This is the official Canon factory Service Manual for the imagePROGRAF iPF750, iPF755, iPF760, and iPF765 large-format printers.

Issued by Canon for qualified service personnel, this manual provides complete technical service documentation required to install, maintain, diagnose, adjust, and repair these 36-inch large-format inkjet printers. It explains the relationship between mechanical drive systems, electrical control signals, firmware logic, and print operation timing, exactly as used in Canon service training.

The manual includes detailed disassembly procedures, service mode operations, adjustment sequences, error code tables, wiring diagrams, and PCB pin layouts, making it the authoritative reference for professional printer repair.

🖨 Models Covered

• Canon imagePROGRAF iPF750

• Canon imagePROGRAF iPF755

• Canon imagePROGRAF iPF760

• Canon imagePROGRAF iPF765

Maximum print width: 36 inches (A0 size)
Printer type: Large-format bubble jet inkjet printer

🧩 Main Contents & Sections

🔹 Chapter 1 – Product Description

• Product overview & features

• Printhead (PF-04) structure

• Ink tanks (PFI-102 / PFI-104)

• Cutter unit & roll holder

• Stand options (ST-33 / ST-34)

• Hard disk drive functions

• Consumables

• Detailed product specifications

• Component names & functions

• Operation panel & menu system

• Safety precautions & service warnings

🔹 Chapter 2 – Technical Reference

• Printer operation outline

• Print signal sequence & timing

• Firmware operation (power-on / power-off)

• Head management & overheating protection

• Mechanical systems:

  • Ink passage system

  • Carriage unit

  • Purge & maintenance unit

  • Paper path & cutter

• Electrical systems:

  • Main controller PCB

  • Carriage relay PCB

  • Power supply

• Sensor detection logic

🔹 Chapter 3 – Installation

• Transporting the printer

• Re-installation procedures

• Handling precautions

🔹 Chapter 4 – Disassembly & Reassembly

• External covers

• Drive unit

• Cutter unit

• Carriage unit

• Purge unit

• Ink tank & ink tube units

• Waste ink collection system

• Sensors & encoders

• PCB removal & replacement

• Grease application points

• Adjustment & setup after parts replacement

🔹 Chapter 5 – Maintenance

• Periodic replacement parts

• Consumables

• Scheduled maintenance procedures

🔹 Chapter 6 – Troubleshooting

• Troubleshooting flow

• Connector locations

• PCB pin arrangements

• Firmware version updates

• Canon service tools

🔹 Chapter 7 – Service Mode

• Entering service mode

• Service mode maps

• Detailed service mode functions

• Special service modes

• e-Maintenance / imageWARE Remote

• Viewing internal print information

🔹 Chapter 8 – Error Codes

• Warning tables

• Error code tables

• Service call error definitionS

📄 File Details

Service your Canon imagePROGRAF printer with factory-level accuracy—this official Canon service manual delivers complete diagnostics, repair procedures, and error code guidance in one instant download.
