Canon MultiPass MP390 / MP370 / MP360 Service Manual – PDF

Description

Canon MultiPass MP390 / MP370 / MP360 Service Manual – Repair & Maintenance PDF DOWNLOAD

Description

Product Overview Maximize the lifespan of your multifunction printer with the complete Canon MultiPass / SmartBase MP390 Service Manual. This technical reference guide is indispensable for service centers and advanced DIY repair technicians. It covers the full range of the MP300 series, including the MP360, MP370, and MP390 models.

Whether you are dealing with paper feed issues, scanner malfunctions, or need to perform a Canon MP390 waste ink absorber reset, this manual provides step-by-step logic. It details the specific SmartBase MP390 service mode settings required to initialize the EEPROM and configure destination settings.

Key Features:

• Comprehensive Disassembly: detailed instructions for removing external parts, the scanner unit, the printer unit, and the ADF (Automatic Document Feeder).

• Diagnostics: Extensive charts for troubleshooting Canon MP370 error codes and MP390 alarm indications.

• Maintenance Mode: Full explanation of service mode operations, including print count checks, cleaning modes, and EEPROM initialization.

• Technical Specifications: Detailed specs for the ink system, scanner resolution, and interface signals.

Table of Contents & Categorized Index:

Part 1: Maintenance

• Adjustment:

  • Canon MP390 print head alignment

  • Grease Application Points

• Cleaning:

  • Cleaning the Roller

  • Cleaning the Bottom Plate

Part 2: Technical Reference

• New Technologies:

  • Borderless Printing

  • Exif Print Support

• Cleaning Mode:

  • Cleaning / Deep Cleaning / Refreshing

• Specifications:

  • Printer & Scanner Specifications

  • Interface Specifications (USB)

Part 3: Disassembly & Reassembly

• External Parts: Covers and Panels

• Main Unit:

  • Scanner Unit Removal

  • Printer Unit Removal

  • Power Supply Unit

  • Logic Board

• ADF Unit: Disassembly of the Feeder (MP390 specific)

• Wiring: Arrangement and Connection Points

Part 4: Maintenance Mode

• Service Mode Operations:

  • EEPROM Information Print

  • Canon MP390 waste ink absorber reset (Waste Ink Counter Reset)

  • Destination Settings

  • Button & LCD Tests

Part 5: Troubleshooting

• Error Display:

  • Operator Call Errors (LED/LCD codes)

  • Service Call Errors (Cyclic blinking)

• Diagnosis:

  • Paper Feed Problems

  • Scanning Image Defects

  • Printing Defects

Part 6: Appendix

• Block Diagrams

• Connector Layouts

• Circuit Diagrams

File Details

• Manual Name: Canon MultiPass MP390 / SmartBase MP390 Service Manual

• Models Covered:

  • Canon MultiPass MP390, MP370, MP360

  • Canon SmartBase MP390, MP370, MP360

• Year: 2003 (Rev. 0)

• File Type: High-Quality PDF (Text Searchable, Vector Images)

• No. of Pages: 149 Pages
