Fujifilm FCR PRIMA T Service Manual PDF DOWNLOAD
Original price was: $85.00.$19.95Current price is: $19.95.
Comprehensive Fujifilm FCR PRIMA T service manual PDF for CR-IR 392-04E Prima T troubleshooting guide, FCR PRIMA T installation procedures, Fujifilm CR system maintenance checkpoints, Prima T error codes and diagnostics, FCR PRIMA T parts replacement guide, and image processing adjustments. Covers checkpoints for trouble, documents, image/parts/installation/maintenance/software issues, and references for the FCR PRIMA T series computed radiography system.
Description
Fujifilm FCR PRIMA T Service Manual PDF DOWNLOAD
Description
This Fujifilm FCR PRIMA T service manual PDF is an indispensable resource for technicians servicing the FCR PRIMA T series computed radiography system, focusing on the CR-IR 392-04E Prima T model. It provides a detailed CR-IR 392-04E Prima T troubleshooting guide with checkpoints for abnormal images, bootup failures, and error codes, including diagnostics and remedies. The manual features comprehensive FCR PRIMA T installation procedures, covering site preparation, mechanical setup, software configuration, RU IP address changes, and optional items like anti-drop retainers or LCD stands.
Fujifilm CR system maintenance checkpoints outline preventive programs, 2nd/4th-year parts lists, and cleaning/lubrication steps. Prima T error codes and diagnostics classify faults with on-site fixes, including SND37A/CPU37A board LEDs and unit/roller locations. The FCR IR 392-04E parts replacement guide includes lists, exploded views, and indexes for accurate repairs. Image processing adjustments cover sensitivity/shading correction, format tweaks, and image data flows.
Safety precautions and voltage checks are emphasized for patient environments. Visual aids like circuit diagrams, I/O locations, conveyance paths, and block diagrams support the CR-IR 392-04E Prima T troubleshooting guide and FCR PRIMA T installation procedures throughout.
Table of Contents
- Checkpoints When Trouble Occurs (Page 1)
- Abnormal image occurs.
- Bootup does not take place, and the panel LED remains as “ ”.
- Documents and References to be Used When Trouble Occurs (Page 1)
- Search the error code.
- Software Control
- Circuit Diagrams (Disconnection Check)
- I/O Locations and Their Functional Overview
- SND37A Board LEDs
- CPU37A Board LEDs
- Unit Locations
- Roller Locations/Conveyance Paths
- Image Data Flows
- Sensitivity/Shading Correction
- Format Adjustment
- Image Related Checkpoints (Page 1)
- Parts Related Checkpoints
- Checkpoints during Installation
- Checkpoints during Preventive Maintenance
- Software Related Checkpoints
- Parts List (INDEX) (Referenced Throughout)
- List of Preventive Maintenance Replacement Parts: 2nd-Year / 4th-Year
- Installation Specifications (Page 1)
- Preparation for Installation
- Installation Procedures (Mechanical)
- Installation Procedures (Software Setup)
- Procedures for Changing the RU IP Address
- Procedures for Changing the IP Address of the FTP Server
- Installing Optional Items (Anti-Drop Retainer)
- Installing Optional Items (Additional Stand for LCD and Stand Wagon)
- When Installed in Patient Environment
- To Table of Contents of Service Manual (Page 1)
- How to Use PDF Manual
- To CLIENT PC – GUIDE PAGE
- Voltage Check Procedures
No separate bookmarks or index are present beyond the guide page. This Fujifilm FCR PRIMA T service manual PDF ensures precise repairs with proprietary insights for the Prima T series.
File Details
- Manual Name: CR-IR 392-04E Prima T Service Manual
- Models Covered: FCR PRIMA T SERIES
- Year: Not specified
- Manual PDF Quality: High-resolution scan with clear text and diagrams
- No of Pages: 488
