularly that the quantity of hardware listed is always the quantity required for one part. Common attaching hardware listed under a part is not included in the assembly or included with the part unless specified. Example: (Incl. Bolt, Lockwasher and Nut).
- Assembly or Packaged Parts”indicates if an individual part is one of many in a large assembly or one of several kinds in a package. All numbers are listed in the second last section of this catalog showing the quantity and description of the various parts that make up the assembly or package.
- The last section of this catalog contains a part number index to indicate on which page or pages a part number appears.
- All illustrations will be found to Follow the text of each group or section of which it is a part. For any additional copies of this catalog there will be a supplementing service charge of three dollars. Refer any requests to your Branch House or office under which you operate.
HOW TO ORDER PARTS
Order all parts for this machine from your local ALLISCHALMERS Dealer.
When ordering parts for this unit, supply the following information:
- The tractor and engine serial numbers
- Fork Lift serial number. The Fork Lift serial number is located on the R.H. side of frame over final drive housing near brake pedals. The Mast Serial number is located on inside of the bottom channel iron of mast assembly.
- State the common name of the part you Wish to order, or a description of the part and its location on the unit, or bring in old part
- Always print your name and post office address, where parts are to be shipped; also specify whether material is to be shipped by freight, express or parcel post. 5. When ordering parts always determine right hand and left hand from a position in the operators seat facing the direction of forward travel.
IMPORTANT
- Unless claims for shortages or errors are made immediately upon receipt of goods, they will not be considered. When broken goods are received, a full description of the damage should be made by the carrier agent on the freight bill. If this description is insisted upon full damage can always be collected from the transportation company.
- No responsibility is assumed for delay or damage to merchandise while in transit. Our responsibility ceases upon delivery of shipment to the transportation company, from whom a receipt is received showing that shipment was in good condition when delivered to them; therefore claims (if any) should be filed with the transportation company and not with Allis-Chalmers Manufacturing Company.
- The right is reserved to change the construction or material of any parts where it seems desirable to do so, without incurring -the obligation of installing such changes on units already delivered.
TABLE OF CONTENTS:
ALLIS CHALMERS CRAWLER TRACTOR H4 HD4 PART MANUAL PM 1012402 – PDF DOWNLOAD
ADAPTOR PLATE
Diesel
Gasoline
AIR CLEANER
Diesel
Gasoline
AIR CLEANER HOSES
Diesel
Gasoline
AIR FILTER INDICATOR
AIR HEATER, diesel
ASSEMBLIES & PACKAGE PARTS thru
AXLE, final drive
BATTERY GROUP
Diesel
Gasoline
BRAKE BAND & ARM
BRAKE LINKAGE
BRAKE PEDALS & LINKAGE
CARBURETOR, gasoline
CARBURETOR COMPONENTS, gasoline
CLUTCH SHIFTER
CONNECTING ROD
Diesel
Gasoline
CONSOLE SHELL & SHUTTLE CLUTCH CONTROL
CONTROL VALVES ,
End Sections
Main Relief
Section, valve (A)
Section, valve (D)
Section, valve (E)
Section, valve (F)
Section, valve (J)
C RA NKSHA FT
Diesel
Gasoline
CYLINDER BLOCK
Diesel ,
Gasoline ,
CYLINDER HEAD
Diesel
Gasoline
DECELERATOR
DISTRIBUTOR, gasoline
DIVERTER
Hydraulic Group, & Backhoe
Valve, & Backhoe
DRAWBAR
DRIVE SHAFT & RING GEAR
ETHER STARTING SYSTEM, diesel
EXHAUST MANIFOLD
Diesel
Gasoline
FAN DRIVE SHAFT
FINAL DRIVE HOUSING
FLYWHEEL
Diesel
Gasoline
FRONT PLATE
Diesel
Gasoline
FUEL FILTER, diesel
FUEL INJECTION PUMP, dies el
FUEL PUMP, gasoline
FUEL TANK
Diesel
Gasoline
FUEL TANK FILTER
Diesel
Gasoline
GEAR COVER
Diesel
Gasoline
GENERATOR
GENERATOR ASSEMBLY
GOVERNOR, gasoline
HAND BRAKE CONTROLS, steering clutch
HAND PRIMER PUMP ASSEMBLY, diesel
HEAD LAMPS
HITCH, Point
Lift Arm Hydraulic Ram
Lift Bars
Lift Links & Beaming Tube
Lift Shaft & Supports
HOLLOW CLUTCH SHAFT
HOOD, SHELL, GRILLE, MUFFLER & EXTENSION
HOOK, pull
HOUR METER
HYDRAULIC HOUSING & GEAR
Diesel
Gasoline
HYDRAULIC OIL FILTER, front
HYDRAULIC PUMP
HYDRAULIC SYSTEM
IDLER GEAR ASSEMBLY, diesel
IDLER PULLEY
Diesel
Gasoline
IDLER SHAFT & GEARS, standard
IDLER SHAFT & GEARS, w/winch
IGNITION, gasoline
INDEX, numerical
INJECTION LINES, diesel
INJECTION PUMP COMPONENTS, diesel
Housing & Drive
Transfer Pump, Head & Rotor
INSTRUMENT PANEL
INTAKE MANIFOLD
Diesel
Gasoline
INTERMEDIATE SHAFT & GEAR
MAIN FRAME & ENGINE SUPPORT
NOZZLE HOLDER, diesel
NOZZLE HOLDER ASSEMBLY, diesel
OIL FILTER
Diesel
Gasoline
OIL PAN
Diesel
Gasoline
OIL PUMP
Diesel
Gasoline
OPERATORS SEAT, standard & Backhoe
PAN, rear bottom
PAN GUARD, rock & bottom
PINION SHAFT
PISTON
Diesel
Gasoline
PLATFORM ,
POWER SHUTTLE CLUTCH
PUMP & MANIFOLD, rear
RADIATOR, HOSES & SUPPORT ,
RADIO
RESERVOIR FILTER
RESERVOIR HYDRAULIC OIL
RESERVOIR OIL STRAINER & MAGNET
SHUTTLE CLUTCH & OIL COOLER LINES ,
SHUTTLE CLUTCH & SUMP LINES ,
SHUTTLE CLUTCH INTERNAL LINES
SHUTTLE CLUTCH VALVE
SUPPORT ROLLER
SPROCKET, final drive
STARTING MOTOR
Diesel ,
Gasoline ,
STEERING CLUTCH
TACH-HOUR METER & DRIVE.
THERMOSTAT & HOUSING
Diesel
Gasoline
TORQUE CONVERTER
TORQUE HOUSING
TURBINE INPUT SHAFT
TRACK ,
TRACK IDLER
TRACK RELEASE
TRANSMISSION
Gear Shift
Housing
Mainshaft
Pinion Shaft
TRUCK FRAME
TRUCK WHEEL
UNIVERSAL CARRIER W/TIE BRACES
Dozer, H-
Dozer, &
Loader, H-
VALVE OPERATING MECHANISM
Diesel
Gasoline
WATER PUMP
Diesel
Gasoline
WEIGHT BRACKET GROUP
WEIGHT CARRIER GROUP , w/universal carrier
WINCH DRIVE, front shaft & housing
WINCH DRIVE SHAFT, rear
WINCH SHIFTER
