Epson Action Printer 4000 Users Manual – PDF DOWNLOAD

Introduction Features
Options
About This Manual
Application Notes
Where to Get Help.
Chapter 1 Setting Up the Printer
Unpacking the Printer.
Assembling the Printer
Testing the Printer..
Choosing a Place for the Printer
Connecting the Printer to Your Computer
Setting Up Your Application Software
Chapter 2 Paper Handling
Using Continuous Paper
Using Single Sheets
Switching Between Continuous and Single Sheets
Printing on Special Paper
Chapter 3 Using the Printer
Operating the Control Panel
Setting the DIP Switches.
Page Length
Skip Over Perforation
Adjusting the Loading Position.
Using Short Tear-Off.
Selecting Typestyles
Selecting an International Character Set
Choosing a Character Table
Using the Data Dump Mode
Chapter 4 Software and Graphics
Enhancing Your Printing
Graphics
User-defined Characters.

Chapter 5 Using the Printer Options
The Cut Sheet Feeder..
The Pull Tractor
The Multi-Font Module
The Interface Boards
Chapter 6 Maintenance
Cleaning the Printer
Replacing the Ribbon
Transporting the Printer.
Chapter 7 Troubleshooting
Problems and Solutions
Power Supply
Printing
Paper Handling..
Options..
Chapter 8 Technical Specifications
Printer Specifications.
Interface Specifications
Option Specifications Initialization
Chapter 9 Command Summary Using the Command Summary.

Commands in Numerical Order Commands Arranged by Topic.
Appendix
Proportional Width Table. Character Table

1. Read all of these instructions and save them for later reference.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water.

5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built in installation unless proper ventilation is provided.

7. This product should be operated from the type of power source indicated on the marking label. If you are not sure of the type of power available, consult your dealer or local power company.

8. This product is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding type plug.

9. Do not locate this product where the cord will be walked on.

• Easy paper handling, featuring automatic single-sheet loading.

• Compatibility with the Epson ESC/P® commands used by the LQ-510, LQ-500, LQ-800, LQ-850, LQ-950, LQ-1000, LQ-1050, LQ-1500, LQ-2500, and LQ-2550. • Fast draft mode printing of up to 180 characters per second.

• An improved control panel design that allows direct selection of character fonts, as well as a choice of normal or condensed printing.

• The Smart Park paper handling system that lets you use single sheets of paper without removing the continuous paper, eliminates paper waste with short tear-off, and allows easy accurate paper alignment.

• Two built-in Letter Quality fonts (Roman and Sans Serif) for producing high-quality documents.

• A 360 x 360 dot per inch graphics mode. · and A micro-adjustment feature that allows you to feed the paper forward or backward to finely adjust the loading and short tear- off positions.
