New Holland TN75FA TNH85FA TN95FA Tractor Service Manual 6035445100- PDF DOWNLOAD

Description

New Holland TN75FA TNH85FA TN95FA Tractor Service Manual

FILE DETAILS:

New Holland TN75FA TNH85FA TN95FA Tractor Service Manual

Size: 37.1mb
Item Number: 6035445100
Description: TN75FA TNH85FA TN95FA
Language: English
Type: Service Manual
Model: TN75FA, TN85FA, TN95FA
Page: 1272

DESCRIPTION:

New Holland TN75FA TNH85FA TN95FA Tractor Service Manual

GENERAL INFORMATION:

• This manual is divided into sections identified by two figure numbers and each section has independent page numbering. For easy reference, these sections have the same numbers and names as the Repairs Rate Book sections. The different sections can easily be found by consulting the table of contents on the following pages. The document number of the manual and the edition/update dates are given at the bottom of each page.
• Pages updated in the future will be identified by the same document number followed by a two figure update number (e.g.: 1st Update 603.54.451.01; 2nd Update 603.54.451.02; etc.) and by the corresponding issue date. These pages will be supplemented by a reprint of the updated contents page. The information contained in this manual was current on the date printed on each section.
• As NEW HOLLAND constantly improves its product range, some information may be out of date subsequent to modifications implemented for technical or commercial reasons, or to meet legal requirements in different countries. In the event of conflicting information, consult the NEW HOLLAND Sales and Service Departments.
• All maintenance and repair work described in this manual must be performed exclusively by NEW HOLLAND service technicians, in strict accordance with the instructions given and using any specific tools necessary. Anyone performing the operations described herein without strictly following the instructions is personally responsible for any eventual injury or damage to property.
• The Manufacturer and all organisations belonging to the Manufacturer’s distribution network, including but not restricted to national, regional or local distributors, will accept no responsibility for personal injury or damage to property caused by abnormal function of parts and/or components not approved by the Manufacturer, including those used for maintenance and/or repair of the product manufactured or marketed by the Manufacturer.
• In any case, the product manufactured or marketed by the Manufacturer is covered by no guarantee of any kind against personal injury or damage to property caused by abnormal function of parts and/or components not approved by the Manufacturer. All maintenance and repair work described in this manual must be performed exclusively by NEW HOLLAND service technicians, in strict accordance with the instructions given and using any specific tools necessary. Anyone performing the operations described herein without strictly following the instructions is personally re- sponsible for any eventual injury or damage to property.
• BATTERY Before carrying out any kind of service operation disconnect and isolate the battery negative lead, unless other- wise requested for specific operations (e.g.: operations requiring the engine to be running), after which it is necessary to disconnect the above mentioned lead to complete the work.
• SHIMMING For each adjustment operation, select adjusting shims and measure individually using a micrometer, then add up the recorded values. Do not rely on measuring the entire shimming set, which may be incorrect, or the rated value indicated for each shim.
• For correct rotating shaft seal installation, proceed as follows: before assembly, allow the seal to soak in the oil it will be sealing for at least thirty minutes; thoroughly clean the shaft and check that the working surface on the shaft is not damaged; position the sealing lip facing the fluid; with hydrodynamic lips, take into consideration the shaft rotation direc- tion and position the grooves so that they will deviate the fluid towards the inner side of the seal; coat the sealing lip with a thin layer of lubricant (use oil rather than grease) and fill the gap between the sealing lip and the dust lip on double lip seals with grease; insert the seal in its seat and press down using a flat punch; do not tap the seal with a hammer or mallet; whilst inserting the seal,
• check that the it is perpendicular to the seat; once settled, make sure that it makes contact with the thrust element, if required; to prevent damaging the seal lip on the shaft, position a protective guard during installation operations. SEALS Lubricate the O RING seals before inserting them in the seats, this will prevent them from overturning and twist- ing, which would jeopardise sealing efficiency.
