Kobelco SK260-9 and SK295-9 Acera Mark 9 Hydraulic Excavator Operator’s Manual PDF Download

Description

Kobelco SK260-9 and SK295-9 Acera Mark 9 Operator’s Manual

This is the full operator’s manual for the SK260 Acera Mark 9 and SK295 Acera Mark 9 Tier 4 hydraulic excavators. It is the document that ships with the machine, written for the person sitting in the seat: how the excavator is put to work, how it is kept safe, how it is serviced on schedule, and exactly what its limits are. Every control layout, warning decal, maintenance interval, fluid capacity and digging figure in these pages applies directly to the SK260-9 and SK295-9, including the long-undercarriage SK260-9 LC and SK295-9 LC versions.

File Details

• Manual type: Operator’s Manual
• Brand: KOBELCO
• Models covered: SK260-9, SK295-9 (Acera Mark 9, Tier 4)
• Language: English
• File format: PDF
• Document number: LB91Z00006P1
• Page count: 202 pages

Chapters Covered

• 1 General Information — Note to the Owner, Intended Use, Electro-Magnetic Compatibility, Proposition 65, Right/Left/Front/Rear of the Machine, Cab Protection (ROPS and FOPS), Biodiesel Fuels, Selective Catalytic Reduction (SCR) Product Overview
• 2 Safety Information — Safety Rules and Signal Word Definitions, General Safety, Starting Safety, Operating Safety, Stopping Safety, Maintenance Safety, Engine Safety, Hydraulic System Safety, Tool Attachment Safety, Safety Decals, Hand Signals
• 3 Controls/Instruments — Cab Access, Operator’s Seat, Seat Belt, Front Console, Instrument Cluster, SCR Overview, Rear View Camera, Right-Hand Console, Radio, Climate Control Panel, Rearward Console
• 4 Operating Instructions — Hydraulic Oil Level, Fuel Level, Engine Oil Level, Engine Coolant Level, Windshield Washer Fluid Level, Draining the Fuel Filter Water Separator, SCR System, Starting the Engine, Inspection After Starting, Stopping the Engine, Parking the Machine
• 5 Transport Operations — Road Transport Frame and Cab Loading, Loading and Unloading, Securing the Machine, Shipping Transport, Lifting the Machine
• 6 Working Operations — Operating the Controls, Machine Travel, Attachment Controls, Swing Control, Practices to Improve Efficiency, Emergency Boom Lowering, Machine Operation in Adverse Weather Conditions
• 7 Maintenance — Preparing the Machine for Maintenance, Break-in Period, Maintenance Chart, and interval-based service procedures from Every 250 Hours through Every 5000 Hours plus As Required items, Fluids and Lubricants
• 8 Specifications — General Specifications, Dimensions and Weights, Digging Data, Bucket Application as a Function of the Arm
• 9 Accessories — Nibbler, Breaker, Hydraulic Oil for Breaker/Nibbler, Rotary Attachment Operation, Biodegradable Hydraulic Oil

Read as a whole, this manual gives a technician or owner a complete working picture of the SK260-9 and SK295-9. It opens with the layout of the machine — undercarriage, swing bearing, upper frame, attachment, engine, hydraulic components and cab — then walks through every control on the front, right-hand and rearward consoles. The instrument cluster is documented button by button: the coolant temperature meter, fuel level meter, urea level meter, work mode selection (S, E and H), the Auto Idle function, travel speed selection, the attachment mode buttons for digging, nibbler and breaker, and every warning icon with its priority level and required response.

The maintenance chapter is organised by hour interval rather than by component, which is how the machine actually gets serviced in the field. Every 250 hours covers the hydraulic oil tank, fuel tank, travel reduction units, swing reduction unit, bucket grease fittings, cab outside air filter, engine air filter outer element and track tension. Every 500 hours adds the cab air recirculation filter, engine oil and filter, fuel filter, swing bearing and boom lubrication. Every 1000 hours brings the engine air filters, hydraulic oil return filters, fuel pre-filter, blow-by filter and hydraulic reservoir breather. Further intervals cover the fan and drive belt, pilot line filter, swing and travel reduction unit oil, engine coolant, the DEF/AdBlue supply module filter and the full hydraulic oil change. The break-in period schedule for the first 50 and first 500 hours is called out separately so nothing gets missed on a new machine.

The specification chapter is what many buyers come for. Both machines are tabulated side by side with rated output, cylinder counts, displacement, bore and stroke, hydraulic pump displacement and flow, working pressures for attachment, travel, swing and power boost, cylinder bore and stroke, travel speeds, swing speed and maximum climbable gradient. Dimensions and weights are broken out per arm length and per track shoe width, with working weight and specific ground pressure for each configuration. Digging data charts give maximum digging reach, reach at ground level, maximum digging depth, maximum digging height, dumping clearance and vertical wall digging depth for every available arm.

What This Manual Lets You Do

With this operator’s manual on hand you can run the SK260-9 or SK295-9 correctly from the first cold start to the end of the shift. You can commission the machine with confidence — checking hydraulic oil, fuel, engine oil, coolant and washer fluid levels against the correct reference marks. You can start the engine in normal conditions or cold conditions, understand the automatic preheating sequence, and connect booster batteries in the right order without risking damage to the electrical system. You can shut the machine down properly so the turbocharger is not damaged, park it safely, and lock it down for the night.

The chapter on working operations is where the productivity gains sit. It explains how to use the arm rather than forcing the bucket, how to keep boom movements smooth, which way the bucket teeth should point, and where the attachment sits when maximum digging force is available. Grading technique, bucket cleanout, stopping the swing early, working in water or mud, and the correct way to lower the boom in an emergency if the engine stops are all covered. Adverse weather operation — extreme cold, extreme heat, high altitude, sandy and dusty sites, salt air and humid climates — is handled with the specific precautions each condition demands.

Why the Correct Procedures and Specifications Matter

The SK260-9 and SK295-9 are Tier 4 machines with a Selective Catalytic Reduction system, a DEF/AdBlue tank, an aftertreatment dosing control unit and a list of warnings that escalate from a displayed message to reduced engine torque and finally to an engine shutdown. The manual documents each DEF/AdBlue level fault, each DEF/AdBlue quality fault and each SCR system fault, together with what the machine will do and how long the operator has to act. It also explains validation re-starts and emergency re-starts. Understanding this before it happens is the difference between finishing the shift and being stranded on site.

The same applies to the fuel side. This manual states plainly that the SCR system is compatible with up to 7% biodiesel (B7), that B20 and B100 must not be used, and that cold pressed biodiesel, straight vegetable oil and other unrefined vegetable oils are not approved at any blend. Getting that wrong affects the engine, the fuel injection equipment and warranty coverage.

Safety is treated at length rather than as a formality. The operating safety rules cover travel on slopes, working near electric lines, digging near underground services, undercutting high banks, handling suspended loads, avoiding the bucket as a hammer, and knowing the swing and travel blind areas. The machine’s ROPS and FOPS protection, the seat belt, the safety lever lock position and the cab emergency exit are all documented, along with the full set of safety decals and the standard hand signals for raise, lower, swing, travel, bucket open and close, stop and emergency stop.

IMAGES PREVIEW

Instant PDF Delivery

This Kobelco SK260-9 and SK295-9 Acera Mark 9 hydraulic excavator operator’s manual is delivered as a PDF file immediately after payment. Nothing ships and nothing is waited for. Open it on a laptop, tablet or phone in the cab, at the bench or in the office, search the section you need, and print the pages you want to keep next to the machine. Whether you are a first-time operator learning the console, an owner setting up a maintenance schedule, or a technician looking up a working pressure or a fluid capacity, the information is in these 202 pages.
