Komatsu PC400-7 Excavator Parts Catalog PDF – SAA6D125E-3 Spare Parts Manual

Description

The Komatsu PC400-7 Excavator Parts Catalog PDF is the complete illustrated spare-parts reference for the PC400-7 hydraulic excavator and the SAA6D125E-3 diesel engine that powers it. It covers machine serial numbers J20001 and up and engine serial numbers 312635 and up. Every major assembly is drawn as an exploded figure next to a parts list showing reference number, part number, description, quantity and the serial-number range each part applies to, so a workshop, parts counter or owner can positively identify a component before ordering it.

File Details

• Manual type: Illustrated parts catalog
• Brand: Komatsu
• Machine: PC400-7 hydraulic excavator
• Engine: SAA6D125E-3
• Serial coverage: PC400-7 J20001 and up / SAA6D125E-3 312635 and up
• Language: English
• Format: PDF – instant download
• Length: Approx. 410 pages

Chapters Covered

• Engine – cylinder head, cylinder block, front cover, idler gear, cam follower cover, oil pan and suction tube, oil level gauge, flywheel housing, flywheel, crankshaft, damper, piston, crank pulley, rocker arm, camshaft and cam follower, tachometer drive, oil pump, oil filter and piping, oil cooler, water drain valve
• Fuel system – fuel supply pump, common rail, return piping, fuel injector, fuel return, fuel control, fuel filter, fuel supply pump drive
• Cooling – water pump, air vent, cooling fan, fan pulley, fan drive, corrosion resistor
• Electrical (engine) – alternator, starting motor, wire harness sections, name plate and caution plate sets
• Fuel tank and related parts – fuel tank variants, fuel line sections, fuel self-supply pump options, foaless variants
• Electrical system – battery and large-capacity battery, starting harness, main harness, battery case wiring, working lamp front and additional, rear work lamp, horn, travel alarm
• Engine related parts – dumper pump and tube, engine mounting, air cleaner connection, aftercooler, fuel control (chassis mount), air cleaner, wiring, caution plates
• Hydraulic system – hydraulic tank (standard and foaless), main valve (connecting parts, valve bracket), main pump (connecting parts), suction line, delivery line with filter, oil cooler line, return line, drain line, boom line, arm and bucket line, relief valve, travel line, swing line, LS line, solenoid valve, pressure switch, PPC main line
• Cooling system – radiator and frame, oil cooler, net and shroud, aftercooler and condenser, radiator piping, cooling stay and aftercooler piping, cover and sheet, fan guard
• Main / revolving frame – revolving frame variants, foaless versions, deck guard versions, boom foot pin
• Operator’s compartment – seat (suspension, leather, standard), seat belt, seat rear cover, top guard, front guard, floor mat, rain visor, sun visor, window washer, air conditioner unit and piping, operator’s cab, floor frame sections covering front window, lower window, roof window, door, door lock, open lock, electrical, accessories, monitor system, plate and duct, partition and foot duct, sub panel, clamp and bolt, travel control, foot rest, console, lever and valve, air conditioner hose, heater hose and clamp, PPC hose and clamp, P.T. block and seal, floor mount, PPC work line clamp, switch
• Guard – hood (standard and foaless), machine cab frame, left and right side doors, partition, cover, battery case, handrail, rear view mirror LH and RH, counterweight, counterweight mounting, under cover sections (light duty, heavy duty, foaless)
• Swing circle and related parts – swing circle, swing machinery, swing motor connecting parts, swivel joint connecting parts
• Travel and lower piping – travel piping, additional travel piping, final drive
• Undercarriage – front idler, idler cushion, carrier roller, track shoe variants (triple grouser with hole, 600 mm and 800 mm wide), track frame variants (center guard, full roller guard, with under cover), track roller, additional track roller, under cover for track frame
• Work equipment – boom standard and heavy duty (including 100 H versions), boom top and bottom pin, bucket cylinder line, arm cylinder line, boom blind parts, lubricating line, working lamp and spacer, boom cylinder and top pin, arm cylinder, arm 3.4 M / 2.4 M / heavy duty, arm bucket cylinder and bucket link, arm bucket cylinder hose and spacer, bucket variants (1.7 m3 vertical pin, 3.2 m3 and 3.0 m3 horizontal pin with adjusting)
• Marks and plates – decal and plate sets (English, English additional, Indonesia additional), mark plates
• Service kit and component – swing machinery assy, final drive assy, shoe bolt and nut service kit, track link (92 set), main pump sections (1/11 through 11/11), boom cylinder, arm cylinder, bucket cylinder, swivel joint, swing motor (1/3 through 3/3), travel motor (1/3 through 3/3), main valve sections (1/20 through 20/20), safety valve, lock valve (boom and arm), selector valve, accumulator, return filter, solenoid valve inner parts, multi pattern valve, breather
• Index – complete part-number index cross-referenced to figure number and page

Put together, the Komatsu PC400-7 parts catalog covers the machine from the cylinder block outward: fuel, cooling and engine electrical systems; the hydraulic tank, main pump, main valve and every line group; the revolving frame and operator’s compartment; the undercarriage and track assemblies; and the whole boom, arm and bucket work equipment. Each figure is keyed to a numbered parts list, so once a component is located on the drawing the corresponding part number, quantity and serial-number breakpoint can be read directly from the adjacent table.

How the parts lists and symbols work

Every figure in the Komatsu PC400-7 spare parts manual is laid out with an index number, part number, description, quantity and serial-number range. The catalog also uses the standard Komatsu parts-list symbols, and reading those correctly is what stops a part being ordered that has already been replaced. The symbols flag interchangeable parts, parts that can be used instead of the line above, discontinued parts where a superseded number is supplied, kit-only items, semi-finished parts, and painted parts. There are also cold-weather specification codes (A) for -30 C machines and (B) for -50 C machines, so the correct climate-spec part can be selected without ordering the wrong variant.

What the PC400-7 parts catalog lets you do

With the Komatsu PC400-7 Excavator Parts Catalog PDF open, a technician or parts counter can identify a component from the exploded view, read its part number, confirm the correct quantity, and check whether the part is subject to a serial-number breakpoint or has been superseded. That means fewer wrong orders, fewer returns, and no reliance on memory or guesswork when rebuilding a cylinder head, a swing motor, a travel motor, a hydraulic line group or an undercarriage section. The catalog covers the main valve in twenty separate sections, the main pump in eleven, and the travel and swing motors in three sections each, so even the internal parts of the larger hydraulic assemblies can be pinpointed.

Because the file is a PDF, it opens on any device – workshop PC, laptop, tablet or phone – and any page can be printed for use on the shop floor. Delivery is instant after payment; there is no shipping and nothing to wait for. A Komatsu PC400-7 excavator parts catalog like this pays for itself the first time it stops a wrong part number going out the door.
