DESCRIPTION

CAT Dragline 2570W Care Walking Draglines Operation & Maintenance Manual – PDF DOWNLOAD

INTRODUCTION

MANUAL PURPOSE AND CONTENT

• This manual has been developed to instruct mining personnel in the care, maintenance and operation of a Model 2S70-W dragline. Every effort has been made to make this manual as complete as possible at·
• the time of printing. However, Bucyrus-Erie Company reserves the right to continually improve its products. Therefore, alterations to the equipment may not be reflected in the current manual.
• When alterations take place that affect manual substance, Bucyrus-Erie Company will make every attempt to update and distribute service information as soon as possible.

The present manual is divided into four major sections. Pages are numbered within each particular section. For example, page 2-4 is the fourth page of Section 2. Each section is prefaced with a table of contents which is found on the first page of the section. With the exception of Section 4, each section is generously illustrated to support and clarify text coverage of the equipment and service procedures.

TABLE OF CONTENTS:

CAT Dragline 2570W Care Walking Draglines Operation & Maintenance Manual – PDF DOWNLOAD

INTRODUCTION
Manual Purpose and Content
GENERAL DESCRIPTION
Function of the Machine :
Major Machine Units
COMPONENT DESCRIPTION
Base
Revolving Frame
Main Machinery
Hoist Machinery
Drag Machinery
Swing Machinery
Propel Machinery
Motor-Generators and Exciters
A-Frame
Lubrication Systems
Machinery House
Cabs
Mast
Boom
Drag Fairlead
Drag Rope Supports and Dirt Deflectors
Wire Ropes and Structural Strands ;
Dragline Bucket
GLOSSARY OF TERMS
