Jeep AX15 Transmission XJ YJ TJ Service Manual – PDF DOWNLOAD

Description

Jeep AX15 Transmission XJ YJ TJ Service Manual – PDF DOWNLOAD

DESCRIPTION:

Jeep AX15 Transmission XJ YJ TJ Service Manual – PDF DOWNLOAD

GENERAL INFORMATION:
The AX 15 is a 5-speed, synchromesh, manual transmission. Fifth gear is an overdrive range with a ratio of 0.79:1. The shift mechanism is integral and mounted in the shift tower portion of the adapter housing (Fig. 1). An adapter housing is used to attach the transmission to the transfer case on 4-wheel drive models. A standard extension housing is used on 2-wheel drive models. The AX 15 is used in XJ and YJ models with a 4.0L engine. The AX 15 is designed for use with either two-wheel drive or four-wheel drive applications.
TRANSMISSION IDENTIFICATION : The AX 15 identification code numbers are on the bottom surface of the transmission gear case (Fig. 2). The first number is year of manufacture. The second and third numbers indicate month of manufacture. The next series of numbers is the transmission serial number.

FILE DETAILS :

Jeep AX15 Transmission XJ YJ TJ Service Manual – PDF DOWNLOAD

Language : English
Pages : 34
Downloadable : Yes
File Type : PDF
Size: 3.27 MB

Questions? Email us: [email protected]
