Canon Inner Finisher-B1 & Additional Tray-B1 Service Manual PDF

Description

Canon Inner Finisher-B1 & Additional Tray-B1 Service Manual PDF DOWNLOAD

Description

This genuine Canon Service Manual is the complete technical reference for servicing the Inner Finisher-B1 and Inner Finisher Additional Tray-B1. It is designed for professional technicians and service engineers who need precise instructions for installation, maintenance, troubleshooting, and part replacement.

Dated March 5, 2010 (Revision 0), this manual explains both the mechanical and electronic operation of the finisher system, including stacking, offset, and stapling mechanisms.

🔧 What This Manual Covers

🔹 Safety & Service Rules

• Safety precautions and servicing notes

• Symbols and service conventions

• Power handling and download warnings

🔹 Product Overview

• Features & specifications

• External views & cross-section diagrams

• Identification of all major parts

🔹 Technology & Operation

• Basic configuration

• Non-sort stacking operation

• Offset stacking operation

• Stapling operation (corner & double stapling)

• Paper flow and mechanism timing

🔹 Work of Service

• Scheduled servicing intervals

• Customer maintenance procedures

• Offset roller cleaning

• Firmware & version upgrade

• Using the Downloader PCB (FY9-2034)

🔹 Periodic Servicing

• Service life of consumables

• Replacement schedules

• Counter references

🔹 Parts Replacement & Cleaning

Neatly organized, step-by-step procedures for:

• Motors, switches, solenoids

• Sensors (Entrance, shift, tray, stapler, etc.)

• PCBs (Controller PCB, Additional Tray PCB, Broadcast PCB)

• Main units (Upper unit, Gripper unit)

• Consumables:

  • Stapler unit

  • Offset roller

  • Shutter unit

  • Paper retainers (front & rear)

• Detailed illustrations for every removal and reinstallation

🔹 Adjustments & Service Modes

• EEPROM initialization

• Shift roller adjustment

• Stapling position calibration

• Operation and service modes using board switches

🔹 Installation Guides

• Inner Finisher-B1 installation

• Additional Tray-B1 installation

• Pre-installation checks

• Bundled parts verification

• Host machine connection

🔹 Appendix

• Service tools

• Solvents & oils

• Special tools

• General circuit diagrams

📊 File Details

🚀 Why Buy This Manual?

If you service Canon finishing units, this manual saves hours of guesswork. Every sensor, motor, PCB, and mechanism is clearly documented with diagrams and exact procedures—so you can diagnose, repair, and calibrate with confidence.

Download instantly and start fixing today—no delays, no confusion, just the exact factory guide professionals rely on.
