Audi A6 2005 2.0 Ltr 4-Cylinder TDI Unit Injector Engine Workshop Manual BLB BNA BRE BRF BVG

Description

Audi A6 2005 2.0 Ltr 4-Cylinder TDI Unit Injector Engine Workshop Manual BLB BNA BRE BRF BVG

This workshop manual covers the mechanical repair and service information for the Audi A6 2005 ➤ fitted with the 4-cylinder TDI unit injector engine (2.0 ltr. 4-valve). It applies to engine IDs BLB, BNA, BRE, BRF and BVG, with Edition 04.2015. The manual is organised by Audi repair groups and takes the technician from basic engine identification and technical data through major mechanical dismantling, installation, measurement and system repair work.

The Audi A6 2005 2.0 Ltr 4-Cylinder TDI Unit Injector Engine Workshop Manual BLB BNA BRE BRF BVG is especially useful for jobs that require more than a general overview. Procedures include removal of the engine from the vehicle, timing-belt and valve-timing work, crankshaft and piston service, cylinder-head removal, camshaft and valve-gear work, oil-pump and balance-shaft repairs, cooling-system service, turbocharger and charge-air work, and exhaust repairs for vehicles both with and without a particulate filter.

File Details

• Manual type: Workshop Manual
• Brand/model: Audi A6 2005 ➤
• Engine: 4-cylinder TDI unit injector engine (2.0 ltr. 4-valve), mechanics
• Engine IDs: BLB, BNA, BRE, BRF, BVG
• Edition: 04.2015
• Language: English
• Page count: 258 pages
• File format: PDF

Engine and Technical Coverage

The technical-data section identifies the covered engines and provides their core engine data. The manual lists a capacity of 1.968 ltr. for BLB, BNA, BRE, BRF and BVG. Power output is shown as 103/4000 kW/rpm for BLB, 100/4000 for BNA, 103/4000 for BRE, 100/4000 for BRF and 89/4000 for BVG. All five are listed with 320/1750 … 2500 Nm/rpm torque, 81.0 mm bore, 95.5 mm stroke, 18.5 compression ratio and firing order 1-3-4-2. The engine data also distinguishes particulate-filter applications: BLB and BNA are shown without a particulate filter, while BRE, BRF and BVG are shown with one.

Mechanical service data is integrated into the relevant procedures rather than separated from the repair work. The manual includes tightening torques, wear limits, clearances, dimensional checks and installation sequences where required. Examples include crankshaft axial and radial clearance, piston-ring gaps and ring-to-groove clearances, piston projection for cylinder-head-gasket selection, piston and cylinder dimensions, cylinder-head distortion, camshaft axial clearance, valve dimensions and valve-guide checks.

IMAGES PREVIEW

Chapters Covered

• 00 – Technical data
  • Engine number
  • Engine data
  • Safety precautions
  • General repair instructions
• 10 – Removing and installing engine
  • Removing and installing engine
  • Securing engine to assembly stand
  • Assembly mountings
  • Removing and installing torque reaction support and torque reaction stop
• 13 – Crankshaft group
  • Dismantling and assembling engine
  • Servicing work on pulley end
  • Poly V-belt drive, tensioner and vibration damper
  • Toothed belt drive and valve timing
  • Removing and installing sealing flanges and flywheel
  • Removing and installing crankshaft
  • Crankshaft dimensions
  • Converting balance shaft assembly to spur gear drive
  • Dismantling and assembling pistons and conrods
  • Checking piston projection at TDC
  • Piston and cylinder dimensions
  • Measuring radial clearance of conrods
• 15 – Cylinder head, valve gear
  • Handling glow plugs
  • Removing and installing cylinder head
  • Checking compression
  • Servicing valve gear
  • Checking axial clearance of camshafts
  • Renewing camshaft oil seals
  • Removing and installing camshafts
  • Removing and installing roller rocker fingers
  • Renewing valve stem oil seals
  • Checking hydraulic tappets
  • Valve dimensions and valve-guide checks
• 17 – Lubrication
  • Servicing sump, oil pump and balance shaft assembly with chain drive
  • Servicing sump, oil pump and balance shaft assembly with spur gear drive
  • Servicing oil filter bracket with oil cooler
  • Checking oil pressure and oil pressure switch
  • Engine oil and checking oil level
• 19 – Cooling
  • Removing and installing parts of cooling system
  • Draining and filling cooling system
  • Removing and installing coolant pump
  • Removing, installing and checking thermostat
  • Removing and installing coolant pipes
  • Removing and installing radiator, radiator cowl and radiator fan
  • Checking cooling system for leaks
• 21 – Turbocharging/supercharging
  • Servicing charge air system with turbocharger
  • Removing and installing turbocharger
  • Charge air cooling
  • Removing and installing charge air cooler
  • Removing and installing charge pressure sender G31 / intake air temperature sender G42
  • Checking charge air system for leaks
• 26 – Exhaust system
  • Exhaust system for vehicles without particulate filter
  • Exhaust system for vehicles with particulate filter
  • Removing and installing particulate filter
  • Removing and installing exhaust manifold
  • Removing and installing exhaust gas temperature senders G235, G506 and G527
  • Exhaust gas recirculation system
  • Removing and installing exhaust gas recirculation cooler

Together, these repair groups make the manual a broad mechanical reference for the covered Audi A6 2.0 ltr. TDI unit injector engines. It combines illustrated removal and installation sequences with exploded views, tool references, cautions, tightening information and measurement procedures, so the technician can follow the mechanical relationships between the crankshaft, timing system, cylinder head, lubrication circuit, cooling system, turbocharger and exhaust components.

Detailed Repair Procedures and Illustrated Component Views

Many repair operations are supported by component drawings and step-by-step illustrations. The engine-removal section shows vehicle preparation, cooling and fuel connections, electrical connectors, engine and gearbox fasteners, supports, lifting equipment and the upward removal of the engine without the gearbox. Installation notes address renewed fasteners and seals, gearbox-specific details for manual and multitronic applications, tightening torques and final checks.

The crankshaft group goes deep into the timing and rotating assembly. It covers the poly V-belt and tensioner, vibration damper, toothed-belt removal and installation, TDC positioning and valve-timing adjustment. It also includes front and rear sealing flanges, flywheel and dual-mass flywheel work, crankshaft inspection, bearing clearances, piston and conrod service, and the balance-shaft drive. For engines requiring the change from a worn chain drive to a spur-gear drive, the manual gives the removal and shrink-fitting procedure, including the specified heating range and installation precautions.

Cylinder-head and valve-gear coverage includes the differences between metal and NGK ceramic glow plugs, cylinder-head removal and installation, gasket identification, compression checking, camshaft removal, rocker-finger service, valve-stem seals and hydraulic tappets. The manual identifies BLB and BNA as using metal glow plugs, while BRE, BRF and BVG use NGK ceramic glow plugs, with specific handling cautions for the ceramic type.

Lubrication, cooling, turbocharging and exhaust sections extend the repair coverage beyond the long block. The oil-system material covers sump removal, oil pumps, chain-drive and spur-gear balance-shaft assemblies, oil filter bracket and oil cooler, oil-pressure checks and oil level. Cooling procedures cover draining and filling, coolant pump, thermostat, pipes, radiator and leak checks. Turbocharger and charge-air sections cover turbo removal, charge-air cooler work, sender removal and leak checking. Exhaust coverage separates vehicles with and without a particulate filter and includes front pipes, catalytic converter-related work, particulate-filter removal, exhaust manifold, temperature senders and the exhaust-gas-recirculation cooler.

Repair the Covered Audi A6 2.0 TDI Engine with the Correct Procedures

The Audi A6 2005 2.0 Ltr 4-Cylinder TDI Unit Injector Engine Workshop Manual BLB BNA BRE BRF BVG gives owners and technicians the procedures and service data needed for substantial mechanical work on the covered engines, from timing and cylinder-head repairs to crankshaft, lubrication, cooling, turbocharger and exhaust-system jobs. Using the documented sequences, measurements, tightening values and special-tool references helps avoid guesswork during dismantling, inspection and reassembly.

After payment, the manual is delivered instantly as a PDF download. There is no shipping delay or physical book to wait for: open it on a computer, tablet or phone, keep it available at the workshop, and print the pages you need for the job.
