Iseki TM3215, TM3245, TM3265 Tractor Parts Manual 177-095-100-00 – PDF DOWNLOAD

FILE DETAILS:

Iseki TM3215, TM3245, TM3265 Tractor Parts Manual 177-095-100-00 – PDF DOWNLOAD

Language : English
Pages : 580
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Iseki TM3215, TM3245, TM3265 Tractor Parts Manual 177-095-100-00 – PDF DOWNLOAD

TM3215FH
ENGINE(E3112B35)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
9
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-036-10 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-103-10 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-014-00 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig801FigS04
10
C o n t e n t s
TM3215F
ENGINE(E3112B36)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
11
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-036-10 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-103-10 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-014-00 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig801FigS04
12
C o n t e n t s
TM3245FH
ENGINE(E3112B33)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
13
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-036-10 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-103-10 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-014-00 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig801FigS04
14
C o n t e n t s
TM3245F
ENGINE(E3112B34)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
15
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-036-10 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-103-10 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-014-00 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig801FigS04
16
C o n t e n t s
TM3265FH
ENGINE(E3CDB70)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
17
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-037-00 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-155-00 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-002-30 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-021-00 ON Fig801FigS04
18
C o n t e n t s
TM3265F
ENGINE(E3CDB71)
CYLINDER HEAD Fig101
CYLINDER HEAD COVERFig102
INLET MANIFOLD Fig103
EXHAUST MANIFOLDFig104
CYLINDER BLOCKFig201
OIL PAN Fig202
REAR PLATE Fig203
TIMING GEAR CASEFig204
HANGER Fig205
VALVEFig301
CAM SHAFTFig302
PISTONFig303
CRANK SHAFTFig304
OIL PUMPFig401
WATER PUMP Fig402
COOLING FAN Fig403
INJECTION NOZZLEFig501
INJECTION PUMPFig502
FUEL PIPEFig503
ADAPTERFig504
ELECTRIC (1) Fig801
ELECTRIC (2) Fig802
SHORT BLOCK ENGIASSY FigP01
BEARING/UNDER SIZE (OPTION) FigP02
19
PISTON/OVER SIZE (OPTION)FigP03
REPAIR PARTS (OPTION)FigP04
COMPONENT PARTS
FOR 6215-300-037-00 ON Fig501FigS01
COMPONENT PARTS
FOR 6215-600-155-00 ON Fig502FigS02
COMPONENT PARTS
FOR 6281-100-002-30 ON Fig801FigS03
COMPONENT PARTS
FOR 6281-200-021-00 ON Fig801FigS04
20
C o n t e n t s
CHASSIS
RADIATOR SYSTEM
(TM3215,3245-EXCEPT H TYPE)Fig101
RADIATOR SYSTEM (TM3215,3245-H TYPE)Fig102
RADIATOR SYSTEM
(TM3265-EXCEPT H TYPE)Fig103
RADIATOR SYSTEM (TM3265-H TYPE)Fig104
MUFFLER SYSTEM (TM3265)Fig105
MUFFLER SYSTEM (TM3215,3245)Fig106
AIR CLEANER SYSTEM (TM3215,3245)Fig107
AIR CLEANER SYSTEM (TM3265)Fig108
FILTER SYSTEM (TM3215,3245)Fig109
FILTER SYSTEM (TM3265)Fig110
FUEL TANK SYSTEMFig111
BATTERY SYSTEM (TM3215,3245)Fig112
BATTERY SYSTEM (TM3265)Fig113
ACCELERATOR PEDAL SYSTEM
(EXCEPT H TYPE)Fig114
ACCELERATOR LEVER SYSTEMFig115
CLUTCH HOUSING SYSTEM
(TM3215,3245-EXCEPT H TYPE)Fig116
CLUTCH HOUSING SYSTEM
(TM3215,3245-H TYPE)Fig117
CLUTCH HOUSING SYSTEM
(TM3265-EXCEPT H TYPE)Fig118
CLUTCH HOUSING SYSTEM
(TM3265-H TYPE)Fig119
PEDAL (CLUTCH) SYSTEM
(EXCEPT H TYPE)Fig120
21
INPUT SHAFT SYSTEM (EXCEPT H TYPE)Fig121
INPUT SHAFT SYSTEM (H TYPE)Fig122
DRIVE GEAR SYSTEM (EXCEPT H TYPE)Fig123
PTO DRIVE GEAR SYSTEM
(EXCEPT H TYPE)Fig124
PTO DRIVE GEAR SYSTEM (H TYPE) Fig125
REVERSE CHANGE SYSTEM
(EXCEPT H TYPE)Fig126
REVERSE LEVER SYSTEM
(EXCEPT H TYPE)Fig127
FRONT MISSION CASE SYSTEM
(EXCEPT H TYPE)Fig201
FRONT MISSION CASE SYSTEM (H TYPE)Fig202
HST SYSTEM (H TYPE)Fig203
INPUT GEAR SYSTEM (EXCEPT H TYPE)Fig204
INPUT GEAR SYSTEM (H TYPE)Fig205
MAIN CHANGE GEAR SYSTEM
(EXCEPT H TYPE)Fig206
MAIN COUNTER GEAR SYSTEM
(EXCEPT H TYPE)Fig207
SUB CHANGE GEAR SYSTEM
(EXCEPT H TYPE)Fig208
SUB CHANGE GEAR SYSTEM (H TYPE)Fig209
SUB COUNTER GEAR SYSTEM
(EXCEPT H TYPE)Fig210
SUB COUNTER GEAR SYSTEM (H TYPE) Fig211
MAIN CHANGE SYSTEM (EXCEPT H TYPE)Fig212
SUB CHANGE SYSTEM (EXCEPT H TYPE) Fig213
SUB CHANGE SYSTEM (H TYPE) Fig214
SHIELD COVER SYSTEM (R TYPE) Fig215
4WD GEAR SYSTEMFig216
4WD CHANGE SYSTEMFig217
REAR MISSION CASE SYSTEMFig218
22
PTO COUNTER GEAR SYSTEMFig219
PTO SHAFT SYSTEM Fig220
PTO CHANGE SYSTEMFig221
MID PTO SYSTEM (M TYPE)Fig222
COVER (PTO/MID) SYSTEM
(EXCEPT M TYPE) Fig223
MAIN LEVER SYSTEM (EXCEPT H TYPE) Fig224
SUB LEVER SYSTEM (EXCEPT H TYPE)Fig225
SUB LEVER SYSTEM (H TYPE)Fig226
4WD LEVER SYSTEMFig227
REAR PTO LEVER SYSTEMFig228
MID PTO LEVER SYSTEM (M TYPE)Fig229
LINK (HST) SYSTEM (H TYPE)Fig230
PEDAL (HST) SYSTEM (H TYPE)Fig231
LEVER (HST) SYSTEM (H TYPE)Fig232
PIPING (HST) SYSTEM (H TYPE)Fig233
DRIVE PINION SYSYTEM (EXCEPT H TYPE)Fig301
DRIVE PINION SYSYTEM (H TYPE)Fig302
DIFF CASE SYSTEM (EXCEPT H TYPE) Fig303
DIFF CASE SYSTEM (H TYPE) Fig304
REAR AXLE HOUSING SYSTEM Fig305
WHEEL SHAFT SYSTEMFig306
DIFF-LOCK PEDAL SYSTEM
(EXCEPT H TYPE)Fig307
DIFF-LOCK PEDAL SYSTEM (H TYPE)Fig308
BRAKE SYSTEM Fig309
PEDAL (BRAKE) SYSTEM
(EXCEPT H TYPE)(1/2)(2/2)Fig310
PEDAL (BRAKE) SYSTEM (H TYPE)(1/2)(2/2) Fig311
LEVER (PARKING) SYSTEM (H TYPE)Fig312
LEVER (PARKING) SYSTEM
(EXCEPT H TYPE)Fig313
WHEEL (STEERING) SYSTEMFig401
23
CYLINDER SYSTEMFig402
STEERING SYSTEMFig403
PIPING (SUB) SYSTEM (EXCEPT H TYPE)Fig404
PIPING (SUB) SYSTEM (H TYPE)Fig405
AXLE BRACKET SYSTEM
(TM3215,3245-EXCEPT A TYPE) Fig406
AXLE BRACKET SYSTEM
(TM3265-EXCEPT A TYPE) Fig407
AXLE BRACKET SYSTEM
(TM3215,3245-A TYPE) Fig408
AXLE BRACKET SYSTEM (TM3265-A TYPE)Fig409
HITCH (BUMPER) SYSTEM
(R TYPE-STANDARD/EXCEPT R TYPE-OPTION)Fig410
SHAFT (4WD) SYSTEM Fig411
PINION (DRIVE) SYSYTEMFig412
HOUSING (AXLE) SYSTEMFig413
GEAR (FINAL) SYSTEMFig414
FINAL DRIVE SHAFT SYSTEM Fig415
ROD (TIE) SYSTEM Fig416
CYLINDER CASE SYSTEMFig501
ARM (LIFT) SYSTEMFig502
CYLINDER SYSTEMFig503
POSITION LEVER SYSTEM Fig504
COVER (VALVE) SYSTEM (EXCEPT R TYPE)Fig505
VALVE (REMOTE/1R) SYSTEM (VR TYPE) Fig506
VALVE (REMOTE/2R) SYSTEM
(WR TYPE)(1/2)(2/2)Fig507
PIPING (MAIN) SYSTEM
(TM3265-EXCEPT H TYPE)Fig508
PIPING (MAIN) SYSTEM (TM3265-H TYPE) Fig509
PIPING (MAIN) SYSTEM
(TM3215,3245-EXCEPT H TYPE)Fig510
PIPING (MAIN) SYSTEM
(TM3215,3245-H TYPE)Fig511
24
LINK (3P) SYSTEM (EXCEPT D TYPE) Fig512
LINK (3P) SYSTEM (D TYPE) Fig513
HITCH (CREVICE) SYSTEM (R TYPE) Fig514
HOOD SYSTEM (TM3215,3245)(1/2)(2/2) Fig601
HOOD SYSTEM (TM3265)(1/2)(2/2) Fig602
GRILLE SYSTEM (TM3215,3245) Fig603
GRILLE SYSTEM (TM3265) Fig604
STEERING COVER SYSTEM
(EXCEPT H TYPE)Fig605
STEERING COVER SYSTEM (H TYPE)Fig606
FENDER SYSTEM (EXCEPT D TYPE)Fig607
SEAT BASE SYSTEM (EXCEPT D TYPE)Fig608
SEAT (NUMBER) SYSTEM (E6 TYPE)Fig609
MIRROR SYSTEM (EXCEPT A,D TYPE)Fig610
MIRROR SYSTEM (A TYPE) Fig611
FRONT MOUNT SYSTEMFig612
REAR MOUNT SYSTEM (EXCEPT D TYPE)Fig613
REAR MOUNT SYSTEM (D TYPE)Fig614
FLOOR SYSTEM
(TM3215,3245-EXCEPT H TYPE)Fig615
FLOOR SYSTEM (TM3215,3245-H TYPE)Fig616
FLOOR SYSTEM (TM3265-EXCEPT H TYPE)Fig617
FLOOR SYSTEM (TM3265-H TYPE) Fig618
STEP SYSTEM (EXCEPT H,D TYPE)Fig619
STEP SYSTEM (H TYPE EXCEPT D)Fig620
NUMBERPLATE SYSTEM
(E4 TYPE EXCEPT D) Fig621
HEAD LIGHT SYSTEM (E6 TYPE)Fig622
HEAD LIGHT SYSTEM (E4 TYPE)Fig623
LAMP SYSTEM (EXCEPT A,D TYPE) Fig624
LAMP SYSTEM (A TYPE)Fig625
LAMP SYSTEM (D TYPE)Fig626
METER PANEL SYSTEM Fig627
25
SWITCH SYSTEM (TM3265-EXCEPT H TYPE) Fig628
SWITCH SYSTEM (TM3265-H TYPE) Fig629
SWITCH SYSTEM
(TM3215,3245-EXCEPT H TYPE)Fig630
SWITCH SYSTEM (TM3215,3245-H TYPE) Fig631
HARNESS SYSTEM (EXCEPT H TYPE) Fig632
HARNESS SYSTEM (HE4 TYPE)Fig633
HARNESS SYSTEM (HE6 TYPE)Fig634
CONTROL (PTO) SYSTEM (H TYPE)Fig635
ROPS SYSTEM (R TYPE EXCEPT A) Fig701
ROPS SYSTEM (TM3215,3245-A TYPE)Fig702
ROPS SYSTEM (TM3265-A TYPE)Fig703
ORNAMENT (TM3265)Fig901
ORNAMENT (TM3245)Fig902
ORNAMENT (TM3215)Fig903
ORNAMENT (H TYPE) Fig904
LABEL (CONTROL) (EXCEPT H TYPE) Fig905
LABEL (CONTROL) (H TYPE) Fig906
LABEL (CAUTION) (EXCEPT H TYPE) Fig907
LABEL (CAUTION) (H TYPE) Fig908
LABEL (CE) (D TYPE)Fig909
TOOLS
(TM3215,3245-ALL TYPE/TM3265-EXCEPT H TYPE)Fig910
OPTIONAL PARTS
MID PTO SET
(EXCEPT M TYPE) (OPTION)(1/2)(2/2) FigP01
TIRE (31X135-15) SYSTEM
(TM3215-ALL TYPE/TM3245,3265-A TYPE) (OPTION) FigP02
TIRE (95-18) SYSTEM
(TM3245,3265-EXCEPT A TYPE) (OPTION) FigP03
TIRE (315/75D-15) SYSTEM
(TM3245,3265-EXCEPT A TYPE) (OPTION) FigP04
26
TIRE (95-16) SYSTEM
(TM3215-ALL TYPE/TM3245,3265-A TYPE) (OPTION) FigP05
TIRE (22X850-12) SYSTEM
(TM3215-ALL TYPE/TM3245,3265-A TYPE) (OPTION) FigP06
FRONT WHEEL (4WD) SYSTEM
(TM3215-ALL TYPE/TM3245,3265-A TYPE) (OPTION) FigP07
FRONT WHEEL (4WD) SYSTEM
(TM3245,3265-EXCEPT A TYPE) (OPTION) FigP08
FRONT WHEEL (TURF) SYSTEM
(TM3245,3265-EXCEPT A TYPE) (OPTION) FigP09
VALVE (AUX/2ND) SET
(EXCEPT W TYPE) (OPTION)FigP10
HITCH (DRAW BAR) SET (OPTION)FigP11
COMPONENT PARTS
COMPONENT PARTS
FOR K200-208-000-00 ON Fig405FigS01
COMPONENT PARTS
FOR K211-092-000-00 ON Fig503FigS02
COMPONENT PARTS
FOR K510-014-000-00 ON Fig203FigS03
COMPONENT PARTS
FOR 1719-511-350-00 ON Fig506,507,P10 FigS04
COMPONENT PARTS
FOR 1772-654-210-00 ON Fig624~626FigS05
COMPONENT PARTS
FOR 1774-127-510-00 ON Fig125FigS06
WIRING DIAGRAM (TM3215,3245) (1)
WIRING DIAGRAM (TM3215,3245) (2)
WIRING DIAGRAM (TM3265) (1)
WIRING DIAGRAM (TM3265) (2)
27
WIRING

DESCRIPTION:

Iseki TM3215, TM3245, TM3265 Tractor Parts Manual 177-095-100-00 – PDF DOWNLOAD

Parts Order:
1) Parts numbers listed in the parts catalogue are all registered in “ISEKI
on-line computer”.
2) When you order parts, please make sure of correct numbers.
3) When substitute parts is available, the part number ordered will be
automatically turned to a new part number.
4) Please be sure to use “ISEKI GENUINE PARTS”.
Any other similar parts other than ISEKI parts when used may cause a
trouble that makes us unable to repair or guarantee the warrant.

S.V 08/03/2025
