LG Bh7520tw Home Theaer System Service Manual
FILE DETAILS:
LANGUAGE:ENGLISH
PAGES:137
DOWNLOADABLE:YES
FILE TYPE:PDF
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
LG Bh7520tw Home Theaer System Service Manual
IMPORTANT SAFETY:
This manual was prepared for use only by properly trained audio-video service technicians. When servicing this product, under no circumstances should the original design be modified or altered without permission from LG Corporation. All components should be replaced only with types identical to those in the original circuit and their physical location, wiring and lead dress must conform to original layout upon completion of repairs.
- Special components are also used to prevent x-radiation, shock and fire hazard. These components are indicated by the letter “x” included in their component designators and are required to maintain safe performance. No deviations are allowed without prior approval by LG Corporation.
- Circuit diagrams may occasionally differ from the actual circuit used. This way, implementation of the latest safety and performance improvement changes into the set is not delayed until the new service literature is printed. CAUTION : Do not attempt to modify this product in any way.
- Never perform customized installations without manufacturer’s approval. Unauthorized modifications will not only void the warranty, but may lead to property damage or user injury.Service work should be performed only after you are thoroughly familiar with these safety checks and servicing guidelines.
SERVICE INFORMATION :
While servicing, use an isolation transformer for protection from AC line shock. After the original service problem has been corrected, make a check of the following: FIRE AND SHOCK HAZARD
1. Be sure that all components are positioned to avoid a possibility of adjacent component shorts. This is especially important on items trans-ported to and from the repair shop
2. Verify that all protective devices such as insulators, barriers, covers, shields, strain reliefs, power supply cords, and other hardware have been reinstalled per the original design. Be sure that the safety purpose of the polarized line plug has not been defeated.
3. Soldering must be inspected to discover possible cold solder joints, solder splashes, or sharp solder points. Be certain to remove all loose foreign particles.
4. Check for physical evidence of damage or deterioration to parts and components, for frayed leads or damaged insulation (including the AC cord), and replace if necessary.
5. No lead or component should touch a high current device or a resistor rated at 1 watt or more. Lead tension around protruding metal surfaces must be avoided.
TABLE OF CONTENTS:
LG Bh7520tw Home Theaer System Service Manual
SECTION 1 ……..SUMMARY
SECTION 2 ……..ELECTRICAL
SECTION 3 ……..CABINET & MAIN CHASSIS
SECTION 4 ……..MT8560 F/E LOADER PART
SECTION 5 ……..WIRELESS RECEIVER PART
SECTION 6 ……..REPLACEMENT PARTS LIST
