FIAT ALLIS 100C MOTOR GRADER PARTS MANUAL – PDF DOWNLOAD
DESCRIPTION:
FIAT ALLIS 100C MOTOR GRADER PARTS MANUAL – PDF DOWNLOAD
IMPORTANT
All parts listed herein, which have no specific usage indicated, are applicable to all models. Those parts which are used only on specific models are so indicated.
- Attaching parts such as bolts, nuts, rivets, screws, washers, etc., are indented immediately following the parts which they attach.
- Parts indicated with a square (o) are also available in packaged sets. Refer to section titled “PACKAGED PARTS”.
- The terms “right” and “left” used throughout this parts catalog are determined by facing the direction of forward travel.
- The engine is mounted unconventionally with the flywheel toward the front of the machine, but all engine parts are designated in respect to the engine as it would be installed in a conventional machine with the flywheel to the rear.
INSTRUCTIONS FOR ORDERING PARTS
Order parts from the dealer covering the local territory.
ALWAYS GIVE THE MODEL AND SERIAL NUMBER OF MACHINE. IF PARTS ARE FOR AN ASSEMBLY WHICH HAS A MODEL AND/OR SERIAL NUMBER (SUCH AS ENGINE ASSEMBLY, PUMP ASSEMBLY), ALSO INCLUDE THIS INFORMATION.
- To obtain parts promptly, give part name and part number.
- Give post office address, town, county and state where parts are to be shipped. Also specify whether material is to be shipped by freight, express or parcel post.
- Confirm all telephone or telegraph orders in writing.
- Parts for standard motor accessories such as generators and starting motors should be ordered from authorized Service Stations maintained by manufacturers of these units throughout the country.
- No credit will be allowed on parts unless they are returned to the dealer from whom they were purchased; from there they will be returned, at the customer’s expense, to the factory for inspection.
- Unless claims for shortages or errors are made immediately upon receipt of goods, they will not be considered.
- When broken goods are received, a full description of the damage should be made by the carrier agent on the freight bill. If this description is insisted upon, full damage can always be collected from the transportation company.
- No responsibility is assumed for delay or damage to merchandise while in transit. Our responsibility ceases upon delivery of shipment to the transportation company from whom a receipt is received showing that shipment was in good condition when delivered to them; therefore, claims (if any) should be filed ·:1ith the transportation company
- The right is reserved to change the construction or material of any parts where it seems desirable to do so without incurring the obligation of installing such changes on units already delivered.
TABLE OF CONTENTS:
FIAT ALLIS 100C MOTOR GRADER PARTS MANUAL – PDF DOWNLOAD
Air Cleaner
Air Cleaner Extension
Air Cleaner Intake
Air Conditioner
Alternator
Axle
Front
Rear
Batteries and Cables
Booster
Brake
Engine Clutch
Brake Control
Brakes
Control Box
Engine Clutch
Parking
Camshaft
Canopy
Chain
Circle Turn
Compressor (Air Conditioning)
Connecting Rod
Coolant Filter
Crankshaft
Cylinder
Brake Master
Brake Wheel
Moldboard
Moldboard
Cylinder Block
Cylinder Head
Cylinder Sleeve
Dash and Floor
Defroster Fan
Elements
Air Cleaner
Engine Oil Filter,
Hydraulic System Filter
Severe-Service Fuel Filter
Severe-Service Oil Filter
Transmission Oil Filter
Engine Breather
Engine Clutch
Engine Clutch Booster
Engine Clutch Control
Engine Mounting
Engine Primer
Engine Shut-off
Exhaust Pipe
Fan
Fan Belt Tightener
Filters
Coolant
Engine Oil ,
Fuel thru E
Hydraulic System
Transmission Oil
Water Separator (fuel) D, G
Floor
Flywheel and Housing
Frame
Front Axle and Wheel Lean
Front Wheel.
Front Wheel Spindles and Steering
Linkage
Fuel Filter thru E
Fuel Supply Line
Fuel Tank
Gauges
Air Restriction Indicator
Ammeter
Engine Oil Level , A
Engine Oil Pressure
Engine Temperature
Fuel Level
Hour Meter , A
Hydraulic System Oil Level
Transmission Oil Level
Transmission Oil Pressure
Gear Shift Controls
Gear Shift Forks and Locks
Grill
Heater, cab
Hood
Hood Side Plates
Horn
Hose Parts
Hour Meter , A
Hydraulic Pump Drive
Hydraulic System thru
Clutch/Brake Booster
Control Box Scavenging
Control Valve
Moldboard Pitch
Moldboard Shift
Moldboard Shift/Pitch Control
Steering
Wheel Lean
Hydraulic System Breather
Hydraulic Tank
Injection Fuel Return Lines , A
Injection Nozzles and Lines . . . , A, C
Injection Pump. A,
Instruments
Lights
Flood
Head
Instrument Panel
Stop
Tail
Lights, Horn and Wiring
Main Bearings
Manifolds
Exhaust
Intake
Water Outlet
Moldboard
Shifting Forks
Shifting Fork Control Levers . . . . ,
Steering Control
Steering Linkage
Sound Insulation
Assembly Tandems
Circle Turn Thermostat
Drawbar and Circle Throttle Control
Extensions Timing Gear Housing
Hydraulic Pitch Timing Gears , , A,
Lift Tires, Tubes and Rims
Power Shift Tire Pump
Pitch Controls Tools
Power Shift Control Valve Transmission
Rock Bits Assembly
Side Shift Bottom Shift
Shift Controls Gear Shift Forks and Locks
Muffler Intermediate Shaft
Reverse Gear Shaft
Oil Cooler Top Shaft
Oil Filter , Transmission Oil Pump
Oil Pan , A Transmission Oiling System
Oil Pump , A Turbocharger
Oil Return Line Turn Signals A
Package Parts Universal Joint
Painting and Marking
Parking Brake Valves
Parking Brake Control Control Box Pressure Regulating . . .
Piston Engine Oil Pressure Regulating . . .
Pointer, timing Engine Oil Pressure Relief
Power Control Shaft
Power Steering Intake
Power Take-off Moldboard Pitch Control
Power Take-off Vertical Drive Moldboard Shift Control
Brake Booster Shifting Fork Control (Control Box). .
Control Box Scavenging Travel Limit (Moldboard lift
Control Valve Supply and shift)
Engine Clutch Booster Wheel Lean Control
Engine Oil , A Valve Operating Mechanism
Fuel Injection A, Vandalism Prevention Parts
Steering
Tire Water Outlet Manifold
Transmission Oil Water Pump
Water Wheel Lean
Wheel Lean Piping
Radiator Wheels
Rear Axle Wheel Lean Control B,
Rear Wheels
ROPS Mounting Brackets
Seat
Seat Supports
Starter
Tools
Transmission
Assembly.
Gear Shift Forks and Leeks .
Intermediate Shaft
Reverse Gear Shaft Transmission Oil Pump
Transmission Oiling System
Valves
Control Box Pressure Regulating
Engine Oil Pressure Regulating .
Engine Oil Pressure Relief
Moldboard Pitch Control.
Moldboard Shift Control
Shifting Fork Control (Control Box
Travel Limit
Wheel Lean Control
Valve Operating Mechanism
Vandalism Prevention Part8
Water Outlet Manifold
Wheel Lean Piping
Windshield Wiper
