Sakai Soil Roller CV550 Series CV550D CV550DV CV550T Operation Manual

MACHINE AND ENGINE IDENTIFICATION NUMBERS 1
SAFETY NOTICES
1 BASIC PRECAUTIONS FOR SAFETY 4
11 General Precautions 4
12 Preparation for Safe Operation 6
13 Before Starting the Engine 7
14 After Starting the Engine 8
15 During operation 8
16 Loading and Unloading 10
1 7 Transportation 11
18 Handling the Battery 11
19 Towing 12
110 Before Servicing 13
111 During Servicing 14
112 Safety Decals 16
2 OPERATION 18
21 Instruments and Controls 18
211 Operator’s station 18
212 Gauges, indicator lamps and warning lamps 19
213 Switches 21
214 Operating levers/ pedals 24
215 Unloader switch 25
216 Fusebox 26
22 Handling and Adjustments 26
221 Seat adjustment 26
222 Scraper adjustment and replacement 27
223 Disengaging the brake when towing 28
224 Pass counter ( option) 30
23 Operation 32
231 Before-starting inspection 32
232 Starting the engine 33
233 After starting the engine 34
234 Traveling 35
235 Stopping/ Parking 36
236 Stopping the engine 37
23 7 Check after stopping the engine 37
24 Vibratory Operation 38

2 5 Precautions for Working 39
2 51 Compaction operation 39
252 When going downhill 39
253 On a slope 39
26 Applicable Jobs 40
27 After Operation 41
28 Loading and Unloading 41
281 Use of a trailer equipped with a winch 41
282 Self-propelling 42
2 9 After Loading the Machine 43
210 Transportation 43
211 Operation in Cold Weather 43
2111 Fuel oil and grease 43
2112 Coolant 44
2113 Battery 45
212 When the Cold Season is Over 46
213 For a Long Storage Period 46
214 During the Storage Period 46
215 When the Battery Has Discharged 47
2151 Connection and disconnection of booster cables 47
1
3 PERIODICAL MAINTENANCE 48
31 Precautions 48
311 Lifting the machine on a hoist 50
32 Walk-around Checking 51
33 Periodical Maintenance Points 52
34 Maintenance Procedure 54
(1) Every 10 hours or daily 54
(2) Every 50 hours 55
(3) Every 250 hours 57
( 4) Every 500 hours 59
(5) Every 1000 hours 59
( 6) As required 61
5 Adding Water and Lubricants 63
36 Electric Wiring Diagram 65
4 SPECIFICATIONS 67
