NEW HOLLAND E16 -E18 Workshop Manual 604 13 396

FILE DETAILS:

New Holland Excavator E16-E18 604.13.396 Workshop Manual
Size : 42.0 MB
Format : PDF
Language : English
Number of Pages : 636 Pages
Print No.604.13.396

NEW HOLLAND E16 -E18 WORKSHOP MANUAL 604 13 396 – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

New Holland Excavator E16-E18 604.13.396 Workshop Manual

INTRODUCTION:

• This service manual has been prepared in order to increase repair quality, providing to the technicians the elements for a good knowledge of the product and showing the proper procedures to carry out the maintenance operations.
• We recommend to thoroughly read the content and follow it when necessary. It is a concise guide. It covers construction features, operation principle, troubleshooting, disassembly and assembly of components and repair action.
• Using this manual in systematic and rational way it is possible to reduce the repairing errors and delay that could cause machine stop with a detriment of cost management. The information quoted in this service manual are supplied also to be used for training aids. Therefore it is advisable to be used in the training of new personnel that will be employed in the machine maintenance.
• All the information, illustrations and specifications contained in this service manual are based on the latest product information available at the time of publication. The dealer reserves the right to makes changes at any time without notice to this service manual for technical or trading reasons.

FEATURES OF THE MANUAL:

MANUAL COMPOSITION:

This service manual is divided into ten Sections. The Section names and its contents are as below. To fully use this service manual it is essential to understand how it is organised. Therefore, in order to speed up the searching of wished subject, it is advisable to carefully read this chapter.

SECTION 1 – HOW TO USE:Begin to read first this Section to know the manual composition. This will help you for subject searching.
SECTION 2 – SAFETY RULES:Indication on how to avoid dangerous situation during the use and maintenance are given in this Section. Furthermore safety decals and related indications used on the machine are listed on this Section.
SECTION 3 – PRELIMINARY:This Section contains the information related to general precautions for repairs and escaping procedure in can of emergency.
SECTION 4 – SPECIFICATION:This Section quotes the specification and data of the machine.
SECTION 5 – TOOLS :This Section contains the list of special tools.
SECTION 6 – STANDARD MAINTENANCE TIME TABLE
SECTION 7 – MAINTENANCE STANDARDS AND TEST PROCEDURES
SECTION 8 – HYDRAULIC SYSTEM: This Section describes the operation of the machine from hydraulic point of view.

TABLE OF CONTENTS:

New Holland Excavator E16-E18 604.13.396 Workshop Manual

SECTION 1 – HOW TO USE
Sections index 1-1
Introduction 1-4
Features of the manual 1-5
SECTION 2 – SAFETY RULES
Safety rules 2-1
Safety signs 2-38
SECTION 3 – PRELIMINARY
General precautions for repairs 3-1
Escaping procedure in case of emergency 3-6
International unit conversion system 3-7
SECTION 4 – SPECIFICATION
Foreword 4-1
Identification data 4-2
Noise levels (2000/14/EC) 4-3
Summary plate for maintenance operations 4-4
Basic components of the mini excavator 4-5
Technical specifications 4-7
Digging performances (canopy) 4-8
Digging performances (cab) 4-9
Transport dimensions (canopy) 4-10
Transport dimensions (cab) 4-11
Lifting capacities (cab) 4-12
Lifting capacities (canopy) 4-13
Machine and components weight (dry) 4-14
Buckets application 4-15
Filling chart 4-16
SECTION 5 – TOOLS
Tools of cylinders 5-1
Tool of hydraulic pump 5-4
Tool of pilot valve track 5-4
Tool of roller track 5-4
Tool of idler adjuster 5-5
Tools of engine 5-5
Tools of travel motor 5-8
SECTION 6 – STANDARD MAINTENANCE TIME TABLE
Preface 6-1
Standard working time table for the maintenance 6-2
SECTION 7 – MAINTENANCE STANDARDS AND TEST PROCEDURES
How to use maintenance standards and precuations 7-1
Performance inspection standard table 7-2
Measuring engine speed 7-4
Measuring hydraulic oil pressure 7-5
Measuring travel performances 7-8
Measuring slew performances 7-10
Measuring attachment operating performances 7-12
Measuring slew bearing performances 7-14
Measuring crawler tension 7-15
SECTIONS INDEX PAGES
1-2
SECTIONS INDEX
SECTION 8 – HYDRAULIC SYSTEM
Function and features of hydraulic circuit 8-1
Hydraulic circuits and components 8-2
Hydraulic circuit operation 8-6
SECTION 9 – ELECTRICAL SYSTEM
How to read circuit diagram 9-1
SECTION 10 – ATTACHMENT
Attachment assy and name 10-1
Bucket 10-2
Arm 10-5
Boom 10-10
Swing 10-15
Dozer 10-22
Hydraulic cylinders 10-26
SECTION 11 – UPPER STRUCTURE
Canopy 11-1
Cab 11-4
Guard 11-6
Floor plate 11-10
Battery 11-13
Counterweight 11-14
Fuel tank 11-17
Hydraulic oil tank 11-20
Air cleaner 11-25
Muffler 11-27
Hydraulic pump 11-28
Radiator 11-43
Engine 11-47
Control valve 11-49
Solenoid valve 11-84
Pilot valve 11-86
Pilot valve travel 11-96
Slew motor 11-105
Joint swivel 11-139
Selector valve 11-154
Upper frame 11-159
SECTION 12 – TRAVEL SYSTEM
Low structure 12-1
Crawler 12-3
Slide plate 12-12
Roller tracks 12-14
Idler adjuster 12-19
Sprocket 12-28
Travel motor 12-29
Slew bearing 12-71
Lower frame 12-76
SECTION 13 – TROUBLESHOOTING HYDRAULIC SYSTEM
General precautions 13-1
Trouble diagnosis: Hydraulic 13-2
Troubleshooting 13-3
SECTION 14 – TROUBLESHOOTING ELECTRICAL SYSTEM
Trouble diagnosis: Electrical 14-1
Troubleshooting 14-2
1-3
SECTIONS INDEX
SECTION 15 – TROUBLESHOOTING ENGINE
Trouble diagnosis: Engine 15-1
Troubleshooting 15-2
SECTION 16 – ENGINE
Specifications and Performance 16-1
Cross Sectional Views 16-15
Cooling water, lubricating oil and fuel oil 16-17
Troubleshooting 16-21
Measuring instruments 16-25
Measurement, inspection and adjustment 16-29
Adjustment the valve head clearance 16-31
Checking the v-belt tension 16-32
Measuring and checking the injection pressure and spray patterns of the fuel injection valve 16-32
Checking and adjustament the fuel injection timing 16-36
Adjustament the no-load maximum (or minimum) revolutions 16-38
Checking the cooling water system and radiator for water leakage 16-38
Checking the battery 16-39
Checking the sensors 16-41
Checking the oil cooler 16-42
Checking the piston cooling nozzle 16-43
Measuring Procedure, Service Data and Corrective Action 16-45
Disassembly and reassembly 16-73
Service data 16-83
Tightening torque 16-89
Fuel injection pump for indirect injection system 16-91
Fuel Injection Pump for Direct Injection System 16-97
Governor 16-111
Turbocharger 16-123
