ERECTING INSTRUCTIONS FOR MARION 7800

• These instructions have been prepared to aid in erecting a MARION 7800 WLE Walking Dragline; a guide for the operator, the groundman, and the oiler in their operation maintenance and lubrication. The engineering drawings which   the machine give the exact location of all parts.
• all necessary dimensions, etc. It is very important that extreme care be taken in assembly because improper erection may cause unnecessary wear and faulty operation of the machine. When the machine is shipped from the factory. the part match marked throughout.
• Care should be taken to follow these match marks when the machine is assembled. All finished surfaces and bearings are protected against corrosion and should be thoroughly cleaned just before assembly.
• When assembling. all bearings should be lubricated. Ball and roller bearings are to be filled only 1/2 full of the proper . Also lubricate all gears and put the proper oil in gear cases up to the correct level before the machme is run.
• All air and electrical equipment, bearings and finished surfaces should be protected from the weather until the machine is fully assembled.

TABLE OF CONTENTS:

CAT Dragline Marion 7800 Operation & Maintenance Instruction Manual – PDF DOWNLOAD

Erection instructions
Adjustments
Operating instructions
Lubrication instructions
Wire Rope Reeving
Electrical instructions
Appendix
