TECNA Forklift TMS10 TMS12 Parts Manual PN S01145110003 – PDF DOWNLOAD

Description

TECNA Forklift TMS10 TMS12 Parts Manual PN S01145110003 – PDF DOWNLOAD

FILE DETAILS:

TECNA Forklift TMS10 TMS12 Parts Manual PN S01145110003 – PDF DOWNLOAD

Language : English
Pages : 58
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

TECNA Forklift TMS10 TMS12 Parts Manual PN S01145110003 – PDF DOWNLOAD

COVERS & ADHESIVE LABELS / CARTER E TARGHETTE ADESIVE/ COUVERCLE ET AUTOCOLLANTS DE SEGNALISATION
DECKEL UND ABZ -BILD / TAPAS Y ADESIVOS DE AVISO (SHEET 1 A)
SUPPORTS AND CASTER WHEEL / SUPPORTI E RUOTA PIROETTANTE / SUPPORTS ET ATTELAGE / LAGERN UND RÄDER /
SOPORTE Y RUEDAS (SHEET 2 A/B)
LOAD WHEELS / RUOTE DI CARICO / ATTELAGES / RÄDER / RUEDAS (SHEET 3 A/B)
TRACTION UNIT / GRUPPO TRAZIONE / GROUPE DE TRACTION / ZUGAGGREGAT / GRUPO DE TRACCION (SHEET 4 A/B)
TRACTION MOTOR / MOTORE TRAZIONE / MOTEUR TRACTION / ZUGMOTOR / MOTORE DE TRACCION (SHEET 5 A/B)
MAGNETIC BRAKE / FRENO ELETTROMAGNETICO / FREIN ELETTROMAGN / ELEKT ROMAGN BREMSE / FRENO
ELECTROM (SHEET 6 A/B)
DRAWBAR CONTROL BOX / TIMONE SCATOLA COMANDI / BARRE BOITE DE COMMANDE / DEICHSEL STEUERUNGSBUCHSE
/ DIRECCION DE MANDOS (SHEET 7 A/B)
DRAWBAR CONTROL BOX PROPORTIONAL / TIMONE SCATOLA COMANDI PROPORZIONALE / BARRE BOITE DE COMMANDE
OPT/ DEICHSEL STEUERUNGSBUCHSE OPT / DIRECCION DE MANDOS OPC (SHEET 8 A/B)
DISTRIBUTOR / CENTRALINA IDRAULICA / DISTRIBUTEUR / STEUERUNG / DISTRIBUIDOR (SHEET 9 A)
HYDRAULIC SYSTEM / IMPIANTO IDRAULICO / INSTALLATION HYDRAULIQUE / HYDRAULIKANLAGE / INSTALLACION
HIDRAULICA (SHEET 10 A)
MASTS / MONTANTI / MATS / MAST / MÁSTILLE (SHEET 11 A-12 A-13 A)
HYDRAULIC CYLINDERS / CILINDRI IDRAULICI / CYLINDRES HYDRAULIQUES / HYDRAULIK ZYLINDER / CILINDROS
HIDRAULICOS (SHEET 14 A)
PART SHEET INDEX – INDICE DELLE TAVOLE – INDEX DES TABLES – TAFELVERZEICHNIS – INDICE DE TABLAS PAGE NO
FORKS / FORCHE / FOURCHES / FORKE / HORCAS (SHEET 15 A)
WIRE NET / RETI DI PROTEZIONE / GRILLAGE / DRAHNETZ / RED (SHEET 16 A)
WIRING DIAGRAM / SCHEMA COLLEGAMENTI CAVI POTENZA / DIAGRAMMA LIAISON CABLE ELECTRIQUE /
ELEKTRTSCHEANLAGEPLAN / ESQUEMA CONEXION CABLE POTENCIA (SHEET 17 A)
SHEATH DIAGRAM / SCHEMA COLLEGAMENTI GUAINE / DIAGRAMME LIAISON GAINES / MONTELANLAGEPLAN / ESQUEMA
CONEXION VAINA (SHEET 18 A)
ELECTRICAL DIAGRAM / SCHEMA ELETTRICO / SCHEMA ELECTRIQUE / SCHALTPLAN / ESQUEMA ELECTRICO
(SHEET 19 A)
HYDRAULIC DIAGRAM / SCHEMA IDRAULICO / SCHEMA HYDRAULIQUE / HYDRAULIKPLAN / ESQUEMA HIDRAULICO
(SHEET20 A)
BATTERY CHARGER / CARICA BATTERIA / CHARGUER / AULFLADERÄT / CARGADOR DE BATERIAS
(SHEET 21 A)
ELECTRIC HORN / CLACKSON MAGGIORATO / KLAXON MAJORE / VERSTAERKTE HUPE/ AVISADOR ACUSTICO AUMENTADO
(SHEET 22 A)
CONSOLE ADAPTER / ADATTATORE PER CONSOLLE / ADAPTATEUR POUR CONSOLE / ADAPTER FÜR KONSOLLE /
ADAPTADOR POR CONSOLA (SHEET 23 A)
CONNECTORS, CONTACTS, TOOLS / CONTATTI, CONNETTORI, UTENSILI / CONNECTEURS, CONTACTS, OUTILS /
KONNEKTORS, KONTAKTS, WERKZEUG / CONTACTO, CONECTOR, UTENSILIO (SHEET 23 A)
NUMERICAL INDEX / INDICE NUMERICO / INDEX GENERAL / ALGEMEINER INDEX / INDICE GENERAL

S.V 07/24
