Skyjack SJIII Series 32xx 46xx & 68xx Compacts & Conventionals Operating Manual – PDF DOWNLOAD
$19.95
Skyjack SJIII Series 32xx 46xx & 68xx Compacts & Conventionals Operating Manual – PDF DOWNLOAD
Description
Skyjack SJIII Series 32xx 46xx & 68xx Compacts & Conventionals Operating Manual – PDF DOWNLOAD
FILE DETAILS:
Skyjack SJIII Series 32xx 46xx & 68xx Compacts & Conventionals Operating Manual – PDF DOWNLOAD
Language : English
Pages : 93
Downloadable : Yes
File Type : PDF
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Skyjack SJIII Series 32xx 46xx & 68xx Compacts & Conventionals Operating Manual – PDF DOWNLOAD
specifications and dimensions are subject to change without notice.
A mobile device that has an adjustable position platform supported from ground level by a
structure.
The SKYJACK SJIII Compact and Conventional series aerial platforms are
designed to transport and raise personnel, tools and materials to overhead work areas.
The aerial platform is a highly maneuverable, mobile work station. Lifting and driving must be on a
flat, level, compacted surface.
The operating manual is considered a fundamental part of the aerial platform. It is a
very important way to communicate necessary safety information to users and operators. A
complete and legible copy of this manual must be kept in the provided weather-resistant storage
compartment on the aerial platform at all times.
The operator must read and completely understand both this operating manual and the safety panel
label located on the platform and all other warnings in this manual and on the aerial
platform. Compare the labels on the aerial platform with the labels found within this
manual. If any labels are damaged or missing, replace them immediately.
SKYJACK warrants each new SJIII Series work platform to be free of defective parts and workmanship
for the first 24 months. Any defective part will be replaced or repaired by your local SKYJACK
dealer at no charge for parts or labor. Contact the SKYJACK Service Department for warranty statement extensions or exclusions.
